Swivel Screw Jack
We are offering swivel screw jack: a swivel screw jack is used as a starting base, the swivel base plate allows to compensate for uneven terrains. It is equipped with a die forged screw-nut used to adjust the height so that a leveled scaffold structure can be built. Features: - base plate measuring 150x150mm allows for the tubular bolt to swivel as needed. - Equipped with die forged nut with socket for the frame pipe installation. - Surface finish: hot dipped galvanised - product can also be made per customer specified sizes - scaffolding screw jack can be in solid screw thread and hollow screw thread in outer diameter of 28mm to 48mm according to different construction scaffolding system and concrete formwork requirements.
...more
stillage
We are offering stillage that is used to contain parts of scaffolding. These are available according to customer specified sizes andor colors
...more
Steel Walkboard with Mesh
We are offering walk boards planks are use for support scaffolding, these colours are available according to customer needs.
...more
Steel Walkboard with Lip
We are offering walk boards planks are use for support scaffolding, these colours are available according to customer needs.
...more
Steel Walkboard with Hook
We are offering walk boards planks are use for support scaffolding, these colours are available according to customer needs.
...more
steel plank
We are offering steel plank, walk boards planks are use for support scaffolding, these colours are available according to customer needs.
...more
Staircase (Steel)
We are offering staircase that is compatible for all types of scaffolding systems (Ringlock, Cuplock, Kwik Stage, Tube and Clamp etc). These can be made per customer specified bay length and height. Comes with Hot Dip Galvanized surface finish or in Paint finish in various colors.
...more
Screw Jack without base plate
We are offering screw jack without base plate (universal screw jack): a screw jack, aka universal jack, provides a method of jacking which can be used at either the top or bottom of a scaffold structure. Features: - This screw jack can also be use with casters or up side down on top of a frame, in conjunction with Forkheads, Socket Base and Drophead Adaptors, for shoring purposes. - Equipped with die forged nut with socket for the frame pipe installation. - Surface Finish: Hot Dipped Galvanised - Product can also be made per customer specified sizes - Scaffolding Screw Jack can be in Solid Screw Thread and Hollow Screw Thread in outer diameter of 28mm to 48mm according to different construction scaffolding system and concrete formwork requirements.
...more
Screw Jack with U Head
We are offering screw jack with u head: screw jack with u head works as a traditional screw jack, with the u-head provides a platform to rest the beams. Features: equipped with die forged nut with socket for the frame pipe installation, and a u head is welded at one end surface finish: hot dipped galvanised product can also be made per customer specified sizes scaffolding screw jack can be in solid screw thread and hollow screw thread in outer diameter of 28mm to 48mm according to different construction scaffolding system and concrete formwork requirements.
...more
Screw Jack with base plate
We are offering screw jack with base plate: a screw jack is used as a starting base for a scaffold structure. It is equipped with a die forged screw-nut used to adjust the height to allow for compensation of uneven floor so that a levelled scaffold structure can be built. Features: base plate measures 150x150mm. Equipped with die forged nut with socket for the frame pipe installation. Surface finish: hot dipped galvanised product can also be made per customer specified sizes scaffolding screw jack can be in solid screw thread and hollow screw thread in outer diameter of 28mm to 48mm according to different construction scaffolding system and concrete formwork requirements.
...more
Ringlock Scaffold Standard
We offer ringlock scaffold standard. Ringlock scaffold standard (verticals) are the vertical members that provide the vertical support for the scaffolding structure. features: these are made of high strength steel pipes per the following standards: en-10219, bs1139, a513, is1161 etc. 48.3mm outer dia and 3.2mm thickness steel pipes duly welded rosette rings at every 500mm intervals with welded spigot pin at one end. Surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc product can also be made per customer specified sizes
...more
Ringlock Ledger
We offer ringlock ledger . Ledgers are the horizontal members that connects to the small holes in the rosettes on the standard vertical members of the ringlock scaffolding. The wedge locking systems provides a frictional connection that assures even distribution of load between vertical and horizontal members. features: ledgers horizontals typically provide the support for decks. Can also be used as mid and top support rails for the hand safety guard rail system. Duly welded cast ends with wedges these are made of high strength steel pipes per the following standards: en-10219, bs1139, a513, is1161 etc. 48.3mm outer dia and 3.2mm thickness surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc product can also be made per customer specified sizes
...more
Ringlock Cross Brace
Ringlock Cross Brace (Diagonals) Cross Braces are the diagonal members of the Ringlock Scaffolding system. The wedge at the end connectors swivel at each end, allowing them to connect into rosettes of the standards diagonally. The wedges, in the end connectors are hammered to secure them on to the larger holes of the the rosettes of the Standards Vertical members. Features : These can also be used as the obtuse angle mid rail and top rail in the hand guard rail system within the scaffold staircase tower. Duly riveted cast ends with Cross Braces are used for the lateral bracing that provides rigidity and safety the scaffold structure. wedges These are made of High Strength Steel pipes per the following standards: EN-10219, BS1139, A513, IS1161 etc. 48.3mm Outer Dia and 3.2mm Thickness Surface Finish: Hot Dipped Galvanised or optional Paint Finish in Blue, Red, Yellow, Black, Silver, Orange, etc. Product can also be made per customer specified size.
...more
Ringlock Caster Adapter
Ringlock Scaffolding Accessories is used to manage Scaffolding according to user requirements.
Color : Black
...more
Ringlock Board Brackets
Ringlock Board Brackets: Ringlock board brackets are used at an edge of the scaffolding structure to extend the working space. Features: Ringlock board bracket has cast ledger end with wedge that is attached to the rosette of the vertical and scaffold boards are placed on it to build a working platform. Horizontals & Verticals are used appropriately to build a safety guard rail system. Surface Finish: Hot Dipped Galvanised or optional Paint Finish in Blue, Red, Yellow, Black, Silver, Orange, etc Product can also be made per customer specified sizes
...more
Ringlock Base Collar
Ringlock Base Collar: Ringlock Base Collar or ‘Starter Collar’ is placed on top of a base jack and is designed to ‘base out’ the Ringlock scaffold structure, creating a lower node point for the scaffold structure. Features: The Ringlock Base Collar has a single rosette welded to it. 2 pipes of different diameters are welded together. The lower pipe is selected so as to place it on the base rod and upper pipe is selected to accommodate the Ringlock Vertical. Base collar is setup in conjunction with a Screw Jack as a starting base for a scaffold. Screw Jack has an adjustable height which allows for compensation on uneven surfaces so that a levelled scaffold structure is always attainable. These are made of High Strength Steel pipes per the following standards: EN-10219, BS1139, A513, IS1161 etc. Surface Finish: Hot Dipped Galvanised or optional Paint Finish in Blue, Red, Yellow, Black, Silver, Orange, etc Product can also be made per customer specified sizes
...more
Pallet (Steel)
We are offering pallet (steel) are use for contains scaffolding parts, these colours are available according to customer needs.
...more
light duty props
We are offering light duty props made of inner pipe of 40mm dia and 1.8mm thickness and outer tube of 48mm dia and 1.8mm thickness features: surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc product can also be made per customer specified sizes.
...more
Steel Ladder
We are offering steel ladder are use for support scaffolding, these colours are available according to customer needs.
...more
Ladder Bracket
We are offering ladder bracket. Ladder bracket are use for support ladder scaffolding, these colours are available according to customer needs.
Color : Black
...more
Intermediate Transom
We are offering intermediate transom. Intermediate transom is used when the distance between the standards is more than the length of the walk boards. Feartures: they rest upon the ledgers to reduce the span and provide extra support to the walk boards. These are made of high strength steel pipes of 48.3mm outer dia and 3.2mm thickness. We provide intermediate transoms in various lengths that suits your job site requirements. Surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc product can also be made per customer specified sizes.
...more
Inside Board Transom
We are offering inside board transom. Inside board transoms are used with board brackets to support the work space that is extended out of the ledger with the help of board brackets. Features: similar to the intermediate transom, they rest upon the ledgers to reduce the span and provide extra support to the walk boards. The extended portion extends beyond the inside ledger to prove support for up to three inside boards. these are made of high strength steel pipes of 48.3mm outer dia and 3.2mm thickness. We provide intermediate transoms in various lengths that suits your job site requirements. Surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc size is measured per the length of the transom. All sizes comes in variations of 1, 2 or 3 boards. Product can also be made per customer specified size
...more
heavy duty props
We are offering heavy duty props: made of inner pipe of 48.3mm dia and 3.2 mm thickness & outer pipe of 60mm dia and 2.8mm thickness features: surface finish: hot dipped galvanised or optional paint finish in blue, red, yellow, black, silver, orange, etc product can also be made per customer specified sizes.
...more
Drop Forged Swivel Coupler
We are offering drop forged swivel coupler: the swivel coupler is essential to connect two scaffolds at any angle used for ledger, facade or face bracing. These are important structural components and must be load-bearing to resist both slip and distortion. Features: drop forged fitting gives the maximum support to the connection. We offer alternate models that compliment the double couplers. Surface finish: hot dipped galvanised product can also be made per customer specified sizes
...more
