Fin Tubes Dealers in Pune

• Diameter: : 12.70mm, 15.88mm, 19.05mm, 22.20mm, 25.40mm & 38.10mm
• Wall thickness: : 1.42mm up to 3.25mm

Carbon Steel Fin Tubes are generally used for Heat Exchanger Applications in Chemical, Petrochemical, Pharmaceutical Companies, etc.Carbon Steel Low Fin Tubes are available with exact lengths required by customer, maximum upto 20 Meters.

• Features: Precise dimension, Sturdiness, Flawless finish
• Material: Stainless Steel, Mild Steel, Aluminium, Brass
• Brand: Natasha
• Application: Oil Coolers

• Size: 3/8”, 1/2", 5/8”, 3/4" & 1", 1.25” Outer Dia.
• Material: S.S.304/316.
• Length: 6 meters

Tube Size : 3/8”, 1/2", 5/8”, 3/4" & 1", 1.25” Outer Dia. Max Length : 6 meters Material : S.S.304/316.

We are offering integral fin tubes. Integral fin tubes were developed to increase the heat transfer performance of fluids while reducing the physical size and cost of the heat exchanger. In these tubes the fins are rolled out from the wall of the tubes and hence are integral with the tube. As the fins are formed from the base tube by rolling out material from its wall, the wall thickness under the finned section is reduced compared to the wall thickness at plain ends. These fin tubes can be manufactured from most tubular materials and the hardness of the material usually determines the finning code or fin profile. The harder materials such as nickel alloys, stainless steel, titanium are supplied with higher density (i.e 26,28,30 or 36 fpi). This shallow profile reduces the work hardening of the material and helps eliminate the possibility of root fin cracking. Whereas, with softer materials like carbon steel, copper, and copper alloys are supplied with deeper profile giving a lower fin density (i.e 16 or 19 fpi). These tubes can also be supplied with intermediate plain landing as well as u bent, where the u bend portion can be finned or un-finned.

Straight Fins : Max 12 finsinch, Tube Size : 38”, 12", 58”, 34" & 1", 1.25” Outer Dia, Max Length : 6 Meters, Material : C.S., Copper, S.S.304316, Cupro-Nickel, Brass.

Seco finned cooling tubes are designed with fins in contact with the holder’s front end, offering a large surface area for fast heat dispersal.

• Material: Stainless Steel, Mild Steel, Carbon Steel, Galvanized Iron, Aluminium
• Type: Integrally Finned Tubes, External Finned Tubes, KL Finned Tubes, L Finned Tubes, G Finned Tubes
• Size: 1/2 inch, 3/4 inch, 1 inch
• Unit Pipe Length: 3 meter, 6 meter, 9 meter, 18 meter, Customized
• Unit Length: 3m, 6m, 12m, 18m, 24m
• Features: Anealed, Cold Drawn
• Brand Name: NFTPL
• Steel Grade: SA179, SA210, SA334
• Condition: New
• Tube OD: 9.53 mm up to 40 mm
• Tube Length: 500 mm up to 16 Mtrs.

• Features: Sturdy construction, Low maintenance, Optimum performance, Precise design, Economical rates, Highly durable

• height: 4.00mm

Integral medium high fin tubes are available in copper with or without internal spiral ridges. These medium high fin tubes are manufactured out of:15.875mm, 19.05mm, 22mm, 25.4mm, 31.75mm & 38.10mm od tubes.

Integral finned tubes are manufactured by rolling process on plain tubes. During finning operation, the inside diameter of the plain tube is reduced and helical fins are rolled on the tube wall.

crimpled strip root solder fin tubes, Chilling Plants

Fin Tubes, Sheet Metal Parts

wire wound finned tubes, Water Cooled Heat Exchangers

Fin Tube, Auto Radiators, Oil Coolers, Heat Exchangers, air cooler radiator

MS Finned Tube, Rotary Motorized Soot Blower, super heaters, hp heaters

The Spiral Finned Tubes, Furnace Coil, Tank Heater, Heating Tape

Integral Finned Tubes, Heat Exchangers, Pressure Vessels, Spiral Tubes
