Control Panels Dealers in Sangli

For the convenience of the clients, we have adopted both online and offline payment modes of transaction. In addition to this, we guarantee transparency and confidentiality in both. Keeping the stern check on packaging procedures, we ensure that the products are packed using the finest packaging material, followed by a stringent check of the whole batch by the professionals. Features : Advanced technology Energy efficient Long life

• Size: Multisizes
• Type: Electric Control Panels
• Application: Boiler Control
• Color: Brown, Grey
• Voltage: 110V, 220V
• Body Material: ABS
• Power: 1-3kw, 3-6kw
• Power Source: Battery
• Phase: Double Phase, Single Phase
• Warrenty: 1 Year
• Autoamatic Grade: Automatic, Fully Automatic, Manual

power control centers (pcc) up to 10,000 a. motor control centers (mcc), distribution panels. automatic power factor controller (apfc) and capacitor controlpanels. auto mains failure (amf) panels. bus ducts up to 15,000a. bigger starters for slip ring and auto transformer starters, soft start starters. plc , dcs, based systems and process control panels. d.g.set canopy, compressor control panels for winery and chilling plants. fire protection panels, control desks, and custom built panels. transformer and capacitor testing panels for these products manufacturing units. automatic cooling systems for 400 kva, ht – transformers in mseb switch yards. all types of out-door - feeder pillers - mcc, pccthe panels, that are mainly used to control the powers are called pcc panels. The sizes of the panels depends upon the amount of current it handles. Almost all types of industries requires these types of the panels.the range is right from 16 a to 10,000 a, there is one incomer of proper capacity and many out goings feeders for these panel.the switchgears may be air circuit breakers ( acb ) or molded case circuit breaker ( mccb ) or switch disconnector fuse unit (sdf). the bus bars may be of electrolytic grade copper strips or aluminum strips. Generally in india aluminum strips are mostly used as the cost is somewhat cheaper than copper. panel-h panel-a: main panel for sahyadri agro and dairy ltd. Baramati,1000 a, acb mseb,incomer,630 a, d.g.set incomer, with mccb type auto change over. panel-b: main panel for satish sugars, hunshyal p.g.( gokak ),3200a,incomer and 3200 a, bus coupler, 630 a, sdf out-going. panel-c: main panel for schriber dynamix dairy ltd. Baramati (pune ), 4000a, fp,mseb incomer , 3200 a, fp,bus coupler,2500a,fp.out-going with mechanical as well as electrical. panel-d: main panel for tulasi castings – midc kupwad. panel-e: main panel for sanjiy ghodavat institute atigre(kolhapur) 800a,legrand make acb and 800 a, hpl make ats with legrand make mccb. panel-f: main panel for warna dairy barshi unit, maim incomer – 800 a, change over switch and 800 a, acb, outgoing – 200a, 630 a, 400a, 125 a, mccb. panel-g: multi party mseb ,pcc panel with one incomer and different out going with separate mseb energy meters. panel-h: a pcc panel fitted at ghodawat farm house, at majale dist kolhapur. The panel was made squire c shaped .two mseb, four d.g.set incomer powers with apfc capacitor panels.

We, being a quality centric company, offer product range that is strictly as per the globally accepted norms. We are acknowledged for providing safe transaction modes for the payments which include online as well as offline method. Thus, we accept cash payments along with bank transfers.

• Type: Automatic
• Voltage: 380V
• Body Material: ABS, Mild Steel
• Power: 3-6kw
• Power Source: Electric
• Phase: Double Phase, Single Phase
• Warranty: 1 Year

The Industrial Control Panels, provided by us, are reckoned due to their long lasting service life. You can choose to make payment through offline and online mediums as per your convenience. We are well versed with all and we ensure that the transaction is transparent. We are reckoned for the quality that we offer in our products. And, for maintaining it, we make use of the world-class raw material for manufacturing the products.

We are offering automatic power factor controller. Certain elctricals loads such as motors found in heavy machinneries ,can cause the electrical system to be highly inductive. This result in poor power factor . Poor power factor means higher energy losses which ultimately get converted into large electricity chrges. A simple solution to this problem is to balance this inductive load with equivalent capacitive load . Tis is achieved by connecting or disconnecting the capacitors to or from the system. Manual switching of these capacitors is not possible in case of rapidly fluctuating loads . So even in an environment of rapidly fluctuating loads to achieve the required power factor one may need an automatic power factor control device, called automatic power factor controller, to connect and disconnect these capacitors. Sycon 66 xx e3 controller is an automatic power factor controller used to control the power factor of the system . It can sense the powre factor of each individual phase in the three phase system and can switch the capacitors according to the requirement.

• Type: Control Panel
• Power: Electric
• Packaging Details: As per Client Requirement
• MOQ: As per Client Requirement

We make available a huge product basket that our quality auditors check closely to maintain the set standards. With the aid of modern packaging system and deft professionals, we can guarantee safe and secure deliveries of products. Also, we make sure that the material used for wrapping them is of premium quality.

• Type: Electrical Control Panel Board
• Voltage: 110V, 220V, 440V
• Body Material: Mild Steel
• Power Source: Electric
• Phase: Single Phase, Three Phase
• Warrenty: 1 Year, 2 Years
• Autoamatic Grade: Automatic, Fully Automatic, Manual, Semi Automatic
• Brand Name: BFPL
• Surface Treatment: 7Tank Pre Treatment + Powder Coating

low voltage electrical switchboards & control panel.

• Brand Name: PE VTECH
• Body Material: Mild Steel, PVC
• Color: White
• Power Source: Electric
• Application: Boiler Control, Industry
• Size: One Size
• Standard: Good
• Autoamatic Grade: Automatic, Fully Automatic
• Type: Single Phase Control Panel
• Country of Origin: India
• Warrenty: A per Condition

Features : Time Delay Autostart Automatic Controlling Of Both Tank Trusted Single Phasing & Dryrun Protection Attractive Model

• Parameter: :
• Rating: Mains Supply
• :: Up to 480V AC 3 Phase, 50Hz
• Output: :
• Up to 435V AC 3 Phase, 50Hz: Capacity
• :: 20Amp (Max)

Three Phase Voltage Correction/Protection Unit   High voltage trip feature protects your machine from high input voltages. This unit will make your machine work/run at High input voltage up to 270V. And if input voltage goes above 270V then High Voltage trip circuitry will turn off the output and protect your machine from high voltage. If you connect your welding machine directly to input without this protector, the high input voltage will damage your machine. Power ON time delays of 10sec suppresses high voltage transients and power surges for safety of your machine. Voltmeter for output voltage indication. Indication for Input supply. Indication for Power ON Time Delay. Indication for High Voltage Trip. It makes user easy to carry or move welding machine with protector to any place.

We are offering automatic power factor controller. Display four segment bright led display led indication for lag or lead p.f. General features intelligent kvar based switching friendly user interface easy to install large 4-digit 7-segment display available in 4,6,8,12,16 stages power factor led indication of capacitor onoff status selectable: kva kw kvar shortfall or excess kvar settings control features site settable: target pf ct ratio capacitor disconnection in case of: low current over voltage auto identification or manual feeding of capacitor values test mode facility electrical specifications voltage input 415v ac +- 15% current input -- 5 a -- 1 a (optional) frequency 50 hz over voltage release 470 v ac -1% low current 1% (50ma) switching contact 10a at 250v ac accuracy 1 digit switching time 5 sec mechanical specifications dimensions 144 (l) x 144 (w) x 80(d) mm panel cutout 138 mm x 138 mm weight 1.5 kg.

Gennext make ATS controller is designed to monitor Mains supply under voltage, over voltage, single phasing and reverse phasing and provides auto start signal to AMF controller on Mains disproportion.   FEATURES ATS controller is used to transfer the load from mains to DG and From DG to Mains very smoothly. It senses 3 phase Mains and DG supply. It reduces LVM, Timers and hence reduces the panel wiring It gives the protection for mains like UV/OV/SPP/RP and unbalance voltage. Settable power on delay, Trip delay, Load transfer delay and cool down delay. It shows Mains Phase and Line voltage readings LED indication for Mains ON, DG ON, Load ON Mains, Load ON DG Autostart input for DG mounted Amf controller. Site voltage calibration possible. Size: 96×96×85mm Cutout size:92×92

In Most Of The Industries, Due To The Fluctuating Load Conditions, The Power Factor Also Varies Accordingly. Hence It Is Practically Difficult To Maintain A Penalty Free Power Factor With Fixed Compensation Of Capacitors. This Results In Low Power Factor And Leads To Higher Kva Demand And P.F. Penalties. Due To Variable Load Conditions And Cumbersome Manual Switching Of Capacitors The Power Factor Can Not Be Maintained At Desired Levels. As Close Monitoring Of Power Factor Is Required All The Time To Avoid Penalties And To Minimize The KVA Demand, Automatic Power Factor Correction Panels Are The Best Solutions. The Panel Are Manufactured Using Micro Controller Based Control Relay To Control The Capacitor Switching. All The Settings Are Done By Finger Tip Key Pad With Options To Select “FIFO” Of “CYCLIC” Order And Many More. The Panels Are Made Based On Study Of Your Load And Perfect Tuning Is Possible To The Requirement Of Your System. ADVANTAGES • Avoids Power Factor Penalties. • Reduces KVA Demand • Avoids Leading Power Factor. • Avoids Over Excitation Of Generators. • Minimizes Line Losses. • Minimizes Transformer Losses. • Protects Motors, Switchgears From • Improves Voltage Conditions.

We offer the widest range of Electrical Control Panels which are of optimum quality. Our industrial electrical control panels are highly demanded in auto industry, process industry etc for Automation Purpose. They are manufactured under the best manufacturing conditions and using the best quality equipments / BOI. Our electric control panels are highly durable and resistant to tough conditions. These panels are available with various specifications for the effective usage of them. We also provide these panels at the most affordable prices possible. Because of our high quality, we have become one of the well known suppliers of electric control panels for Automation Purpose.

Automatic Power Factor Control Panel controls power factor up to unity. Automatic Power Factor Control Panel helps achieve and maintain unity power factor and gain incentives on electrical bills as much as 7%. Typical application of Automatic Power Factor Control Panel is seen in Dairy Plants, Colleges, Hotels, Bazzars, Shopping Malls, Resorts, Sugar Industries, and Spinning Mills etc. Benefits of Automatic Power Factor Control Panel Reduce electricity bills Control maximum demand Maintain good power factor up to unity Avoid penalty and gain maximum 7% incentives on electrical bills Control reactive power

Model No.Name UC 7014/1 Anolog Meter panel ( A / V meter & Indicator) Without wire UC 7014/2 Anolog Meter panel ( A / V meter & Indicator) With wire UC 7014/3 Digital meter panel ( Voltage & amps.) UC 7014/4 Digital meter panel With Indicator ( Voltage & amps.)RelayVolt meter / Amp meter ( Round )CoilStarter Kit

• Material: MS
• Application: For Submersible Pump Controller
• Phase: Single Phase
• Voltage Rating: 220/240 V
• Automation Grade: Automatic
• Motor Power: 2 HP
• Brand: Super
• Rated Current: 2000 Amp

Certain electrical loads such as motors can cause electrical systems to be very inductive, which results in very 'lagging power factor' i.e. wastage of energy. The simple solution to maintain the power factor in required range is to connect or disconnect the power factor correction capacitors. Manual switching is just impossible for rapidly fluctuating loads and hence an automatic control system is required which continuously monitors the power factor and make appropriate corrections to maintain it within the required range Power Factor Controller Range With a very wide spectrum of features and prices, we have a wide range of automatic power factor controllers. This includes very high range models such as SYCON 66SS with a Smart Switching Algorithm implemented for fast power factor achievement as well as low cost models based on most common FIFO switching algorithm.

For optimum utilization of available power the reactive power consumption should be reduced or nullified i.e. power factor should be unity, hence, most of the Power Distribution companies have policy to penalize the industrial and commercial consumers for not maintaining power factor above certain limit (generally above 0.90 value). However, due to reactive power drawn by capacitive or inductive load in the consumer premises the power factor is either lagging or leading, thus to maintain it within limit i.e. for compensating or supplying required KVAR, the capacitors (in case of lagging PF) or reactors ( in case of leading PF) are connected across the system. For stable load the fixed KVAR compensation is required , while for variable load the KVAR requirement also changes as per the load duration cycle, thus in such case the Automatic Power Factor control Panel is installedElectric Power quality is a term that has captured increasing attention in power engineering in the fresh years. The power quality is mainly depends on the needs of the equipment that is being supplied. Usually the term it refers for maintaining a sinusoidal waveform of bus voltages at rated voltage and frequency. The waveform of electric power at generation stage is purely sinusoidal and free from any distortion. All the Power conversion and ingesting equipment are also designed to function under pure sinusoidal voltage waveforms. However, lots of devices that distorted the supply waveform. These distortions may spread all over the electrical network. In fresh years, there has been an increased use of non-linear loads, which has resulted in an increased fraction of non-sinusoidal currents and voltages in Electric Network. Classification of power quality areas may be made according to the source of the problem such as converters, magnetic circuit non linearity, arc furnace or by the wave shape of the signal such as harmonics, flicker or by the radio frequency interference.     High and Low Voltage Capacitor Panel Application : For Improving Lagging Power Factor of peak loads Systems   Specification : • Multistage controller• Auto/manual controller• P.F. Closer to unity/Targeted• Thyristor/Contractor Switched• Zero voltage switching as per controller• Suitable for variable load.

We are offering control panel. This consists of mainly the star delta starter for motor, & its safety elements. The control unit circuit contains the switches & relays for proximity switch functioning & signaling. The digital temp.control system for controlling the oil temperature & its safety features as per international standards.
