A/J 210 electronic flow monitor are high speed micro- controller based units with a high resolution back-lit display. By using front panel tactile keys, one can view / program different parameters A-210 / J-210 is a Digital Rate Indicator and Totaliser suitable for VATS sensors or others giving pulse output of 200 Hz max.A/ J-210 one can read the flow rate in LPH, M3 / Hr only and corresponding Total reading in Litre or M3 only. Our IP 65 grade enclosures make our flow meter versatile on both Panel & Field uses Along with these two consecutive displays these monitors also have relays to operate in various modes such as: Batcher, Pulser, and Rate Switch

• Material: Aluminum
• Certification: ISO 9001:2008 Certified
• Type: Indicator
• Surface Treatment: Polished
• Warranty: 1 Year
• Function: Rate Indicator Only

Features Ruggedised, State-of-the-art, Micro-controller based system. Dual functionality flow rate indication / 4 digit and 9 digit, totalizing and Batch Counter mode. User configurable flow rate range, Field settable flow totalizing rate. Relay outputs – Optional for Batch or Set point operation, 24VDC 100 mA Excitation Supply for external use. Retransmission output – Optional, Serial communication port with MODBUS protocol – Optional, Flameproof enclosure – Optional.    Application Flow Indicator Totalizer model FIT is a panel mounted instrument with multi-functionality viz. Flow Rate indication, Flow Totalizing, batch counter & alarm for instantaneous flow. It accepts mA signal proportional to flow rate from flow transmitter. Flow Transmitter can be DPT with orifice assembly, Rotameter, Magnetic Flowmeter etc. with output of 4-20 mA. FIT displays instantaneous flow rate on 5 digit LED Display. Flow Rate and Totalizer range can be configured as required even at site. Totalizer is a 8 digit LED Display. Totalizer cab be reset manually or remotely as optional. The unit incorporates two relays, from which one can be used for alarm for instantaneous flow & one for batch counter or both for alarm. On each set point one contact output is given, which can be used for control or hooter applications. Power Supply for external transmitter (24 VDC @ 100 mA) is a standard feature. It eliminates need of separate power supply to power the transmitter. For batch counting, batch count can be set. When flow total equals preset count, system giver a contact output. It can be used for control operations like dosing, stoppage etc.

• Suitable For compressed gas & air • Linear or Square Root operation. • Accuracy of ± 0.25 % of Full Scale. • Three nos. of 4-20 ma dc i/p from DP / Flow transmitter, Pressure transmitter,   Temperature transmitter/RTD PT-100. • Universal power supply. • Isolated 4 – 20 mA output proportional to Flow rate. • 4 digit LED display for flow rate & 6 digit for total flow is available. • Serial Interface with Computer through MODBUS RTU Protocol. • Two numbers of alarms is available on instantaneous flow rate. • If Flow rate exceeds the set reference flow, the lower 4 digit Display for Flow rate   blinks.

Flow Rate Indicating Totalizer cum Batcher MS FL 27   FEATURE : Microcontroller based design Simple & cost effective construction Flow ranges - Programmable Flow Units – Programmable Batching Controller 4 to 20 mA DC Isolated Retransmission output Specification Type : 4 to 20 mA DC Range : Programmable Unit : Programmable Set Points : 02 Nos. Output : 02 Nos. Potential Free Relay Retransmission Output : 4~20 mA DC Isolated Mounting : Panel Mounted Dimensions : 96 x96 x 100 mm Supply : 230 VAC

Presenting Flow Indicator Totalizers which are of top quality. The Flow Indicator Totalizers manufactured by us are made from best grade material available. These are manufactured for many industrial applications. Our Flow Indicator Totalizers serve maximum efficiency, longer equipment life and users safety. We are one of the best known and trusted manufacturers, exporters and suppliers of Flow Indicator Totalizer all over the country and in international markets as well. These totalizers are available with us at reasonable market prices.

• Material: Stainless Steel
• Display: LCD Digital
• Protection grade: IP67
• Temperature Range: -50-200 Degree C
• Features: Low Price, The simple and compact module, Effortless to install

Models• FIT- 96X96 with mA/Pulse input• FIT- 96X48 mA input• MFM 393 • NHM 393 • FIT- 96X96 with mA/Pulse input    Flow Indicator Totalizer model FIT is having Dual functionality flow rate indication / 8 digit flow totalizing and Batch Counter mode with configurable flow rate range. Flow Indicator Totalizer is a panel mounted instrument with multi-functionality viz. Flow Rate indication, Flow Totalizing, batch counter & alarm for instantaneous flow. Flow Indicator Totaliser accepts 4 - 20 mA DC Linear or Pulse or Square root corresponding to flow rate,Factory set. Flow Transmitter can be DPT with orifice assembly, Rotameter, Magnetic Flowmeter etc. with output of 4-20 mA. Flow Indicator Totaliser incorporates two relays, from which one can be used for alarm for instantaneous flow & one for batch counter or both for alarm. There are two relay outputs which operate on flow rate and/or totaliser as per combination selected. Serial connectivity on RS485 port with MODBUS RTU protocol. Flow Indicator Totaliser is used in many applications such as water treatment plants,sawage water treatment plants, effluent water treatment plants,food,chemical plants and water distribution.   Flow Indicator Totalizer model FIT-4896 is 7 Segment LED display for either 5 - Digit Flow rate or 8 - Digit Totalizer toggled by front key. Flow Indicator Totaliser is a panel mounted instrument with multi-functionality viz. Flow Rate indication, Flow Totalizing, batch counter & alarm for instantaneous flow. Flow Indicator Totaliser accepts mA signal, linear / square root, proportional to flow rate from flow transmitter. Flow Transmitter can be DPT with orifice assembly, Rotameter, Magnetic Flowmeter etc. with output of 4-20 mA. Serial connectivity on RS485 port with MODBUS RTU protocol. MFM 393 is micro-controller based arithmetical computation unit generally used in mass flow applications. Mass Flow Computer accepts three 4-20mA inputs at a time. MFM 393 displays instantaneous Mass Flow rate on 4 digit LED Display. Totaliser can be reset manually from password protected PROG menu. MFM 393 provides linear 4-20mA retransmission signal corresponding to Calculated Mass Flow Rate for other panel mounted instruments like recorders, controllers etc. Serial connectivity on RS485 port with MODBUS RTU protocol. NHM-393 is a Net Heat Calculator specially developed for Centralized Air Conditioning Applications which is mainly used in Building Automation Systems. NHM-393 is a net heat calculator supplied with RTD Pt1000 Temperature Transmitters for accurate temperature sensing. 8 Digit Net Heat Totaliser is an important feature of NHM-393. This totaliser makes NHM-393 a reliable energy meter for the total net heat consumed. Real Time Clock is used to calculate the totaliser values very accurate.Most reliable 4-20mA loop is provided for easy installation of the NHM-393 anywhere in the plant which is powered by unit. NHM-393 calculates net heat consumed in chilled water air conditioning systems which supports all flow meters which will provided 4-20mA signal corresponding to volumetric flow rate. RS485 - MODBUS RTU protocol for serial communication is provided for energy management systems. Ideal for Building Automation Applications.

• Accuracy: ± 0.25 %

This instrument is designed to measure the mass flow rates of Bio gas, Natural gas, CNG, O2, CO2, Compressed air and other compressed gasses in closed conduits. The instantaneous density is calculated by measuring the temperature and pressure.Most suitable for Compressible Fluids having variation in their Pressure & Temperature which includes Compressed Air & gases like Biogas, LPG etc.

Features Compact 1 / 8 DIN size case Two pulse and three control inputs 2 relays (NO) of 5 A and 250 V OR 2 Open Collector Outputs; 100 mA maximum One 4-20 mA analog output RS232 / RS485 port for serial communication and printing Password security for function keys +24 VDC unregulated O/P for AC powered unit NVRAM to retain data on power failure Both inputs can have up-to 16 points linearizing K factor

4 – 20 mA Input Flow Indicating Totalizer Fully configurable through front keypad Accuracy better than ± 0.25% FSD 24 V DC Transmitter Power Supply Retransmission output (Optional) 2 programmable Alarm contacts for batching PC Communication – RS232 / RS485 MODBUS RTU Protocol (Optional) Available in 6 / 8 / digits totalizer LED / LCD display Selectable Operation: Linear / Square Root Enthalpy / Mass flow versions Available in 92 X 92 or 68 X 138 mm Cutout

The Instrument can be configured to work on Steam Natural gas or any gas Accepts up to three inputs– FLOW( mA ), PRESSURE( mA ), TEMPERATURES ( RTD) Gives efficient Pressure and Temp. Compensations for Mass Flow Calculations Retransmission and RS-485232 communication Available Calculates Flow rates in NM3Hr. or SM3Hr. – as selected 810 digit Flow Totalizer with Password protected Resetting Weather proof or flame proof housing

Item Code: MASSDetails: The Instrument can be configured to work on Steam Natural gas or any gas Accepts up to three inputs– FLOW( mA ), PRESSURE( mA ), TEMPERATURES ( RTD) Gives efficient Pressure and Temp. Compensations for Mass Flow Calculations Retransmission and RS-485/232 communication Available Calculates Flow rates in NM3/Hr. or SM3/Hr. – as selected 8/10 digit Flow Totalizer with Password protected Resetting Weather proof or flame proof housing

• Display: 3 1/2 digit, 1/2" red LED for flow rate
• nput: 4 to 20 mA DC or pneumatic (3 to 15 psi) optional
• Square Root Extraction: Provided in-built (optional)
• Range: Adjustable at site
• Count Rate: Adjustable at site
• Counter: 6 digit, Electromechanical or 6/8 digit, digital with battery back-up
• Transmitter Supply: 24 V DC provided for powering two-wire transmitter
• Retransmission output: 4 to 20 mA DC (optional)
• Supply: 230 V AC, 50 HZ (others on request)
• Mounting: Flush on panel
• Dimensions: Cutout : 1) 92mm x 92mm. 2) 136mm x 68mm Bezel : 1) 96mm x 96mm. 2) 144mm x 72mm
• Depth: Less than 200mm

We are an eminent and leading trader of flow totalizers
