Alarm Annunciators Dealers in Pune

• Application: Fire
• Display Type: Led
• Executive standard: Technical Conditions for Fire Indicating Panels (GB17429-1998)
• Operating voltage: 24 V (pulse modulation)
• Subsequent Fault: 60 flashes / min
• Ambient Temperature: -0 deg C to 50 deg C

Over the years, we have become a high-flying name since our Alarm Annunciators is qualitative and deliveries are time-bound. Ranked amidst the established names, we deliver the truly appreciable products from Maharashtra(India).

• No. of Channels : min. 2 No. to max 64 no.
• Type of Input : Potential free Contact (24 V DC excited), NO / NC types selectable.
• Type of Output : Potential free Relay Contact for external hooter
• Power Supply : 90-270 V AC, 50 Hz +/-10%, single phase
• Contact Rating : 1 c/o, 5 Amp. @ 230 V AC
• Window Indication : Group of super bright LEDs
• Window Size : 40 x 40 mm
• Flashing Frequency : 40 flashes / min
• Function : TEST, ACCEPT, RESET on front fascia, as well as remote terminals for the same
• Power Consumption : <10 VA
• Isolation : 1.4 KV between Input & Power Supply
• Mounting : Flush of the panel
• Temperature Coefficient : ± 0.01% peroC
• Response Time : <20 msec 2
• Enclosure : MS Powder Coated
• Dimensions : Please concern factory
• Weight : 3 kg
• Operating Conditions : Temperature 0 to 55oC / Humidity 5 to 95% non condensing

• Application: Industrial
• Voltage: 90-270VAC/DC
• Brand Name: MINILEC
• Application: Industrial
• Model Name/Number: MBAS0600
• Type: Wired

Based on latest single chip microcontroller technology, Compact design for reliable and accurate operation, Fast response time, Field selectable operational sequences, Incorporates a group of super bright LED's instead of twin Filament lamps for ultimate life at very less power consumption, Fault input contacts NONC site selectable by means of DIP switches.

Microprocessor based 8 / 16 /32 channel Alarm Annunciator accept input from potential free contacts, power supply available 230VAC or 24VDC or customer specify flashing rate 55/60 flash per minute, front key switch available for ACCEPT and TEST as well same function is available on back panel for remote operation, additional power contact through relay is available for alarm signal to connect warning light / hooter etc.

• FEATURES: 4 windows to 128 windows,Integral & Split models,Super bright LEDs for faciaetc.

Minilec Microprocessor Based Alarm Annunciators are designed to keep an alert and watchful eye on your plant and processes. The entire range has been designed with an insight into the modern day manufacturing plant and its future requirements. Minilec Alarm Annunciators are equipped with microprocessor-based design, super bright LED facia windows, site selectable, programmed sequences as per ISA standard and thoughtful provisions for troubleshooting and maintenance.

• Model: Alert 16W
• No of Points: Up to 16 potential free contacts
• Push Buttons: Test, Accept & Reset connect externally (Inbuilt optional)

ESD’s microcontroller based Alert series mimic type wall mounting Alarm Annunciators are used to give signals for audio visual indications of the fault condition. These Annunciators can be connected to potential free field contacts or signals from PLC’s. User can connect super bright RED LED’s which are mounted on the Mimic. These annunciators along with the mimics helps in visualising the online plant status.

In the process there may be an alarm or trip condition. This alarm condition or trip condition occurs at a set point of a parameter in the process. To indicate this we manufacture highly efficient, accurate and intelligent Microprocessor Based machine called Alarm Annunciator. An Alarm Annunciator continuously scans these fault conditions, which may occur during any process operation. Fault condition is indicated by flashing of the LED based facia windows of Annunciator and by sounding the audio Hooter and the operator can take necessary corrective action.

• Brand Name: GIC
• Voltage: 90-70/DC
• Model Name/Number: AU1D8S
• Type: Wired
• Number of Stages: 8 WINDOW
• Usage/Application: Industria

• Model Alert: 6081 (refer model selection chart)
• No of Points: Potential free contacts as per chart
• Contact type: Make or Break to alarm individually selectable

ESD s microcontroller based Alert series window type panel mounting Alarm Annunciators are used for giving audio visual indications of the fault condition. Specially selected super bright RED LED ensures long distance visibility and trouble free long life service.

• Size: 300(W) x 210(H) x 120(D) mm.
• Supply Voltage: 90-270 VAC/DC or 20-60 VDC
• No. of window: 12 Window (4R - 3C).
• Power Consumption: 0.8 VA per window

Based on latest single chip microcontroller technology, Compact design for reliable and accurate operation, Fast response time, Field selectable operational sequences, Incorporates a group of super bright LED's instead of twin Filament lamps for ultimate life at very less power consumption, Actuated thro' potential free fault input contacts, Fault input contacts NONC site selectable by means of DIP switches, Opto-isolated all fault inputs, immune to noise disturbances, Provision for external audible (Bell or Hooter) thro' potential free relay output contact, All models are with built-in Test, Silence(optional), Accept & Reset push buttons, provision on back side terminal strip, Specially designed power supply for high noise immunity, Wide input variations & having built-in transient protection, The extensive protection so provided safeguards all I.C.'s & components from failure, thereby offering complete reliability, All cards interconnected with plug-in polarized connectors for easy servicingType tested for noise, impulse and functional test as per various standards

Offering Alarm Annunciators, which are designed to keep an alert and watchful eye on your plant and processes. These Alarm Annunciators provided by us are dynamic, alert and responsive. We are one of the best known and trusted manufacturers, exporters and suppliers of Alarm Annunciator all over the country. The Alarm Annunciator manufactured by us are of top quality and superior grade material. Various models are available at reasonable market rates.
