Sequence Timer Dealers in Pune

• Applications: Refinery Industries , Oil and Gas Industries

The unit can provide thyristor output or relay output as per request. ON and OFF timing are set able through front potentiometer. These are widely used in Hydraulic press sequence control, blending and storage coils in cement industry, bag filters, dust collectors type tube chuting press, pot header in rubber industry, machine tools sequence etc.

• Display Type: Digital
• Features: Large Size Displays, Speed Indicator , Batch Counters for Shop floor,

Microcontroller based Bag Filter Timer controls the cleaning cycle of Pulse Jet Bag Filter. This Timer is fully Programmable and has Digital Display to indicate all programming & Operating parameters. It can be used for On-Line as well as Off-Line cleaning. Different application specific models are available to cater Off-Line Cleaning, On-Line Cleaning with Off Line feature, Solenoid Fault detection, Multiple configurable Timers in one unit, Master Controller & Slave timer application, MODBUS PROFIBUS connectivity etc.

IFI's integrated programmable bag filter controller helps you get the best performance out of your Bag Filter.It integrates all important signals associated with a bag filter & produces the most efficient cleaning program. The Inputs & Outputs of the IPBC can be configured as per user requirement.Sequential Operation of Solenoid Valves for Cleaning, Monitors Pressure build up in Air Header, Rotary Air Lock Valve Motion, Differential Pressure Build up across Bag Filter, Functioning of Hopper Level Indicator.

1. Model- ST0210 2. No. of Outputs- Upto 10 , (Selectable from 1 to 10), Higher outputs on request 3. Output types- Potential free contact. 4. Inputs- Start, Stop. 5. Operation- Single Cycle / Continuous Cycle …… (Program selectable) 6. Time settings Range Second, Minute, Hour. (0.01 sec. to 9999Hrs.) --- settable 7. Type of Time settings a) Common ON, Common OFF b) Individual ON, Common OFF c) Individual ON , Individual OFF … (Program selectable) 8. Start condition. Output ON Instant, Output delayed ON 9. Hold Current status hold during power OFF (Program selectable) 10. Display Interface 2 Line LCD, 7 keys keypad for setting. 11. Supply 90-265VAC 12. Size 96x96x110 mm 12. Password Password Protection for Control Parameters.

Digital Programmable Sequential Timer
