Furnaces Dealers in Pune

• Type: Electric
• Material: Stainless Steel
• Certification: CE Certified
• Weight: 100-300kg
• Voltage: 380V
• Application: Heating Process
• Power: 1-3kw
• Warranty: 1 Year
• Automation Grade: Automatic
• After-Sales Service Provided: Spare Parts

Direct Baleout Type Melting Cum Holding Furnace These furnaces are suitable for HPDC / GDC shops where production rates are required upto 250Kg/Hr for single alloy. This furnace can also be used as central melting furnace for several GDC machines where metal can baled out for the baleout pot provided on furnace and can be fed to GDC machines placed in vicinity. These furnaces uses burner flue for melting of solid aluminium which in terms increases furnace efficiency and reduces melting losses.       Distinct benefits of DIRECT BALEOUT TYPE Melting cum Holding furnaces with ONLINE DEGASSING 1.Melting and Holding is done in single chamber. 2.Reverses flow pattern of flue gases ensures higher retention of flue in furnace. 3.Higher retention of flue results in lower fuel consumption and very low melting loss. 4.Continuous melting rate ensures better productivity than batch type furnaces. 5.No blind corners in refractory which allows easy and thorough cleaning of furnace 6.Metal tapping is possible through DIRECT BALEOUT POT. 7.Furnace can be optionally equipped with ONLINE DEGASSING SYSTEM. 8.Additional heat recuperation can be provided as an option.

• Capacity: 200 kgs / hr
• Heating Media: LPG
• Operating Temperature: 1000oC
• Application Area: For all types of heat treatments

Muffle furnace use Resistance wire as heating elements, which can be used up to 1200oC. These compact muffle furnaces are perfect for many applications in laboratory. It is an ideal instrument for materials annealing and sintering in your research.

• Brand Name: Kristech
• Material: Iron
• Driven Type: Electric
• Color: Ivory
• Condition: New
• Power: 1-3kw
• Automation Grade: Automatic
• Application: Heating Process

Lab Furnace Standard sizes & upto 1000Deg CChamber Size(Inches)    Volume        Power4x4x9                               2Ltrs            1.5KW5x5x10                             4Ltrs            1.8KW6x6x12                             7Ltrs            2.0KW Other Sizes available as per your requirement Made in Light weight material, using Kanthal A1 wire of suitable gage, with PID controller ,giving fast heating

• Type: Industrial Furnace
• Material: Plastic
• Certification: ISO 9001:2008 Certified
• Weight: 100-300kg
• Voltage: 110V, 220V, 230V
• Condition: New
• Application: Heating Process
• Power: 1-3kw, 12-15kw
• Driven Type: Electric, Mechanical
• Warranty: 1yrs
• Automation Grade: Automatic

Lead Melting furnace of 400 kgs capacity to inside electrically heated with 6 Nos tubular heaters enclosed in three fabricated frames to prevent damage to heaters at the time of feeding lead ingots complete with electrical control panel suitable for mounting on wall. The electrical control panel shall have a temperature controller connected to a thermo couple fitted to the furnace and shall also have a timer to enable automatic switching ON at preset time prior to start of shift. The furnace shall have a hood for fume escape through a chimney. Ducting to chimney and chimney shall not be in our scope of supply.

• Power Source: Electric
• Voltage: 230 V
• Automation Grade: Automatic
• Material: SS
• Frequency: 50 Hz

• Type: Conveyor Furnace
• Certification: ISO 9001:2008 Certified
• Condition: New
• Country of Origin: India

in order to keep pace with the requirement of the clients we manufacturer and supply a wide array of spring tempering furnaces. the range we offers consist of continuous spring tempering furnaces that provide accurate function and optimul performance. owing to the years of experience, we manufacturer and supply of quality gamut of continuous spring tempering furnaces. these product are reckoned for its durability and strength condition: new quality: good usage: industrial speciality: long functional life advantage; easy to operate durability: long life feature: affordable price, high performance

Controlled Atmosphere Brazing FurnacesTPM Depot has a technical tie-up with Shroyoku Sanggyo Furnace Company. We are Specialized in Controlled Atmospheric Brazing furnaces in India , Aluminum Brazing Furnaces,continuous Aluminum Brazing Furnaces Manufacturers in India. These furnaces are being used for brazing aluminum heat exchangers for automotive and other industrial applications.

• Power Supply: 230 VAC single phase 2500 W
• Material: Metal
• Max.Temperature: 950 deg.C.
• Size: 125 (H) X 125 (W) X 300 (D)
• Durability: Long Life
• Surface Finishing: Polished

• Power Source: Electric
• Automation Grade: Automatic
• Brand Name: BMC
• Melting Material: Aluminium
• Type Of Furnace: Tilt
• Input Voltage (V): 440 V
• No.of Phase: Three Phase

• Material: Stainless Steel
• Voltage: 220V
• Power: 1-3kw
• Driven Type: Electric
• Warranty: 1yrs
• Automation Grade: Automatic

Light weight ceramic fibre wool insulation (instead of brick insulation). The outer casing is made of double walled thick P.C.R. sheet duly powder coated. Heating elements are made of KANTHAL 'A-1' wire & backed by high temp. Insulation which avoids loss of energy. Temp. Control unit consists Microprocessor Digital Temp. Controller fitted in front of furnace with two pilot lamps. The apparatus is completed with thermocouple, silver thermal fuse, and main lead with power plug. To work on 220/230 volts or 400/440 volts A.C. Maximum temp, is 1000C & working temp. 950C.For model of higher temp.

The Electrical Tilting Furnace developed by Energy Systech is a must-have piece of equipment in an aluminium casting shop. Metal is melted in a turbulence-free condition inside a crucible, held at constant temperature, treated and degassed. This precious metal is available to be used for castings at unparalleled convenience and efficiency. This furnace is commonly used as a feeder furnace for the PDC holding furnace. Large castings, typical pour weight 40-400 kg of aluminiumAs a feeding furnace to PDC Holding Furnace (Launder transfer) As a central melting furnaceAs a feeding furnace to Induction Furnace for alloy making (Launder transfer) Available in Melting and Holding varietiesVery economical operationSuperb temperature controlDegassing possible inside the furnaceRapid discharge of treated melt reducing oxidation and heat lossNoiseless operationRequires minimal maintenance and care  Hydraulic and Geared options Rugged constructionSmooth, jerk-free tiltingLong life "Vertical Heaters", the workhorse innovation by Energy SystechExcellent crucible support resulting in its long life

• Brand Name: Sensoheat
• Phase: Single phase
• Finishing: Powder Coated
• Working Frequency: 50/60 Hz
• Heating Range: Upto 1200 degree Celsius
• Rapid Heating Rate: 1 to 20 c/min
• Current: 20A

• Features: Easy maintenance for replacing the heating element, Robust construction, Easy to operate .
• Max Temperature: 0-500 degree Celsius
• Melting Material: Aluminium
• Voltage: 380V
• Capacity: 1 ton
• Location: Pan India

Applications Annealing Normalising Hardening Solution Treatment Heating Forge Heating Tempering Aluminum Solutionising Stress Relieving Ductile Iron Full Annealing. Auto cycle control Ramp, Soak, Cool ..... 8 Steps Profile 10, 20 Profile Memory Multi Input Multi Output (MIMO) PID Controlling Action. Micro processor based programable controller. one burner, one thermocouple forms one pair as zone, thus multi zone control Digital display for time temprature graph online with USB pendrive for data storage, Wired lan PC connectivity for real time graph printing Firing High Velocity Short Flame Burner Direct On/Off pulse firing effect. Smokeless perfect combustion The furnaces are calibrated for uniformity as per API 6A Standard ( The Temperature Difference Between Highest & Lowest Points at Stabilised Conditions should not be more than 13ºC.) Mechanization Trolley - movement by geared motor with brake. Door - movement by geared motor with brake, counter weighed, Door Lock Unlock - innovative,Pneumatically operated instant latching unlatching for perfect sealing Construction Strong rigid construction Heat resistant grade CI castings at door and frame, bogie and furnace interface eliminates warpage. Railway rails for load bearing under temperature. Double sealing minimising heat losses. Insulation High temperature high density ceramic fibre modular lining. Self supporting U-fold door lining. Recuperator All fuel fired furnaces are equiped with recuperator to recover the heat from flue gases by preheating combustion air. By thumb rule a rise of 150 degree C in combustion air 7.5% heat is recovered. PLC control Large furnaces handle high value materials, it is essential to install PLC for opration to avoid manual errors. PLC checks each & every operation prior to loading of materials called booting to ensure air/gas/power etc. are within the specifications & all the sensors are in working condition PLC monitors each & every operation during auto cycle for supply conditions, flue temperatures burner operations any deviation is automatically notified audio visualy & through SCADA PLC keeps event history for the record Control Panel Aesthetically powder coated control panel. Electrical switch gears for drives, burners. Status indication and control. Burner sequence controller and flame failure device. Programmable startup, burner, temperature controlling system. Calibrations Thermal survey as per API 6A Standard. All measuring instruments calibrated to national traceability
