Single Phase Relay Dealers in Pune

• Relative Humidity: 10 to 95% RH
• Supply voltage: 230 VAC, 50 Hz (P & N) (No auxiliary supply)
• Output Contacts: Two SPDT (C-NO-NC) Relay, Rating 5A at 230V AC
• Indications: VOLTAGE RELAY ON
• ON Delay: Selectable by Keys From 1 to 60 sec
• Mounting: Din Rail Mounting
• Dimensions: 63(W) X 72(H) X 114(D) mm.
• Trip Time delay: Settable 0- 30 sec

Micro controller based technology. Protection against under voltage, Over voltage. All set points settable by keys. Trip Delay is settable Reverse Phasing Protection can be bypass through settings. Indications Voltage relay, fault relay ON. Message display for Under/Over Voltage. No separate auxiliary supply required.

• Supply Voltage: 3 Phase 415 VAC,50 Hz
• ON Delay: 1 to 60 sec.
• Relative HumidityC: 10% to 95%

Protection of 3 Phase devices against Over voltage, Under voltage,Single Phasing, Reverse Phasing & unbalance supply are one of the major issue in electrical systems. For safe running of 3-phase devices, special protections that keep a continuous watch on supply conditions are very essential. The major cause of maximum load burn-out is overloading which occurs due to unbalance supply, Single Phasing & Reverse Phasing conditions. VMR3P detects such Conditions & protect the load from burn out. PROTON's VMR 3P' offer above protections along with 3 digit display showing R-Y,Y-B,BR voltages in scanning mode with precise accuracy. LOWHIGH voltage tripping to ensure trouble free running of 3-phase Loads.

These relays are useful for protection of 3-phase AC induction motors against various hazards. With their unique advantages they eliminate use of a thermalbimetal relay for motor protection. Being current sensing, they are to be selected according to motor rating and are available for practically all ranges of motors. These relays are ideally suitable for Air-conditioning Compressor motor protection, as also for motors in machines, conveyors, craneshoists and lifts, and for pumps. FEATURES Fixedadjustable unbalance settings Fixedadjustable settings for underover voltage, current, load Fixedadjustable trip delays Resetting Auto or Manual Output contacts : 1 CO or 2 CO Choice of enclosures (DIN-Rail, Flush) Models with Micro-Controller based design Serial Communication (RS485) port 2 line alpha-numeric LCD display Use of SMD Technology User-friendly LED indications

  • Durability.     • Direct control by integrated Circuit.     • Load current up to 125 A.     • Load voltage up to 330/480 VAC.     • Isolation voltage 2500 VAC. (4000V Optional).     • Optimum Strength.     • Zero voltage Turn-on, Zero Current Turn-off.     • Fast switching response.     • Chassis mounting.     • Normal Open type.     • LED Indicator Showing Relay ON status.     • Reliable.     • Weight-Approx 100 g.
