Conductivity Meter Dealers in Pune

• Brand Name: USIS
• Application: Laboratory
• Retransmission Output: 4-20 mA or RS485 Modbus
• Relative humidity: not more than 85%

• Accuracy: +- 2 %
• Model Name/Number: CT-650
• Brand: Aster
• Display Type: Digital, 4 digit LED 7 Segment
• Resolution: 0.001 /0.01 /0.1 /1 PPM
• Physical Dimensions: 105 x 105 x 130 mm
• Cut Out Size: 92 x 92 mm
• Input Supply: 230 V A.C. 50 / 60 Hz Or 110 V A.C. Or 24 V D.C.
• Features: Mains operated Conductivity/TDS indicator. Ideal for outdoor as well as panel mount application. Automatic temperature compensation. 4-20 mA output for panel indication/PLC.
• Available Ranges: 0 - 19.99 µs/cm², 0 - 1999 µs/cm², 0 - 9999 µs/cm²
• Mounting Type: Field/Panel

• MOC: CPVC
• Temperature Range: 0-80°C
• Process Connection for Sensor:  ½” BSP Female
• Process Connection for Flow: ¼” BSP Female

MicroSet Instrumentation & Controls reserves the right to make changes to this data sheet or the product without notice, as part of our policy of continued developments and improvements.

• Brand Name: C-Gen
• Accuracy: 98%
• Voltage: 220 V
• Material: MS

Microprocessor based electronics allow wide operating range and long term signal stability. Optional relays provide control for adjustment or alarms. Also the meter comes with saddle mounting option or standard fittings to adopt to any process flow solution. CT 20 can be used for conductance, TDS signal transmission and display with 4-20 mA OP. Features: • Easy installation • Display in microSCM, ppm (TDS) • Customized 4 digit LCD • Weather proof enclosure • Tactile keys on front panel • Easy programming with front panel keys • Branded meter at the most economic price. • Clearly marked terminal labels • 4-20 mA Current OP

owing to our manufacturing facilities, we offer a wide array of digital conductivity ms cd 622 this instrument is a reading meter that measures the solution’s conductivity with the aid of a conductivity cell. Without the manual balance, the specific conductivity can be read on the digital display. Integrated circuits are included in these instruments and that keep the power consumption low.   specification frequency source : in built automatically selected selectable ranges : 0-20μs, 200μs, 2ms & 200ms / cms, measuring accuracy : ±1% of f.s. In all ranges ±1 count @ 20°c indication : 3.5 digit led calibration : single point manually decimal : automatic selection conductivity cell : approx. 1.0 cell constant with plastic protective cover (optional 0.1 cell) power requirement : 230 ± 10% 50 hz single phase approx environment : 0 to 50°c dimension : 205mmx65mmx130mm. weight : 1.5 kg. In aluminum cabinet standard accessories : conductivity cell, stand, rod, clamp & manual

• Brand Name: Baumer
• Conductivity: 14 selectable ranges
• Model: CombiLyz AFI5
• Measuring range: 0-1000 ms/cm
• Max Measuring span: 1000 ms/cm
• Min Measuring span: 500 Mu s/cm
• Reference Temperature: 25 deg C adjustable
• Repeatability: Less than 0.5 % FS , greater than 1 ms/cm
• Compensated Temperature Range: -20 to 150deg C

• Color: Blue
• Model Number/Name: HTL-02
• Brand Name: EEE
• Usage/Application: Laboratory
• Material: Metal Bar
• Usage: Laboratory
• Condition: New

PH Meter/ Conductivity Meter are reliable and accurate test instruments for measurement of Conductivity of aqueous solutions.These instruments are ideal for monitoring salt contents in water and soluble salts in soils. They are extremely useful instruments for agriculture and soil analysis labs, swimming pools, fertilizer plants, petroleum refineries, textile plants etc.    Features:    Reliable and easy to operate Cell constant adjustment facility ATC facility (S-942) High durability and longevity Properly tested

The apparatus consists of a copper sphere in which a mica heater is fitted. This small sphere is surrounded by another copper sphere and the insulating powder to be tested is filled in between these two spheres. The heat produced by heater is radially flows outwards in all directions through insulating powder. A digital temperature indicator is used to measure temperatures of Inner & Outer sphere. An ammeter & voltmeter is provided to measure heater input. By knowing heat input and temperatures, thermal conductivity of powder can be calculated. The unit is provided with asbestos powder, however any other powder can be tested with this unit. Specifications: Inner sphere - copper - 100 mm. dia. Outer sphere - copper - 200 mm dia. Heater – Mica heater placed in inner sphere. Thermocouples on outer surface of inner sphere and inner surface of outer sphere. Instrumentation & Controls : Digital Voltmeter - 0 - 199.9 Volts. Digital Ammeter - 0 - 1.999 Amp. Multy channel Digital Temperature Indicator. Heater Control. Service Required : 230 V.A.C. stabilised supply with earthing. Floor space - 1.5m X 1.5 m at working height.

• Accuracy: +- 2% FSD
• Weight: LESS THAN 1KG
• Voltage: 230 V A.C./ 110 V A.C./ 24 V D.C
• Color: BLACK
• Warranty: 1 YEAR
• Country of Origin: Made in India
• Brand: Aster - Embark
• Usage/Application: Industrial
• Material: ABS
• Model Name/Number: CI550
• Display Type: 4 digit LED display
• Dimension: 105 x 105 x 130 mm
• Features: REMOTE MONITORING/4-20mA Output, Tracebaility
• Resistivity Range: 0 to 2 lakhs uS/cm2(6 ranges are avilable)
• IP Rating: weather proof IP-65
• Galvanically Output: No output and 4-20 mA output
• Electrode Type: SS 316 & ABS 3/4 Inch and 1/2 Inch BSPM
• Mounting Type: Panel mount
• Resolution: 0.001/0.01/0.1/1 depending upon range
• Temperature Accuracy: 0-60 Degree C (optional 0-100 Degree C with ATC)
• I Deal In: New Only
• Packaging Details: CARTON BOX PACKING

Electronet series CT-100S are Conductivity transmitters used for various industrial applications. It can accept input from conductivity electrode of cell constant 0.01 / 0.1 / 1 & conductivity signal is transmitted in the form of electrical 4 - 20 mA signal. The on-line conductivity indication is provided through LCD. Span/Zero adjustments are easily accessible.

• Conductivity: 14 selectable ranges
• Min. measurable conductivity: 50 µS/cm
• Max. measuring span: 1000 mS/cm
• Min. measuring span: 500 µS/cm
• Max. measuring error: ± 1.0 % FSR , 0 … 1 mS/cm to 0 … 500 mS/cm ± 1.5 % FSR , 0 … 1000 mS/cm ± 1.5 % FSR , 0 … 500 µS/cm
• Reference temperature: 25 °C , adjustable
• Repeatability: < 0.5 % FSR ,> 1 mS/cm
• Compensated temperature range: -20 … 150 °C
• Temperature compensation: 0.0 … 5.0 % FSR/K , adjustable
• Step response time: ≤ 2.0 s
• Sample time: ≤ 0.4 s
• Concentration: 4 factory set media
• Customer defined media: Customer defined (30 point lookup table)
• Temperature: Free programmable range
• Measuring range: -20 … 150 °C
• Thermal response time, T90: ≤ 15 s
• Max. measuring error: ± 0.4 K
• Process temperature: -20 … 140 °C , permanent 140 … 150 °C , max. t < 1 h
• Process pressure: ≤ 25 bar
• Connection variants: G 1 A hygienic
• Wetted parts material: PEEK Natura
• Surface roughness wetted parts: Ra ≤ 0.8 µm
• Properties: Universal commands Common-practice commands Conductivity device family commands Device Specific Commands For more information please see ‚HART Field Device Specification‘
• Protocol: HCF standard, Rev.7
• IO-Link version: 1.1
• Device profile: Smart Sensor Profile
• Baud rate: 38,4 kbaud (COM2)
• Cycle time: ≥ 8,4 ms
• Process data length: 128 bit
• SIO-mode: Yes
• Process data (cyclic): Switch state Signal analog output 1 Signal analog output 2 Temperature Unit temperature Conductivity Concentration Actual measuring range
• Degree of protection (EN 60529): IP 67 IP 69K , with appropriate cable
• EMC: EN 61326-1
• Hygiene: 3-A (74-07) EHEDG EL Class I FDA (21 CFR 177.2415)
• Safety: cULus listed, E491206

The Model 2000XTC Transmitter resets the standard for thermal conductivity detector based applications within the process control industry. As an intrinsically safe transmitter, packaged within a rugged, weatherproof housing, the 2000XTC is suitable for use in harsh, hazardous outdoor environments. Using a novel, solid-state thermal conductivity sensor, this cost-effective transmitter can be configured to detect H2, He, N2, Ar, CO2 or a number of other gases of interest in binary or multi-component sample gas mixtures.   Features • Customer selectable gas constituents; 11 gases, 110 combinations• Automatic linearization• Auto-ranging with manual override to lock into specific range• Alphanumeric display which prompts and informs operator• Auto and remote initiated calibration capabilities• Bi-directional RS-232 serial digital communication port• Extensive self-diagnostic capabilities• 2 x programmable concentration alarm and system failure alarm relays

• Application: Food and Beverage Industry
• Body Material: Plastic
• Usage: Laboratory

Capitalizing on the competence of our skilled workforce, we are betrothed in the arena of presenting a wide consignment of Conductivity Meters. Widely cherished for their rust resistant, these are developed with perfection. To add, the final consignment could be delivered by us in bulk orders at most feasible rates.

• Ambient Temperature: 0 ° C + 60 " C
• Switching Unit: Micro controller Based.
• Mains Voltage: 65-265 V AC, 50HZ/18-36 V DC
• Power consumption: 2.5 VA
• Safety operation: Field selected switch over for minimum or maximum (FSL/FSH) switching points.
• Switch status display: LED L1 to L4 for four points of level Alarm and L5 for power ON/ timer.
• Features: No moving part, free from maintenance.

Digital Conductivity Meter, Digital Flow Meter, flow rate indicator

Br Instrumentation & Controls are labeled as leading manufacturer, exporter and supplier of conductivity measurement & control systems in India.

Conductivity Meters, Calorimeters, Water Baths, viscometers

Conductivity Meter, electronic instruments coils, Temperature Indicators

Thermal Conductivity of Metal Rod Apparatus, Ice Plant Trainer

Portable Conductivity Meter, Absorption Analyzer, Conductivity Analyzer

conductivity sensors, conductivity transmitter, Dissolved Oxygen Sensors

Conductivity Meter, magnetic flowmeter, magnetic float, Level Switches
