Input Module Dealers in Pune

• Categories:: Falcon Mini Falcon 100 Falcon DIDO24

The term can also be used as part of an action; to "perform IO" is to perform an input or output operation. IO devices are used by a person (or other system) to communicate with a computer. For instance, a keyboard or a mouse may be an input device for a computer, while monitors and printers are considered output devices for a computer. Devices for communication between computers, such as modems and network cards, typically serve for both input and output.

• Output Type: Open Collector Output
• No. of Inputs: 14
• Types of Input: Pulse input 1Hz to 10Hz
• No. of Outputs: 8
• Maximum input amplitude: 5VDC/ 12VDC /24V DC > FACTORY SET.
• Communication Port: RS485 2 wire, Modbus RTU Protocol
• Supply voltage: 230 VAC + 10%, 1ph, 50 Hz
• Enclosure: DIN rail mount, ABS molded , 32 terminal box Size : 70 x 150 x 114 mm ( H x W x D )

Multichannel Counter FALCON148 is blind unit with RS485 connectivity which is best suitable for SCADA,Counting applications. This module uses MODBUS RTU protocol for serial communication. RS485 serial port is provided to make the module suitable for multidropping application. FALCON148 can also be used as slave module with PLC FALCON 148 module is optically isolated inputs, accepts potential free contact signals. FALCON148 can be used as a Production Counter, Revolution Counter, Fault Counter, Bottle Filling Counter, Digital Batch Counter, sensing level switches, proximity switches, door switches, alarm/ trip conditions in Panel, pump/ motor status, equipment status etc.FALCON148 module is optically isolated open collector outputs to drive external Relay module. These outputs can be used to perform supervisory control actions like giving alarms, operating valves, switching ON/OFF pumps/ motors etc.

Input Output Interface Module, Solid State Relay, Proximity Switch
