RTPFC Panel Dealers in Pune

• Usage/Application: Pf Improvement for dynamic load/ Harmonic Reduction
• Phase: 1 - Phase
• Brand Name: Treffer
• Working Temp: 50 Degree Celsius
• Voltage: 400/440/480/525/690/800V
• Rating: 50 to 4000Kvar
• Mode of Switching: Static

This high-speed real-time Automatic Power Factor Correction Panel comes with suitable Tune and Detune harmonics filter. Venus technocrafts ensures that they compensate the reactive power required by any load requiring PF correction in a very short time (less than 20 ms), thereby reducing failure in sophisticated equipment. Maintaining unity PF, reduction in KVA demand, reduced electricity bills, enhanced capacity of transformer, switchgear, HT cable are few of the benefits accrued.       This state-of-the-art electronic switching device is primarily designed as a replacement of the electro-mechanically switched equipment. These systems while distinctly superior come with a price tag very comparable with the conventional switching APFC systems.

T-RTPFC panel is integrated with CRCA MS Sheet encloser with powder coated, fully wired with self-healing MPP capacitor & Reactor, capacitor duty Thyristor, fan, APFCR, all switchgear with IP protection, busbar AL/CU, with IEC STD, The thyristor switched contactor shall be capable of handling a the continuous current of 130% of the rated capacitor current at rated voltage of 415V. The blocking voltage of the thyristor switch during off condition should be minimum1800 Volt peak. Every thyristor switch should be capable of handling a the dv/dt of 2000 Volts/S. The thyristor switched contactor used shall turn on at zero differential voltage across it. This zero differential voltage tolerance shall not exceed 6 Volts peak value around zero. The time delay between turn off and subsequent turn on should be as minimum as possible and in the range of milliseconds. There should not be any discharge devices across capacitor that can exceed the watt loss of more than 30 watt.   MODEL : T-RTPFC   Specification: 50/60Hz Rating : 50….4000Kvar Voltage: 400/440/480/525/690/800V Mode of switching : Static Application: Pf improvement/Harmonic Reduction

• Specifications:: Rating : 50.....4000Kvar , Voltage : 400/440/480/525/690/800V ,Mode of Switching : Static and Application : Pf Improvement for dynamic load/ Harmonic Reduction

T-RTPFC panel is an integration of CRCA powder coated MS Sheet enclosure , fully wired with Self healing MPP capacitor & Reactor , capacitor duty Thyristor, fan,APFCR, all switchgears, with IP protection , busbar ALCU, with IEC STD, a) The thyristor switched contactor shall be capable of handling the continuous current of 130% of the rated capacitor current at rated voltage of 415V. The blocking voltage of the thyristor switch during off Condition should be minimum 1800 Volt peak. Every thyristor switch should be capable of handling the dvdt of 2000 Volts S. b) The thyristor switched contactor used shall turn on at zero differential voltage across it. This zero differential voltage tolerance shall not exceed 6 Volts peak value around zero. c) The time delay between turn off and subsequent turn on should be as minimum as possible and in the range of milliseconds. There should not be any discharge devices across capacitor that can exceed the watt loss of more than 30 watt.

• Usage/Application: Textile
• Phase: 3 - Phase
• Material: Iron
• Rated Voltage: 415 V
• Application Type: Chemical Industry, Cement Plant, Sugar Plant, Textile, Hospital
• Rated Reactive Power: 50 to 1000KVAR
• Automation Grade: Automatic
• Frequency (Hz): 50
• Power Source: Electric

RTPFC panels with IoT gateway, LT-HT ATS motor starter

real time power factor correction panel, factor control panel, MCC PCC Panel
