Non PTH PCB Dealers in Pune

• Maximum board size: 850 mm x 450 mm
• Thickness: 0.2 to 3.2mm

Thickness of 0.2 to 3.2mm (with finish copper of 1-43 oz), Line width and spacing of 6 6 mils (sample lots 55mils), Minimum finished hole size of 0.3mm, Surface finish of Solder levelling Lead free hot air levelling ENIG. Laminate Tg- 130-180( normal). Mask finish- Green, White, Red, Blue, Black. Maximum board size- 850 mm x 450 mm.

Double sided pcb, Double-Sided PCB are a step above single sided in their complexity. Double Sided PCBs require plated through holes to provide better anchoring for soldered components and front to back electrical continuity. Most designs require solder mask front and back along with a silkscreen layer for component designators. Very often double sided designs utilize mixed technologies of through hole (PTH) and surface mount (SMT).

• No. Of Layers: 2
• Masking Color: GREEN
• Shape: Square
• Country of Origin: Made In India
• Board Thickness: 1.6MM

Double-Sided PCB are a step above single sided in their complexity. Double Sided PCB require plated through holes to provide better anchoring for soldered components and front to back electrical continuity. Most designs require solder mask front and back along with a silkscreen layer for component designators. Very often double sided designs utilize mixed technologies of through hole (PTH) and surface mount (SMT). Double Sided PCB circuits were the gateway to higher technology applications. The advent of the plated thru hole was quickly adapted and allowed electronic designs to expand in capability and shrink in physical size. Today the double sided printed circuit board technology remains the workhorse of the assembly industry. There are near limitless applications for old and new designs.

• Application: Industrial electronic
• Power: 20v-240v
• Dimensions: 28'' x 49''
