Hydro Power-Tech Engineering Ravki, Rajkot, Gujarat

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Voltage : 220V

Warranty : 1year

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Power : 1-3kw

Voltage : 220V

Warranty : 1year

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Voltage : 220V

Warranty : 1year

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Voltage : 220V

Warranty : 2years

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Voltage : 220V

Warranty : 1year

Salient Features “Programmable logic controls” (PLC) is provided in our Machine of international standard make Delta, offering maximum production flexibility and full compatibility with international standards. Both cylinder are work independent (two worker can work as same time)  Stroke adjust with the help of proximity sensor and light indication glass for easy stroke adjustment,MONOBLOCK Structure and Precise machining of the structural membrane is done to get the required accuracies like parallelism between platen and bed and right angularity. Between bed and the moving platen.  ‘Auto Lubrication System: All moving parts are lubricated from a centralized lubrication arrangement with auto timer, once you fill lubricant no worry for 2-3 months about lubrication.  Auto hold down mechanism which will give fast production rate and it hold material with heavy force and cut material so increase Die life with better cutting quality,  Quick Die – Punch Mechanism:- you can change punch fast and easy,  All die are inter-changeable so one die can use 2 to 4 times, also material and process of die so that it will give longer life without blending edge,  Universal angle cutting mechanism will give possibility to cut wide range of angle size in one die, no die change required for bigger or smaller size of angle.  The low noise hydraulic power pack unit is designed as per international practices and assembled with internationally reputed make components. The presses are designed as per ISI guidelines, hence standard seals, bushes are used.  Machine have Guard at all station, electric switch and rubber pad which provide safety for operator and protect machine again dust and free-falling metal while cutting,  All station of Shearing have common Stroke Counter, it will Count Number of Cut.  Table Design with ‘T’ Slot, Regular die of Power Press can be Use on Ironworker Machine. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   Machine Comes with Standard Functional Accessories: Die Set (total 14 Nos.): A 10 Pair of Punch and Die (select Any 10 Round Punch + Die Set from Dia. 8 Mm to 20mm) A Set of Angle Steel Cutting Blade. A Set of Square and Round Bar (or I Section or C Section) Cutting Blade (any One of Three) A Set of Flat-bar Shearing Blade. A Set of Notching Blade (v- Notch or Square Notch Any One) Die Set is Customizable as per Your Requirement, Please Freely Discuss with Our Company.   Standard Functional Accessories: Automatic Multi Point 24v Dc Motor Operated Lubracting System 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (auto Hold Angle & Flat) Back Gauge Mode (inching, Auto) Both Side E/stop Two Saparat Foot Switch

Brand Name : HPT

Voltage : 220V

Warranty : 1year

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Warranty : 1year

Usage : For Punching

Automation Grade : Automatic

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Voltage : 220V

Warranty : 1year

Usage : For Punching

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Warranty : 1year

Usage : For Punching

Automation Grade : Automatic

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Voltage : 220V

Warranty : 1year

Usage : For Punching

Automation Grade : Automatic

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Voltage : 220V

Driven Type : Hydraulic

Warranty : 1year

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Voltage : 220V

Warranty : 1year

Usage : For Punching

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Warranty : 1year

Usage : For Punching

Automation Grade : Automatic

Machine Comes with Standard Functional Accessories: Die Set : A 10 Pair of Punch and Die, (select Any 10 Round Punch - Die Set from Dia. 8 Mm to 20mm)   Standard Functional Accessories: 3 in 1 Die Holder (50, 73 Die Holder & Angle Punching) Hydraulic Hold-down Mechanism (optional) Mode (inching, Auto) E/stop Foot Switch

Brand Name : HPT

Driven Type : Hydraulic

Voltage : 220V

Warranty : 1year

Usage : For Punching

Automation Grade : Automatic

Product Features Adopt CNC technology, servo motor in feeding, with high efficiency, stable work piece precision. Key hydraulic, pneumatic and electric parts all imported. There are three sets of punch and die on each side which can install three kinds of punches with different diameters. Three sets of moulds can move altogether controlled by PLC to change the punching back mark. Computer with English interface, easy operation, and can display the drawing of work piece. Easy programming and can directly use the program data made by lofting software. Only need to input size of work piece, diameter of holes, back mark and quantity of work piece when edit program. CNC infeed carriage is driven by servo motor. The photoelectric encoder feeds back the information. Closed loop control to ensure high positioning precision. All marking, punching and shearing in automatic completeness, all finished angles can be unloaded by pneumatic turnover device so as to lighten the working strength. The control system consists of the host computer, CNC system, servo motor, PLC, external examination sensors, etc. Just input the dimension of workpiece, the processing will be created. Furthermore, the program can be stored, selected, displayed and communicated as per the workpiece No. Marking unit adopts closed frame with good rigidity. Four groups of character boxes are fixed on the marking unit which can be selected by program. Marking back mark can be set at will. The punching, marking and shearing cylinders are bigger; NC carriage is new type and stronger; the clamps are stronger. The key hydraulic pneumatic and electrical elements are all imported from Germany, Japan, and South Korea etc. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   After sales service After sales service we not only apply ourselves to develop the new products and improve our products’ quality, but also build a quite perfect after sales service network all over the world and supply more convenience and better service for our customers.   We supply the foundation drawing of the machine’s installation but not constructing. We take charge of the machine’s installation and adjustment if you supply the lifting equipment and necessary conditions. Please let us know the list of accessories before the machine leaves the factory. When the machine is finished, we will inform you to inspect the machine in our factory. After your inspection and acceptance, the machine will be dispatched or shipped. During installing the machine, we supply free training and technical consultation service, buyer be in charge of accommodation, flight and daily salary of technician. The final acceptance of the machine is done in you place according to the signed agreement and relative technical files. We guarantee for product’s maintenance, change and return after sales for one year. In this period, we can change the damaged parts for free if not your responsibility (not including easily worm parts). After this period, we can repair the machine for you only taking the basic charge.

Driven Type : Electric

Power : 1-3kw

Warranty : 1year

Usage : Punching Iron Sheet

Automation Grade : Automatic

Product Features Adopt CNC technology, servo motor in feeding, with high efficiency, stable work piece precision. Key hydraulic, pneumatic and electric parts all imported. There are three sets of punch and die on each side which can install three kinds of punches with different diameters. Three sets of moulds can move altogether controlled by PLC to change the punching back mark. Computer with English interface, easy operation, and can display the drawing of work piece. Easy programming and can directly use the program data made by lofting software. Only need to input size of work piece, diameter of holes, back mark and quantity of work piece when edit program. CNC infeed carriage is driven by servo motor. The photoelectric encoder feeds back the information. Closed loop control to ensure high positioning precision. All marking, punching and shearing in automatic completeness, all finished angles can be unloaded by pneumatic turnover device so as to lighten the working strength. The control system consists of the host computer, CNC system, servo motor, PLC, external examination sensors, etc. Just input the dimension of workpiece, the processing will be created. Furthermore, the program can be stored, selected, displayed and communicated as per the workpiece No. Marking unit adopts closed frame with good rigidity. Four groups of character boxes are fixed on the marking unit which can be selected by program. Marking back mark can be set at will. The punching, marking and shearing cylinders are bigger; NC carriage is new type and stronger; the clamps are stronger. The key hydraulic pneumatic and electrical elements are all imported from Germany, Japan, and South Korea etc. Machine comes with all Standard accessories spanner set, warranty Card, instructional and maintenance manual.   After sales service After sales service we not only apply ourselves to develop the new products and improve our products’ quality, but also build a quite perfect after sales service network all over the world and supply more convenience and better service for our customers.   We supply the foundation drawing of the machine’s installation but not constructing. We take charge of the machine’s installation and adjustment if you supply the lifting equipment and necessary conditions. Please let us know the list of accessories before the machine leaves the factory. When the machine is finished, we will inform you to inspect the machine in our factory. After your inspection and acceptance, the machine will be dispatched or shipped. During installing the machine, we supply free training and technical consultation service, buyer be in charge of accommodation, flight and daily salary of technician. The final acceptance of the machine is done in you place according to the signed agreement and relative technical files. We guarantee for product’s maintenance, change and return after sales for one year. In this period, we can change the damaged parts for free if not your responsibility (not including easily worm parts). After this period, we can repair the machine for you only taking the basic charge.

Voltage : 220V

Warranty : 1year

Usage : Punching Iron Sheet
