Self Centering Rotator
Get Price Quote
We bring forth highly efficient Self Centering Type Rotators for our esteemed clients. The Self Centering Type Rotators offered by us is widely used for manipulation of shells or cylindrical component for processing or positioning. Our Self Centering Type Rotators assure hassle free service and optimum machine availability for production. These Rotators are widely used in fabrication shops. Moreover, we are also engaged in providing a customized range as per the specifications of our clients. Attributes : High mechanical efficiencyExcellent load bearing capacitySturdy construction Specifications : Roller Surface Speed : 75 mm / min to 1500 mm / minDrive : Variable Speed A.C. Motor (A.C. VFD) For Job Diameter : 500 mm � min and 8000 mm � max (The Job diameter varies according to load conditions) Note : Customised Self Centering Rotators May also Be Provided Apart from Our Standards. Technical Specifications Model Capacity (Drive + Idler ) (Tones) Roller Dia. (D) (MM) Roller Width (W) (MM) Roller Material SRT-SCR- 01 1 300 90 POLYUR ETHANE SRT-SCR- 05 5 300 100 SRT-SCR- 10 10 400 100 SRT-SCR- 15 15 400 120 SRT-SCR- 20 20 400 145 SRT-SCR- 30 30 400 200 SRT-SCR- 40 40 500 175 SRT-SCR- 50 50 500 250 SRT-SCR- 60 60 500 250 SRT-SCR- 80 80 550 300 SRT-SCR- 100 100 550 300 SRT-SCR- 150 150 550 350 SRT-SCR- 200 200 600 150STEEL SRT-SCR- 250 250 600 180 SRT-SCR- 300 300 660 200 SRT-SCR- 500 500 660 250.
Self Centering Rotator
Get Price Quote
We hold normally 2000 to 3000 tonnes of steel in our works to ensure on time delivery to clients. The material is confirmed prior to manufacturing with all required Chemical, Physical and ultrasonic tests by our Quality Control department. We hold a strong setup of raw material in various thickness ranging from 5 mm to 250 mm thickness of reputed mill. We also have full fledged facility of CNC profile cutting with modern machines and equipment for better quality.
Best Deals from Self Centering Rotator
Self Centering Rotator
Get Price Quote
The construction of this type is similar to Conventional Type except that this model has a provision to slide the Roller Brackets over the Base Frame equally in both directions through a lead screw having LH & RH Threads. Unlike in Conventional Type the Roller Brackets in Self Centering Type is not bolted on the base frame. The rotation of lead screw can either be Manual or Motorized (Optional). The Technical Specifications are same as Conventional Type. Salient Features Low investment cost. Ideal version to start with new fabrication line. Most suitable for small and heavy fabrication shops. Simple & Sturdy design. Proven reliability. Accepts wide range of Job diameters.
Self Centering Rotators
Get Price Quote
Main base frames are fabricated and stress relieved before maching. There are two Roller Beds, the Drive and Idler unit each. The precisely machined (on boring machine) Roller Brackets are bolted on the roller beds. In this type of machine one of the roller brackets is fixed at one end of the bed and the other is moved to suit the job diameter. Shafts of different lenghts are provided to cover the diameter settings.
Self Centering Rotator
Get Price Quote
