Modbus Gateway Dealers in Pune

• Brand Name: Planet

Standard Industrial Modbus TCP/RTU/ASCII Network Integration PLANET has added the Industrial Modbus TCP/IP Protocol to its easily-integrated industrial management level products that come with SCADA/HMI system and other data acquisition systems on factory floors. Moreover, the industrial IT SNMP network is upgraded to the Industrial automation Modbus TCP/IP network. PLANET industrial management level products with the Modbus TCP/IP Protocol offer flexible network connectivity solutions for the industrial automation environment.   To complete the industrial automation environment application solution, PLANET has announced a first industrial level 1-port RS232/422/485 Modbus Gateway, IMG-2100T, a bridge that converts between Modbus TCP/IP Protocol and Modbus RTU/ASCII Protocol. It features a wide operating temperature range from -40 to 75 degrees C and a compact but rugged IP30 metal housing.   Features Serial Interface One DB9 interface that supports RS232 One terminal block interface that supports 2-wire RS485 and 4-wire RS422/RS485 operation Asynchronous serial data rates up to 921600bps   Ethernet Interface 1-port 10/100BASE-TX RJ45 interface with auto MDI/MDI-X function   Management Function Built-in IP-based Web interface and telnet interface for remote management Software Protocol supports Modbus TCP, Modbus RTU, Modbus ASCII, IP, ARP, DHCP and DNS Supports RTU Master, RTU Slave, ASCII Master, and ASCII Slave four serial operation modes via management interface Master mode supports 32 TCP slave connection requests Slave mode supports 32 TCP master connections PLANET Modbus Gateway utility for finding client device on the network PLANET Smart Discovery utility automatically finds the client devices on the network Firmware upgrade/configuration backup and restore via HTTP protocol   Industrial Case and Installation IP30 metal case DIN-rail and wall-mount designs Redundant power design - 9 to 48V DC / 24V AC, redundant power with reverse polarity protection Supports 6000 VDC Ethernet ESD protection Free fall, shock-proof and vibration-proof for industries Supports extensive LED indicators for network diagnosis -40 to 75 degrees C operating temperature  Reset button for resetting to factory default

• CODE: SC10MK

Model SC10MK is a programmable, Web enabled Modbus RTU to Modbus TCP protocol converter. High end CPU along with Linux OS makes it an idle choice for applications like Meter readings, Solar controls & any other protocol conversion applications.

• Features: 15 KV ESD protection for serial signals(MB5001C-Sis only)

Rugged metal housing with DIN-Rail Wall-Mount, Ease-of-use in Modbus protocol conversion include RTU, ASCII and TCP, Monitor, Manage and Control Industrial Field Devices Remotely,Configurable via Built-In Web Server Serial Console, or Telnet,Upgradeable firmware from remote-PC via Ethernet.

• Supply: 10-28 VDC
• COMMUNICATION: Rs485 for Master side. HART on slave side.
• COMMUNICATION SETTINGS: 8 way DIP switch for baud rates from 9600,19200,38400, 57600 & station ID from 1 to 64 for MODBUS side.
• NO OF SLAVES: 15 HART slave units

Hart - RS485 Converter HMT-112, HART to MODBUS Converter is designed to accept HART inputs from maximum 15 slave units and convert standard variables into fixed MODBUS address registers. This is useful to accept / read exact values available for Flow, Pressure, Temperature transmitters in digital form in the control room eliminating errors in Analog input acquisition and process systems. User selectable baud rate for MODBUS Master on DIP switch is provided. LED Indications for master and slave operations for easy diagnosis.

Hmt-01 is designed to accept hart signals from field instruments in multi drop mode and convert standard variables into fixed modbus address registers. This is useful to accept read exact values available for flow, pressure, temperature transmitters in digital form in the control room eliminating errors in analog input acquisition and process systems.

Advantech EKI-1200 : Modbus Gateway, HP Routers, AMP / TYCO Patch Cord

modbus gateway

modbus gateway, Remote Monitoring System, software applications
