Screw Capping Machine Dealers in GIDC, Rajkot

• Bottle Size :: Diameter Up to 85mm* or other Shape bottle with proper base
• Bottle Height :: 300mm* Maximum
• Cap Size :: Upto 32mm*
• Electrical :: 415VAC 3Phase and 220 VAC Single Phase Power Supply (50 Hz) with A.C. Drive
• Power :: 3.0 H.P.
• Conveyor Height :: 850-900 mm
• Overall Dimensions :: 2200 mm (L) x 1250 mm (W) x 2000 mm (H)
• Speed :: Max. 200 Bottles per minute depending on Bottle and Cap Size

 CAPSEAL-200SR - Automatic Ten Head Bottle Screw Capping Machine The Automatic Ten Head Rotary Bottle Screw Capping Machine Model CAPSEAL-200SR for Plastic Screw Cap. Machine is suitable for Round or other shape of Glass/Plastic/PET/HDPE or LDPE Bottles with maximum speed of 200 Bottles per minute depending on Bottle Diameter, Bottle Height, Bottle Shape and Cap Size. Specially Machine construction in Stainless Steel finish including machine M.S. frame structure with Stainless Steel Cladding/Enclosures. The Capping Machine is ideal for application in Pharmaceutical, Food, Pesticides, Cosmetic & Other Industries. The Machine is equipped with Orientations type Cap Feeder or Vibratory type Bowl Feeder depending on cap shape and size for continues feeding of Cap for online operation on any liquid of powder filling line. Machine suitable for various sizes of Bottles and ROPP Cap with the help of change parts. Capping Machine is suitable for application in Pharmaceutical and other industries requiring higher production speed on automatic online operation.   SPECIAL/OPTIONAL* FEATURES :     No Bottle - No Cap System No Cap - Machine Stop System Machine construction in Stainless Steel Finish Infeed and Exit Star Wheel with Overload Clutch System to avoid Bottle breakage Single Drive Synchronizing Total Operation of Star Wheel and Turret with Star Wheel Cap Feeder with Variable Speed System for feeding control of caps. Minimum Change Over and Setting time Hopper can be completely dismantle for easy cleaning  Various safety features including Clutch system to avoid Bottle Breakage Single Drive synchronizing operation of Conveyor and Star Wheel Minimum Change over time

Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine. Operation : The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.     Salient Features :     No container no cap arrangement. Single motor synchronizes conveyor, star wheel & platform turret. Adjustable height of conveyor belt. All contact parts are made out of stainless steel. Pick & Place arrangement. Torque adjustable. Low noise level, low power consumptions. No cap, No container arrangement. Motorized Height Adjustments. Acrylic cabinet. Safety Guard for Operation and Protection. Specially designed hopper is to increase storage capacity of bowl.

• Electrical Supply: Three Phase + Neutral + Earthing
• Electrical Load: 1.5 KW
• Air Pressure: Minimum : 6 Bar, 0.5 CFM.

Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine. Operation : The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.   Salient Features : No container no cap arrangement. Single motor synchronizes conveyor, star wheel & platform turret. Adjustable height of conveyor belt. Pick & Place arrangement. Torque adjustable. Low noise level, low power consumptions. No cap, No container arrangement. Motorized Height Adjustments. Acrylic cabinet. Safety Guard for Operation and Protection. Specially designed hopper is to increase storage capacity of bowl.

• Net Weight: 350 Kg Approx.
• Model: HMPL-RBS
• Product Size: 10 ml to 500 ml Bottles
• Cap Size): 22 & 25 mm / 25 & 28 mm
• Cap Feeding System: Vibratory Bowl with chute Suitable Cap
• Capping Head Type: ROPP / SCREW Cap
• Output Speed: 30 to 120 Bottles/Minute
• Direction of Movement: Left to Right
• No. of Sealing Head: 1 / 4 / 6 / 8 Nos.
• Power Supply: Three Phase / 440 V AC / 50 Hz
• Height of Conveyor: 850±50 mm Adjustable
• Dimensions: 2440 mm (L) x 850 mm (W) x 1900 mm (H) Approx.
• Change Parts Required: (A) Bottle: Star Wheel, Center guide.

Screw Capping Machine, automatic bottle liquid filling machine
