Natural Gas Meter
Get Price Quote
0.0
View Profile
Natural Gas Meter
Get Price Quote
1 Piece(s) (MOQ)
We have Natural Gas Meter within the working range of the meter the rotor spins proportional to the actual velocity of gaseous material flowing. A pick-up sensor produces an electrical signal as each blade crosses through its low magnetic or rf field. This signal is amplified and conditioned by a transmitter or fed directly into a rate/totalizer, and represents the actual cubic feet per minute (acfm) flowing through the meter. The k-factor is stenciled on the meter body in pulses per actual cubic feet (p/acf). Because gases are compressible, most people desire to measure the equivalent amount of gas corrected for the line pressure and temperature to standard cubic feet per minute (scfm at 60â°f, 14.69 psia). If the flow temperature and pressure are relatively constant, then a simple correction can be calculated to shift the k-factor from p/acf to p/scf and a simple totalizer (measurement systems india make ) may be used. When flow temperature and pressure are not constant, a flow computer. specifications linearity 1 â±1.0%/0.5% repeatability 1 â±0.25% maximum over-range 125% of flow rate for intermittent periods frequency output 0 to 1,100 hz voltage output approximately 100 mv@ 100 hz to 1.5 v (rms)@ 1,000 hz. Pressure drop 0.5 psi at 100% of flow range pressure rating we manufacture flowmeters for most pressures. installation vertical or horizontal (any direction). Materials of construction body: 316 l stainless steel. Flanges: 316 stainless steel rotor: 431 stainless steel. Rotor shaft/bearings: standard: tungsten carbide v-cup cartridge frame retainer: 302 stainless steel cartridge frame: 316 l stainless steel. Temperature range:meter with bearing structure of: standard: tungsten carbide: -40â°f to 300â°f (-40â°c to 149â°c). For other temperatures consult factory.
0.0
View Profile
Best Deals from Natural Gas Meter
Natural Gas Filtration
Get Price Quote
In pharmaceutical, food and chemical processes, small batches of compounds are to be dried. Dryers specially made for this purpose use hot dry air. Air is sucked from the room through filters and blown over heater coils. The blower forces this hot air through the compound to be dried. Part of the compound gets carried along with the air while being removed by an exhaust blower. A collector or bag filter is used to collect it. MagneticTM instruments are used for pre-filter as well as collector filter to monitor clogging. MagneticTM instrument with switch can start cleaning cycle of collector filter at preset differential pressure.
0.0
View Profile
Natural Gas Meter
15,000 Per Piece
01 Piece (MOQ)
0.0
View Profile
Natural Gas Meter
Get Price Quote
Natural Gas Meter, LPG Fired Gas Burner, Lpg Gas Meter
0.0
View Profile
