Pressure Gauges Dealers in Chow Mandi, Roorkee

• Material: Metal & Plastic
• Shape: Round
• Color: Green
• Application: Laboratory
• Size: Standard
• Country of Origin: India
• Least Count: 0.5 mm

Self-recording rain gauge (SRRG) is an automatic device used to record a continuous rainfall for 24 hrs on a daily chart, if rain occurs.The characteristics of rainfall events viz. onset and cessation of rainfall, duration of rainfall, intensity of rainfall and the total amount of rainfall in mm can be obtained from the rainfall chart.DETAILS OF EQUIPMENT It is a float type rain recorder in which the rain is led into a float chamber containing a light, hollow float. The rain gauge is installed on a level ground and fixed on a masonry foundation of 60 × 60 × 60 cm3 sunk into ground. Base of the gauge is cemented into the foundation so that the rim of the gauge is exactly 75 cm above the case of self-recording rain gauge. If the height of the rim were more, the rainwater collected would decrease because of the change in wind speed near the ground. Rainwater is entering the receiver through an 8-inch diameter funnel. The receiver is consisting of float and siphon chamber. MEASURING PROCEDURE A pen is mounted on the stem of the float and as the level of water rises in the receiver, the float rises and the pen records on a chart placed on a rotating drum with clockwork arrangement, the amount of water in a receiver continuously. The clock work drum revolves once in 24 hrs. Siphoning starts automatically when the pen reaches the maximum point of the chart. If the rain continues, the pen rises again from the zero line on the chart. If there is no rain, the pen traces the horizontal line from where the rain stopped

• Size: Standard
• Type: Self Recording
• Material: Mild Steel, Stainless Steel
• Diameter: 20-40mm
• Shape: Round
• Application: Liquid Pressure Measuring

Elegantly designed and flawlessly manufactured, our Self Recording Rain Gauges are high in demand among the global buyers. We are acknowledged as a trustworthy Manufacturer, Exporter and Supplier of Self Recording Rain Gauges in Uttarakhand, India. Our Self Recording Rain Gauges are primarily used to give continuous record of rainfall. One can get them at moderate prices, from us.   Features : High accuracy. Elegantly designed. Tropicalized Specification :  Rain Gauge Recording Type - this natural siphon type recording rain gauge is designed to give continuous record of rain fall. It is generally used in conjunction with an ordinary rain gauge ( non recording type ) exposed close by. Rainwater enters the gauge at the top of the cover and is carried through the funnel to float chamber provided with a float. The recording pen is mounted on the stem of the float. As the water level rises in the receiver, the float rises and the pen records rain on a chart placed on a clock drum which revolves once in 24 hours. The recording mechanism is mounted on the base and the base cover is provided with a gunmetal rim of about 203 mm. Dia. The funnel lifts of the base and carries a hasp, which is engaged with a staple on the base and pad locked. An angle iron piece with foundation bolt is provided for anchoring the rain gauge base to the ground. The dimensions of the base, collector, funnel, float chamber float chamber, float etc. are as per ISI specification and also as per IMD specification. The unit is supplied with 100 graph paper sheet, a phial of special recording ink, recording pen, filter, clock movement with drum and key, float chamber with float, foundation angle iron and literature booklet. Details : Spare Rain Gauge Charts: per packet of 100 chart sheets. Spare Recording Ink: phial containing about 20 ml. of the special type of ink.

• Feature: Durable
• Condition: New
• Power: 6-9 kw
• Voltage: 220 V
• Capacity: 200 sq.cms
• Use: Industrial
• Frequency: 20 Hz

Used for measuring of rainfall manufactured from non-corrosive Fiber Glass Reinforced Plastic container. It consists of collector assembled with gun Metal Ring, Funnel, Locking Ring & Base. The Rain gauge supplied with 4 lit plastic bottle & measuring cylinder Rain gauge are available in capacity of 200 sq.cms collected area.
