Flaring Machine Dealers in Pune

• Features: Machines available for end forming, cutting and punching of tubular parts,Compact and modular, yet robust designs,High productivity machines etc.

Electropneumatics offers total solutions in tube processing including tube bending, end forming and cutting. The end forming and cutting machines cover a wide range of diameters and applications in the automotive, air conditioning and ventilation, HVAC, furniture, boiler, shipbuilding, piping, construction and such industries.

• Power: 440 V AC, 3 phase, 7.5 HP
• Max tube dia.: 50 mm
• Max tube length: 400 mm
• Max tube thickness: 2.5 mm
• Swedging force: 20 Tone (Hydraulic)
• Hydraulic: Rexroth/ Yuken
• Control electric: Siemens
• Pneumatic: Festo/ SMC

• Brand Name: EEE
• Production Capacity: 300 piece / hr
• Usage/Application: Industrial
• Model Name/Number: SPM-72
• Material: Mild Steel
• Model: SPM-78

This machine manufactured by PRECIMAKE AUTOMATION is designed for tube flaring machine. The machine operation is controlled by PLC based control panel. Through HMI flaring time will be set.a. Switch ON the control panel power supply.b. Ensure inlet Air Supply of 5 bar.MACHINE SPECIFICATIONS1. Machine overall size : 1080×1550×5802. Operating Height : 950mm from ground level3. Job loading / unloading : Manually by operator4. Power supply : 1Ǿ, 230V, 50Hz AC Supply5. Supply Air Pressure : 0.5MPa or 5barSEQUENCE OF OPERATION 1. Set the flaring time from HMI and load all child parts carefully2. If home condition not satisfied before cycle start the machine will indicate the fault ( buzzer will turn on ) simultaneously HMI will display the fault occurred3. Before cycle start insure that operators hand will be removed 4. On cycle start Flaring cylinders goes down 5. After flaring time it will goes up 6. Machine is ready for next cycle
