Humidity Transmitters Dealers in Pune

Based on the AirChip 3000 Digital TechnologyInnovation in Humidity and Temperature Measurement Highest accuracy at 0.8 %rh and 0.1˚C Outstanding long-term stability and chemical resistance Widest Temperature measuring range at -100…200 ˚C Two Interchangeable HygroClip digital or analog probe inputs 10,000 point data logging with time stamp and battery back-up Up to 4 programmable Analog Outputs available Digital Output Options Multiple Alarm Relays Audible and Visual Alarms Galvanically Isolated power supply

• For monitoring climate in building technology, BMS, AHU's and climatic chambers• Accuracy: ± 2.5% rH• Simple adjustment concept for adjustments on site• Connection to P2A Software for parameterization, analysis and adjustment

The Humidity sensor reacts very quickly on humidity leaps and measures accurately and free of any hysteresis. These characteristics suits especially good for a precise and quick control of the room climate. These are compact Transmitters for humidity, temperature and combined humidity temperature with excellent price performance ratio. Advantages: Calibration free Ready to use Precise humidity measurement Drift stable thanks to wide sensor area Available with optional temperature sensor Smallest dimensions Mechanical robust and easy to integrate Different output options on request Technical Data: Measurement Principle :- Capacitive humidity sensor Humidity measurement range :- 0 to 100%Rh Operating temperature :- -25 to +85°C Operating voltage :- 8 to 32VDC Current consumption : 4 to 20mA Output signal :- 4 to 20mA (0 to 100%Rh) Temperature sensor :- optional Pt100Pt1000. Accuracy :- < 3% Rh Terminal connectors :- Soldering terminals for VCC, Analog out 4 to 20mA, Loop-through of optional temperature sensor.

• 2- wire 3/4-wire Transmitter• Response time t 63 < 10 S• Accuracy at 23 ± 5 °C ± 1.0 % rh/0.2K• Measurement range -50... 200 °C/ 0...100 %rh• Display (Optional) Backlit graphic LCD• Output : 4 - 20 mA, 0 - 10 VDC , 0 - 1 VDC

• Output: 4 - 20 mA
• Features: Pocket friendly price , Easy to install, Durable.
• Working Range: 0-20m/s
• Response Time: Typ. 4 sec. or typ. 0.2 sec.
• Power Supply: 24V AC/DC +- 20 %
• Current Consumption: Max 150mA
• Electrical Connection: Screw Terminals max. 1.5 mm
• Angular Dependence: Less than 3 % of measurement
• Probe Length: 200 mm

Humidity Transmitter, Electric Actuator, Circular Chart Recorder

Humidity and Temperature Transmitter, LBFS Series Baumer Make Level Switch

Humidity Temperature Transmitter, GP-S070 Graphic Touch Panels
