Dispensing Booth
Get Price Quote
We are recognized in the global market as one of prominent Dispensing Booth Manufacturers, based in India. Our Dispensing Booth restricts the harmful emission of dust, vapor, or powder during various industrial applications like drum tipping, powder dispensing, product sampling, etc. Features Designed in accordance with WHO-GMP 3 Stage Filtration Heavy Duty Low Noise Motor Blower Assembly Suitable to accommodate to floor & table balances Sizes 3'x2' 4"X2' 6Ix2" 4"X3' 4'X4' 6'x3' 6'X4' As Well As Custom-Made Sizes. Optional Accessories Magnehelic pressure differential gauge Flameproof electrical fittings Work table for balance Mini pleat HEPAfilter Ultra violet Tube Comprises of Filtrox make Imported Minipleat HEPA Filter with hot melt technology, which conforms to EU 13 Grade, with an efficiency rating better than 99.99% for 0.3 μ at supply position Filtrox make Minipleat HEPA Filter with hot melt technology, which conforms to EU 13 Grade, with an efficiency rating better than 99.99% for 0.3 μ at exhaust position Filtrox make prefilter which conforms to EU 4 Grade, with efficiency of 90% down to 10 micron These Filters arebasically made from micro-Fibreglass media and are washable Filtrox make Intermediate filter which conforms to EU 7 Grade, with efficiency of 95% down to 3 micron. These Filters are basically made from micro-Fibre-glass media and are washable Motor Blower provided are statically and dynamically balanced, Supply of sufficient capacity and static pressure is used to take care of airflow requirement for entire life of HEPA. Blower is high performance, noise abated, light weighted statically and dynamically balanced SS 304 Double Walled Side Panels. 7 Magnehelic Differential Pressure Gauge (0 - 25 mm: 2 Nos.) to monitor pressure drop across intermediate filter & HEPA filter and (0-10mm: 1No.) To monitor pressure drop across PRE Filter with respect to ambient Electrical control panel mounted on the side panel of the unit. Fluorescent Light (250 Lux) ON/OFF Switches for motor & lights 5/15 Amp single-phase switch socket for external equipment
Powder Dispensing Booth
120,000 - 350,000 Per Piece
1 Piece(s) (MOQ)
Equipment is used for dispensing of powder & chemicals to minimize the risk of contaminating of the work area & ensures the health for working person under the laminar air flow. The equipment is based on 3 level of filtration of air circulation. This ensures that the cloud or particles formed by the material dispensed is sucked from the pre filter, intimated filter & supply with mini pleat HEPA filter. Magnehelic gauge will indicate the pressure difference between the filters. During the initial cycle, we achieve class 100 air with velocity 0.45m/s +/- 20% below working area.Features Class 100 air Air curtain effect, Antistatic PVC curtains is provided Internal coving is provided DOP part up stream is provided Mini pleat HEPA filter eff. 99.997% down to 0.3 micron as a supply filter Pre filter eff. 95% Intermediate filter efficiency 90% Electric Motor with high capacity blower FRP blower with aluminum impeller dia 7"x41/2" Electrical supply 3 phase, 415 volt, 50Hz Velocity 0.45m/s +/-20% below working area Antistatic PVC curtains [optional] 10% of the air will throw out with Hepa filters. Feather Touch buttons for on off the Aux. socket & machine
Best Deals from Dispensing Booth
Powder Dispensing Booths
Get Price Quote
Powder Dispensing Booth
140,000 - 150,000 Per Piece
Dispensing Booth
Get Price Quote
Focusing on maximum client satisfaction, we are engaged in offering a quality range of Dispensing Booth. The offered booth is widely used for dispensing the powder and minimizes the risk of contaminating the work zone. Its usage ensures health safety of a person working with chemicals. This booth can be customised to meet the requirements of the clients. In order to maintain their premium quality and flawlessness, a team of quality controllers strictly check these booths against predefined quality parameters.
Powder Dispensing Booths
Get Price Quote
Powder Dispensing Booths, Clean Room Validation Service
Dispensing Booth
Get Price Quote
AMC, garment cabinets, Pressure Module, HVAC, Bio- safety Cabinets
Dispensing Booth
Get Price Quote
Portable Clean Room, Operation Theater Interior Designing, Inside Air Shower
Powder Dispensing Booth
Get Price Quote
Powder Dispensing Booth, Krystal Parallel Magnet Block
Industrial Powder Dispensing Booth
Get Price Quote
Industrial Powder Dispensing Booth, Laminar Flow workstation
Powder Dispensing Booth
Get Price Quote
Powder Dispensing Booth, Air Shower, odor control systems, Fume Extractor
