Proveg Engineering & Food Processing Private Limited Ganesh Nagar, Pune, Maharashtra

We are a quality conscious firm and consider all the quality measures right from the product development to the final dispatch. As a dependable name, we make sure that our products are of excellent quality. To make it possible, we use only quality-approved and certified raw materials sourced from reliable vendors.

Watermelon Seeds Shelling Machine (watermelon, melon, pumpkin) seed shelling machine can realize melon seeds shells alone. The equipment has low energy consumption, compact structure, take up the space is little, seed kernel loss is low, the operation convenient maintenance etc. Technical Details Specification and Commercial Detail of Machine: Power: - 1.5kw (440V) Capacity: - 120-150 kgh seeds kernel Whole kernel rate - ≥95% Skin contains seed rate - under 0.3% Size - 1580*680*900mm Weight- 200kg Operation People - 1 persons

Wall Mount High Speed Disperser is the disperser mounted to the wall, widely used in Euro market. It saves producting room significantly and especially suitable for small-batch production of products with many varieties. Technical Parameter: Model Motor Power (kw) Speed (rpm) Disc dia. (mm) Material Capacity (L) Lifting (mm) Wight (kg) PVG-SFSW-4 4 0-1450 200 SS304 ≤ 200 900 500 PVG-SFSW-7.5 7.5 0-1450 230 SS304 ≤ 400 900 600 PVG-SFSW-11 11 0-1450 250 SS304 ≤500 900 650 PVG-SFSW-15 15 0-1450 280 SS304 ≤700 900 700 PVG-SFSW-18.5 18.5 0-1450 300 SS304 ≤800 1100 900 PVG-SFSW-22 22 0-1450 350 SS304 ≤1000 1100 1100 PVG-SFSW-30 30 0-1450 400 SS304 ≤1500 1100 1400

We are connected with well-known transport providers to make sure the distribution of deliveries is done out without a problem and on time. In our well-structured warehouse, we store the entire lot in a secured manner under the strict supervision of our expert warehouse personnel. Moreover, our facility is installed with all required amenities needed for safe storage.

Application: ultra-fine powder (e.g. Rice flour, milk powder, building materials, coffee powder, seasoning powder, toner) granular material (e.g. Forage, granular fertilizer, seeds, nuts) flaky material (e.g. Potato chips, crackers) strip material (e.g. Noodles, bean sprouts,) paste materials (e.g. Bean paste, paste, architectural coating) solid liquid mixture (e.g. Pickled pepper) technical parameter: model external dimensions (l×w×h) mm type of bag range of bag width (l×w) mm packaging speed bagsmin id of reel max. Allowable od of reel compressed air requirement power supply vfs320 1050×800×1010 pillow bag, gusset bag, die cut bag (50~200)×(80~150) 40~80 ф72mm ф400mm 0.6mpa 350 lmin 440v 50~60hz 3kw vfs5000d 1470×988×1400 (50~280)×(70~180) 30~80 ф75 mm ф400 mm 0.6mpa 0.36lmin 440v 50~60hz 3kw vfs5000b 1800×1220×1680 (50~340)×(80~250) 20~90 φ75mm φ450mm 0.6mpa 350lmin 440v 50~60hz 5.5kw vfs7300b 1854×1440×1930 (50~460)×(80~350) 30~80 φ75mm φ500mm 0.6mpa 350lmin 440v 50~60hz 6kw vfs7800 1900×1470×2080 (50~430)×(70~350) 20~70 φ75mm φ450mm 0.6~0.8mpa 350 lmin 440v 50~60hz 3kw vfs1100 2150×1750×2300 (300-650)×(300-535) 5-30 φ75mm φ600mm 0.6~0.8mpa 300 lmin 440v 50~60hz 4.5kw

Specification: Model PVG-VCV60Q PVG-VCV80Q Speed Cartoon 30-100 per min 30-90 per min Main motor 1.2kva 1.2 kva Vacuum Pump 0.4 kva 0.4 kva Weight 1400kg 1500kg Dimensions: Model PVG-VCV60Q PVG-VCV80Q Width 1665mm 1665mm Length 3825mm 4330mm Height 1600mm 1600mm Loading Area A 1000mm 1100mm B 1000mm 1250mm

Using vacuum absorb the high temperature frying oil into the filter cylinder, through filter cloth purification, then return to frying machine. Filter cloth use optimum porosity and permeability, separating impurity particles and other harmful substances, thereby inhibiting frying oil acid value too high and the generation of peroxide, prolong the service life of oil, to improve the quality of the products. With the characteristics of high filtration accuracy, energy saving, simple operation and so on. technical parameters: model pvg-lyj-600 pvg-lyj-800 capacity 30-50kgminute 80-120kgminute working pressure 0.3mpa 0.3mpa filter material stainless steel strainer stainless steel strainer filtering area 0.68 m2 (three strainer) 1.2 m2 (three strainer) 1.1 m2 (five strainer) 2.0 m2 (five strainer) entrance pipe 1.5 inch 2.0 inch exit pipe 1.0 inch 1.5 inch power 1.5 to 2.2 kw 3 to 5kw dimension 850 x 810 x 880 mm 1100 x 1000 x 1320 mm

Material : MS

Operation Mode : Manual

Color : Blue and White

Electricity Connection : Three Phase

Capacity : More than 100 kg

Brand Name : PVG

Voltage : 440 V

Warranty : 1 year

Characteristics: Using photo-cell detecting the color mark and dual-tracing system to effectively eliminate the packing error, thus promises a high rate of qualified finished product. New double vertical sealing design makes excellent sealing below normal temperature (about 80 degree) thus raises the packing speed and reduces the burning of packing film. Bag length and packing speed are displayed automatically. The processing line of this machine can be modified to save space. Using servo motor control to achieve step-less speed changing and dynamic adjusting during operation; Large colored touch screen displays all data. It also can store the product-menu. When changing products, bag length and material supplying position can be adjusted automatically; packing quantity added and paused; compared with SW, the driving system is more simple and the maintenance is more convenient. Features: Photoelectric detection color, two-way tracking, which can effectively eliminate the packaging error, to ensure high yield. New vertical seal heating design, so that the sealing temperature is lower than the conventional temperature of about 80 degrees, effectively improve the packaging speed, Hot film bag length, speed automatically displayed. Can be designed across the production line, saving space. SF-W servo type servo motor control, can achieve variable speed control, dynamic adjustment of the running process; Type color touch screen design, can achieve packaging data storage, call out, automatically adjust, track, find cut point, reported Warning tips, fault tips, packaging count accumulated, suspended; transmission structure is easier than SW, maintenance square Main Technical Data: Model Spec SF-W 450150 Film Width(mm) 450 Size of Package L: Length(mm) B: Width(mm) H: Height(mm) L:80~240 B:40~80 H:35~ 70 Packing Speed ( Bagmin ) 30~80 Dimension (mm) 5000×960×1750 Film Material compound Film of heat seal： OPPPE,PTPE,ALPE, etc Total Weight(kg) 1300 Main Power

Traditional Tri Roll Mill is suitable for grinding and dispersing ointment or high viscosity slurry with comparatively high requirement of fineness. It achieves required grinding effect by the friction and crashing among the three tilt rollers rotating at different speeds. Ti is equipped with emergency brake button to prevent equipment damage caused by foreign matter roped into. The roller is citing of special had alloy and ceramic materials are options. Technical Parameter: Model Speed supply Motor Power (kw) Roller dia. (mm) Roller Length (mm) Roller Material Hardness Slow speed (rpm) Mid Speed (rpm) Fast Speed (rpm) Size (mm) Weight (kg) PVG-SYGM -65 240V 50HZ 0.75 65 136 Cr12 Quenching HSD55-60 26 70 145 410x400x450 60 PVG-SYGM -150 440V 50HZ 2.2 150 300 Chilled alloy HSD68-72 34 78 181 830x830x1910 500 PVG-SYGM -260 440V 50HZ 7.5 260 675 Chilled alloy HSD68-72 23 64 183 1680x1320x1150 21100 PVG-SYGM -405 440V 50HZ 15 405 810 Chilled alloy HSD68-72 14 42 130 1950x1900x1450 5200 PVG-SYGM -405 10) 440V 50HZ 22 405 1000 Chilled alloy HSD68-72 14 42 130 2150x1900x1450 5800

Cjd1000k quantitative ton bag packaging machine adopts high accuracy sensors (0.02%) and high-resolution control instruments to constitute the metering control system with high accuracy and good stability. The feeding mechanism adopts gate valves of two diameters to control 3 levels of feeding: fast, slow and precision feeding and is suitable for materials of various properties and states. The machine has wide packaging range, adjustable in the range of 500~1200kg. It is suitable for packaging of big packaging bag. Parameter setting and weighing calibration are simple and easy to understand and the operation is convenient. technical parameters: model form of packaging feeding range metering accuracy packaging speed cj1000k ton-bag 500~1200kg 0.1ú.oimlⅲ 0.3% static accuracy 0.1ú. Oiml level iii, dynamic accuracy 0.3% feeding starting to feeding end, 4~6 tonshour

Technical Parameter: Name - Thin batter mixer Model - PVG-DJJ-200 Power - 1.1kw Capacity - 200L Overall dimension - 1330*790*1400mm

Technical Parameter: Name - Thick batter mixer Model - PVG-DJJ-100 Mixing tank capacity - 100L Power - 1.1kw Pump power - 0.75kw Overall dimension - 1330*790*2100mm

We supply professional Sunflower Seeds Hulling Line. The sunflower seeds shelling and separating equipment possesses high automatic characters. If they are exists any unshelled seeds, they will be sent to the next shelling machine for hulling clearly. The shelling and separating equipment, owning independent intellectual property rights, is a perfect machine to deal with sunflower seeds. First, this equipment removes the miscellaneous impurities from the raw materials such as little stone, flat seeds etc. And next it follows the working procedures: cracking, shelling, separating, grading and rechecking the sunflower seeds and kernels. Technical Parameters of PVG-TFKH-1200 Sunflower Seeds Hulling: Model Power Source Capacity Perfect Kernel Rate Dimensions (L*W*H) Weight PVG-TFKH-1200 14.59kw440v 500kg-800kgh ≥90% 1440mm*280mm*410mm 5000kg Technical Parameters of PVG-TFKH-1500 Sunflower Seeds Hulling Machine: Model Power Source Capacity Perfect Kernel Rate Dimensions (L*W*H) Weight PVG-TFKH-1500 16.47kw440v 500kg-1000kgh ≥90% 1130mm*330mm*550mm 5200kg

Station packaging unit machine is the classical model for bag feed fully automatic packaging, can independently complete such works as bag pickup, date printing, bag mouth opening, filling, compaction, heat sealing, shaping and output of finished products, etc. It is suitable for multiple materials, the packaging bag has wide adaptation range, its operation is intuitive, simple and easy, its speed is easy to adjust, the specification of packaging bag can be changed quickly, and it is equipped with the functions of automatic detection and safety monitoring, it has outstanding effect for both reducing loss of packaging material and ensuring sealing effect and perfect appearance. The complete machine is made of stainless steel, guaranteeing hygiene and safety. s-shaped bag feed packaging machine adopts servo motor for its main power, the merit is stable operation and fast speed, when a fault occurs with the metering scale or there is no material, the packaging machine does not run and stops and waits for material, when the metering scale discharges material, the packaging machine runs automatically, thus not only improving production efficiency, but also reducing wastage of packaging bags. Suitable form of bag: four-side-sealed bag, three-side-sealed bag, self-standing bag, handbag, zipper bag, plastic bag with cover, paper-plastic bag, etc. Suitable material: materials like liquid, sauce, granules, powder, material of irregular shape, etc. Material of the packaging bag: preformed bag and paper-plastic bag etc. Made of multiply composite film. technical parameters: model bag size mm metering range g packaging speed bagsmin control motor cf6-200a w:100-200mm l:100-300mm 5-1000 25-45 variable frequency motor cf6-200a-s w:100-200mm l:100-300mm 5-1000 25-45 servo motor cf6-300a w:180-300mm l:200-500mm 100-2500 20-40 variable frequency motor

Weight : 35 Kg

Voltage : 230 V,50 Hz

Spiral Mixer is a machine that mixes flour and water or other ingredients into dough. It can be used singly or work with other equipment. It is widely applied for making dough for various cakes, biscuits, bread and steamed bread in hotels, restaurant, canteens, etc. it can also be used for mixing other materials. Technical Parameters: Model Spiral making quantity (kg) Spiral making time 9(min) Voltage (V) Spiral making motor powder (kw) Tipping bucket motor power (kw) Mixer power (kw) Overall dimensions L x W x h (mm) Weight (kg) PVG-HMJ-15 15 5-15 440 1.1 - 19 785x425x820 102 PVG-HMJ-15D 15 5-15 240 1.1 - 25 785x425x820 102 PVG-HMJ-25 25 5-15 440 1.5 - 25 880x460x886 138 PVG-HMJ-25D 25 5-15 240 1.8 - 25 880x460x886 138 PVG-HMJ-50 50 5-15 440 3 0.55 26 1110x630x1070 290 PVG-HMJ-75 75 5-15 440 4 0.75 27 1188x710x1220 414 PVG-HMJ-100 100 5-15 440 5.5 0.75 27 1250x740x1300 485 PVG-HMJ-125 125 5-15 440 7.5 1.1 20 1540x800x1375 938 PVG-HMJ-150 150 5-15 440 7.5 1.1 20 1632x800x1375 1056

Material : Carbon Steel

Power : 10 Hp

Brand Name : PROVEG

Soybean Stone Mill Machine is a traditional characteristics crafts. Stone running slow, the soybean milk have full natural release of soya protein and a variety of nutrients. The natural minerals in the stone and the soybeans' nutrition mix together to make the soaybean milk more fragrant and delicious, more nutritious Technical Parameters: upper stone diameter (cm) bottom stone diameter (cm) upper stone thickness (cm) botton stone thickness (cm) Voltage (v) Power (w) Capacity ( KGH) Rotation Speed (rpmmin) 30 50 11 8 220 180 3-5 33-35 35 55 10-12 8 220 180 4-6 40 60 13-14 10 220 370 5-8 45 70 13-16 10 220 370 7-10 50 80 13-16 10 220 370 10-15 60 90 18 12 220 1500 15-20 70 100 18 12 440 2200 20-25 80 110 20 13 440 3000 30-40

Technical details and specification: name - small type garlic peeling machine model - pvg-fdry-100 specification :- capacity - 80-150kgh input voltage - 220v,50hz total power - 1700w electric heating - 1500w*1 flow into the air source - 1.05m3min or 7.5k w air compressor air pressure - 8kgcm2 dimension - 60*60*135cm.

Small size continuous frying machine double belt, frequency conversion speed, product will not float, color and fragrance consistent the belt have a turnover mechanism, can clean the oil floating debris and net residue easily automatic temperature control, safe and convenient frying time: 10 seconds to 3 minutes technical parameters: model heat mode pvg-xdfl-2000 - electrical heating, power 24 kw pvg-xdfl-2500 - electrical heating, power 30 kw pvg-xdfl-3000 - electrical heating, power 36 kw pvg-xdfl-3500 - electrical heating, power 48 kw pvg-xdmfl-3000 - direct coal combustion pvg-xdmfl-3500 - dimension and oil tank size: because of the different frying technics, oil thank size and power should be adjusted according to moisture content and frying time of the products.

Introduction: The machine uses automatic mechanized operations, simply send the onion into the hopper, conveyor machine can transport to the onion peeling machine, the device will be automatic peeling Machine peeling power is large, regardless of onion skin thick or thin, tight or loose. Even refrigerated onion peel can be done at one time The special design of the aircraft skin way to make peeling, the onion without injury The machine high capacity per hour can be achieved around 500KG The machine can be matched with other machines such as root cutting machine, slicer, dicer , Dryers and other supporting components automated assembly line onion processing equipment Technical Parameter: Model PVG-BSP-1 Applied Small onion 30-50mm Capacity Around 500kgh Power 1.5KW Needed air compressor air pressure:0.8-1.0Mpa, Air capacity: 6-8 CBMM3 Voltage 440V, 50HZ, 3 Phase Dimension 2550*850*1800mm Weight 350kg

Small Bun Production Line for small steamed bun is high-tech equipment used the essence of the advanced foreign technology. This production line consists of material batter, mixing, sheeting into pieces, rounded, vibration screening, winding, arrangement, baking, cooling conveying, etc. The whole line has a high degree of automation, stable operation unit performance, it has excellent appearance and the international advanced technology, can replace imported equipment. Technical Parameters: Small steamed bread production capacity - 4 tonsday or so Egg yolk cakes production capacity - 2.5 tonsday or so Installed power - 220 kw(the small steamed bun heating 160 kw, production egg yolk pie heated 200 kw) The compressed air pressure - 0.6 mpa The oven length - 15 m Steel band width - 800 mm

Flow chart: mixing extruding drying flavoring cooling equipment: mixer screw conveyor extruder air conveyor roasting oven air conveyor twin roller oil sprayer cooling conveyor model and parameter: model parameter pvg-bfj-i mixer pvg-lxsl-i screw conveyor pvg-slg65-ii extruder pvg-fsj-1.1 air conveyor pvg-kx-3-5d dryer pvg-fsj-1.1 air conveyor pvg-pyj-i oil sprayer pvg-gt-ii roller pvg-lqss-ii-5-f air conveyor installed capacity (kw) 4 1.1 35 1.1 27 1.1 1.87 0.75 1.1 dimension (m) 1.050.81.4 3.20.60.7 2.50.91.2 1.1 0.6 0.5 5.41.31.7 1.10.6 0.5 0.70.50.9 3.91.0 2.0 5.4 0.6 0.5 technical parameters: output: - 100-150 kghr square for workshop - 50m2 and 4m high installed capacity - 72kw . Voltage frequency (3 phase) - 220v 60hz dimension (m): - 25.0 x 2.0x 4 workers required: - 2-3 workers
