Dock Shelters Dealers in Pune

• Type: Dock Shelters
• Application: Warehouse
• Color: Bklack
• Feature: Longer Service Life
• Condition: Good

The NIHVA dock shelter is mainly used in situations where an optimal sealing is required, and in which large differences in vehicle size apply. Furthermore the dock shelter is well-suited to serve as a drive through shelter.

• Brand Name: Zirkel
• Function Type: Automatic
• Built Type: Modular
• Frame Material: Galvanized Steel,composed of U-shaped profiles with highly-flexible flaps,made from 3 mm black pla
• Side Section: Sides and roof section covered with vinyl fabric
• Features: These elements protect the doors against drafts,rain and wind

The organization is involved in catering to the market with its qualitative array of Dock Shelter. We are flexible enough to deliver the products that we make available across Maharashtra(India).

• Features: Dock Shelters are best solution for energy-saving.
• Width: 3400 mm
• Depth: 600 mm ( 900 mm on request)
• Curtain Weight: 3400g/m²
• Product: Motorized Sliding Doors
• Door Type: Single side / Bi-parting Type
• Door Mounting: On Top Track Mechanism
• Opening Direction: Horizontal
• Mounting Location: Inside/Outside
• Mounting Surface: On RCC/steel
• Wind Resistance: Up to 120 km/Hr *Higher Wind Pressure on Request
• Panel Profile: Mild Steel tubular section door frame with provision to fix 40 mm thk PUF panel
• Door Panel: 40 mm thk CFC free self extinguishing Polyurethane Foam (PUF) panel of density 40 Kg/m³ is having both sides’ 0.5 mm thk GI precoated sheets.
• PUF Panels: 50 mm / 60 mm/ 80 mm / 100 mm thick panels
• Cladding Sheet: Single skin Pre-coated G.I Cladding Sheet Both Side Pre-coated G.I Cladding Sheet without insulation Both Side Pre-coated G.I Cladding Sheet with Thermocol Insulation
• Plain Sheet: Single Skin Plain Sheet 1.2mm thick with all around beading Both side Plain Sheet 1.2mm thick with all around beading
• Outer Frame: Standard Tubular Pipe Section Optional M.S/G.I “C” type profile frame for all type of Cladding Sheet
• Top Track: Specially designed double modular top mounted track constructed from MS plate. Equipped with end stops
• Bottom Track: Bottom Guide track to avoid oscillation of the door optional as per design
• Rollers: Top Rollers : Dual Type Top Rollers assembly with bearings. Bottom Rollers: Pin type Bottom Rollers assembly with bearings.
• Door Operation Mechanism: Bottom Mounted Rack & pinion Mechanism / top mounted sprocket chain mechanism
• Hardware & accessories: Handle on both side of the door. Optional Locking system ONLY for manual Doors.
• Options available: In-Built Wicket Door. Bottom Brush Profile. Vision Windows. Louvers. Vertical EPDM rubber sealing.
• Motor Mounting: Top Mounted
• Drive Type: European make Non-Reversible gear Motor
• Control Unit: Inbuilt advance control, compatible with all types of features
• Function Logic: Automatic /Semi-Automatic /Deadman
• Manual Operation: Rotating release device easy to operate & key protected (Standard)
• Operating Switch: Push Button from Inside
• Metal Rack: Zinc platted Metal Rack

Loading systems dock shelters are manufactured to provide optimum stability and durability. Loading dock shelters provide an optimum seal between the internal and external environments, and assist with the reduction of energy consumption. As well as protecting your goods, Dock shelters also contribute to an improved workplace atmosphere which can also lower your absence rates due to illness. A complete range of loading dock shelters and seals are available to suit different types of vehicles.

With us, one can stay assured about the security of their payments as we follow safe and secure online and offline payment modes. We facilitate our patrons with the methods like bank deposits, cash, electronic funds transfer and various others. We are appreciated amidst the celebrated names in the sphere of providing exclusive range that includes Loading Dock Shelter.   Details : Warehouse Logistics Loading Bay Houses Manufacturing Industries Packaging Industries Transportation Application/ Uses : Warehouse Logistics Loading Bay Houses Manufacturing Industries Packaging Industries Transportation

• Finishing: Polished
• Built Type: Modular
• Usage/Application: For Industrial Storage Room
• Frame: Galvanized Steel
• Height: 8 Feet
• Closed Cell Pad Size: 300 mm x 300 mm
• Liner Material: Polyester Fabric

We bring forth our special quality Dock Shelters. These Dock Shelters are highly demanded in the market due to the durable nature and perfect finish. These Dock Shelters are made as per the international standards to suit the client needs. Our Dock Shelters are well tested under strict industry norms to check faults and flaws. Attributes SS SidewaysHigh shear strengthRetractable mechanismImported PVC fabricChoice of colors Benefits Corrosion free sideways even in acidic, humid atmosphereNo Anti static charge, thanks to Imported PVC fabric of high gradePrevents dust & minimize lossesEase of operations even in dense traffic conditions Applications PharmaceuticalPaintAutomobilemanufacturing industriesWarehousesLoading, Unloading bays

• Brand Name: Master Handlers

we are offering dock shelter. master handlers dock shelter, which is used for sealing the area around the door opening and a docked vehicle, making use of robust durable curtains. master handlers dock shelter is often used in situations where optimal sealing is required but when there are large differences in the dimensions of the vehicles using the shelter. also, it is ultimately suitable to serve as a drive-through shelter. master handlers has two options for the shelter: as a built-in (non-projecting) or projecting frame type. in order to excel in durability, the material from which the dock shelter's curtains are made is characterised by a high tear strength, uv-radiation resistance and resistance against extreme temperature fluctuations. as a standard, the front side of the shelter is provided with approach markers. these markers serve as reference points for the driver, in order to dock as accurately as possible. as such the gaps around the loading bay door resulting from incorrect docking are reduced and the possibility of damage limited. for custom-made solutions, various options are available. these can increase user-friendliness, improve safety en enable integration with other product or systems on the loading bay.

Ideal to use during loading and unloading applications where good insulation between the inside of the factory and body of the vehicle is required. Protects workers from wind, rain, cold & sun during loading and unloading operations. Safe structure consists of shockproof arches which can be retracted without harm if the vehicle makes an incorrect maneuver. Sturdy structure with top collar side caps in crosshatched and reinforced cut-proof heavy duty black rubber withstanding abrasion and weather conditions. Compact retracted on the wall when not in use.

The dock shelter seals between vehicle and building by keeping wind, rain and cold outside, or the cold inside in case of cold storage facilities, they contribute to an energy saving and efficient operation as well as to an improved working environment. The Dock Shelter is suitable in locations where vehicles of varying sizes and models dock.The choice of shelter is normally based on some basic conditions: Building design, type of vehicles, energy saving demands and goods requiring special conditions.For locations where vehicles of varying sizes and models arrive at frequent intervals, inflatable seals or dock shelters offer a good solution. In applications where the vehicles are of similar sizes, the pad seal is a simple but excellent solution.Effective sealing reduces energy costs for heating or cooling and here the inflatable seals provide the best values. Special goods e.g. deep-frozen food often requires unbroken cold chains. The inflatable seal or the pad seal are the products most preferred.Retractable built-in scissor arms will allow the shelter to adapt to the truck's position during the dock-in maneuvering.
