Hardness Testing Machine Dealers in Sangli

• Test Loads: 500,750,1000 & 3000 kgf
• Max test height: 380 mm (approx)
• Depth of throat: 200 mm
• Size of base: 380 x 740 mm (approx)
• Machine height: 1230 mm (approx)
• Drive Motor: 0.33 HP
• Power supply: AC (for machine) & 1 Phase 200-220 V, 50Hz, AC (for computer), 3 Phase 400-440 V
• Weight of the machine: 425 kg (approx)

We manufacturer of material testing lab such as vicker hardness testing machine and supplying to all over india.

‘fine spavy associates & engineers pvt. ltd.’, is a well known vickers cum brinell hardness testing machine manufacturers and suppliers based in miraj, maharashtra. we offer premium quality vickers cum brinell hardness testing machines that are widely preferred to precisely measure vickers / brinell hardness of metals from soft to very soft levels. these premium quality machines have cemented our position among the well reputed vickers cum brinell hardness testing machine manufacturers and suppliers. praised for :- push button control for load selectioncomputerized model is availablesuitable for finding out vickers / brinell hardness of metals specifications :- test loads for vickers / brinell - from 1 kg to 250 kgoptical magnifications - 35x, 70x & 140xdiamond indentor - 136° pyramidmaximum test height x throat: 250 x 150 mmload accuracy well within ± 1%machine conforms to is:1754

We offer Micro Vickers Hardness Testing Machines. MICRO VICKERS HARDNESS TESTING MACHINES ( Model : FMV-1 ) • Suitable for finish components like thin sheets, fine wires, etc. Watch parts like springs, pivot bearings, gears, cutting edge of Razor blades, drills, file teeth, etc. Metallic foils, surgical needles, pen points & so on. • To determine hardness on - surface coatings (like electroplating, etc.), extremely thin case hardened parts, anodized castings of alluminium, shot blasted or rolled faces, etc. • A range of test loads can be used to suit particular application. Test loads from 10 grams to 1000 grams. • Magnifications - 125X, 250X & 625X available. • X-Y stage is provided with least count of 0.01mm, which can move the job as per the requirements. • A precision Diamond Indentor (136° pyramid) is used to make sharp indentations on the specimens samples. • Maximum Test height x Throat : 115 x 70 mm. • Load accuracy well within ± 1% of nominal load value. Machine conforms to IS:1754. • Computerized model is available .Computerized model has built in CCD and suitable advanced software. Hardness will be displayed on computer monitor automatically. Results printout can be taken. • Extra (Optional) accessories like – Knoop Indentor, Knoop test block, Precision vice, Thin specimen holding device, V-shape anvil, Vertical & Horizontal fine specimen holding device, Rotary table, etc. Are available

 Rockwell Hardness Testing Machines is designed for measuring hardness of metals & alloys of all kinds, hard or soft, whether   round, flat or irregular in shapes.• Rockwell Hardness Testing Machines is ideally suitable for laboratories, tool rooms, Heat treatment shops, R&D departments,   inspection departments, foundries & educational    institutions.• Automatic weight selection with automatic zero setting dial gauge.• Rockwell test minor load is 10 kgf & major loads are  60,100,150 kgf.• Rockwell hardness scales such as HRA, HRB, HRC, etc. is obtained by using different types of indentors ( Diamond / Ball ).• Test height x Throat is – 215 x 132 mm• Extra test height & throat of  295 x 148 mm, Model : MRS-150 is also available.• Motorized versions are also available.• Machines strictly conforms to IS:1586- 2000.
