Shearing Machine Dealers in Surat

• Type: Shearing Machine
• Certification: CE Certified
• Weight: 100-1000kg
• Color: Multi Colour
• Voltage: 220V
• Rated Power: 1-3kw, 3-6kw, 6-9kw, 9-12kw
• Automatic Grade: Semi Automatic
• Driven Type: Hydraulic
• Warranty: 2years

The company has emerged as a major Manufacturer and Supplier of Hydraulic Shearing Machines in Surat. The Hydraulic Shearing Machines, offered by the company, are known for their quality as well as high durability. The company offers various accessories with the Hydraulic Shearing Machines and the delivery is always on time. Standard Accessories Main Drive Motor Electric Control Panel Operational Consol Rake angle selection through selector switch Lever operated Blade clearance with calibration Fine stroke adjustment rod with limit switch Front sheet support Squaring arm with steel rule Hardened Transfer bars mounted on table Hold down cylinders Cutting area illuminated for clear view of blades Four edge HCHCR Blade suitable to MS & SS Manual Back Gauge Optional Accessories Motorized back gauge with DRO Second squaring arm on other side Front support with roller according to required length Rear Sheet support Timer belt drive for back gauge Ball Transfer Table Degree protector for angular cutting Stroke counter Design with throat depth First fill of Hydraulic oil Four edge HCHCR Blade suitable to MS & SS   Specifications Model Cutting Length (in mm) Shearing Capacity Thickness (in mm) Nominal Rake Angel (in degree) Rake Angle range (in degree) Rake Angle Stroke per min No. of Hold downs Holding Force Power (in kg.) Packing (in HP) Dimension (LXWxH) M.S. S.S Min. Max. in mm HVR 320 2000 3.15 4 2 3.15 1 15' 0.5-3 20 11 11 2000 3 3100X1850x1950 HVR 325 2500 3.15 4 2 3.15 1 15' 0.5-3 25 13 13 2300 5 3200x1850x1950 HVR 330 3000 3.15 4 2 3.15 1 15' 0.5-3 21 9 16 2600 5 3700x1850x1950 HVR 340 4000 3.15 4 2 3.15 1 15' 0.5-3 12 6 22 3200 7.5 4700x1950x2050 HVR 415 1500 4 6 3 4 1 37' 0.5-3 25 13 8 4500 7.5 2250x1850x2050 HVR 420 2000 4 6 3 4 1 37' 0.5-3 23 11 11 6200 7.5 2750x1850x2050 HVR 425 2500 4 6 3 4 1 37' 0.5-3 21 8 13 8000 7.5 3300x2250x2400 HVR 430 3000 4 6 3 4 1 37' 0.5-3 21 10 16 10000 10 3700x2250x2400 HVR 440 4000 4 6 3 46 1 37' 0.5-3 20 6 20 12000 10 4500x2250x2400 HVR 615 1500 6 8 4 6 1 45' 0.5-3 22 8 8 6500 10 2250x1900x2100 HVR 620 2000 6 8 4 6 1 45' 0.5-3 20 7 11 6500 10 2750x1900x2100 HVR 625 2500 6 8 4 6 1 45' 0.5-3 24 8 13 8500 15 3300x2250x2500 HVR 630 3000 6 8 4 6 1 45' 0.5-3 22 6 16 10800 15 3800x2250x2500 HVR 640 4000 6 8 4 6 1 45'0.5-3 24 6 20 13600 20 4800x2250x2500 HVR 815 1500 8 10 6 8 2 0.5-3 15 8 8 10500 10 2250x2050x2200 HVR 820 2000 8 10 6 8 2 0.5-3 18 8 11 12000 15 2750x2050x2200 HVR 825 2500 8 10 6 8 2 0.5-3 20 8 13 16500 20 3300x2350x2600 HVR 830 3000 8 10 6 8 2 0.5-3 18 6 16 18500 20 3800x2350x2600 HVR 840 4000 8 10 6 8 2 0.5-3 18 8 20 23000 30 4800x2350x2600 HVR 1015 1500 10 13 8 10 2 0.5-3 14 6 8 10500 10 2250x2050x2300 HVR 1020 2000 10 13 8 10 2 0.5-3 18 8 11 13000 15 2750x2050x2300 HVR 1025 2500 10 13 8 10 2 0.5-3 15 8 13 17500 20 3300x2500x2800 HVR 1030 3000 10 13 8 10 2 0.5-3 12 6 16 20000 20 3800x2500x2800 HVR 1040 4000 10 13 8 10 2 0.5-3 13 6 20 25000 30 4800x2500x2800 HVR 1320 2000 13 16 10 13 2 13 15 8 11 16000 25 2850x2500x2700 HVR 1325 2500 13 16 10 13 2 13 13 6 13 20000 25 3350x2600x2800 HVR 1330 3000 13 16 10 13 2 13 11 6 16 25000 25 3800x2600x2800 HVR 1340 4000 13 16 10 13 2 13 9 4 20 25000 30 4850x2200x2800 HVR 1620 2000 16 20 13 16 2 13 18 6 11 20000 30 3000x2500x2800 HVR 1625 2500 16 20 13 16 2 13 15 5 13 25000 30 3500x2600x2900 HVR 1630 3000 16 20 13 16 2 13 12 5 16 28000 30 4000x2600x2900 HVR 1640 4000 16 20 13 16 2 13 9 4 20 30000 30 5100x2750x2900 HVR 2025 2500 20 25 16 20 2 13 12 5 13 28000 40 3500x2750x3000 HVR 2030 3000 20 25 16 20 2 13 11 5 16 35000 40 4000x2750x3000 HVR 2040 4000 20 25 16 20 2 13 9 4 20 40000 50 5100x2800x3000 HVR 2525 2500 25 30 20 24 2 13 10 4 16 36000 60 3600x2900x3000 HVR 2530 3000 25 30 20 24 2 13 8 4 18 45000 60 4000x2900x3200 HVR 2540 4000 25 30 20 24 2 13 7 4 20 50000 75 5100x2900x3200

• Voltage: 415 V
• Phase: 3
• Item Code: HT8002
• Model: SE-800/2002
• Capacity: 7500 Mtr/day
• Usage/Application: Sublimation Printed paper to Fabric transfer by heating.
• Printing Machine Type: HEAT TRANSFER MACHINE
• Power: 65KW

We are manufacture this machine. This Machine is used for saree thread cutting. for example jacquard thread.

TECHNICAL SPECIFICATION:    SIZE OF LOG : 3" to 7” DIA. LOG LENGTH : 6 METER LENGTH SHEAR DIE : SPECIAL GRADE ALLOY STEEL HARDENED  TAPER / OVALITY : TAPER IN CUTTING WILL BE +/- 2 MM  OVALITY : IN CUTTING WILL BE +/- 2 MM  JOB UNLOADING TRAY : WILL BE AVILABLE WITH MACHINE  LENGTH STOPPER WILL BE AVAILABLE WITH MACHINE  HYDRAULIC POWER PACK : AS PER MACHINE CAPACITY  OPERATION TYPE : SEMI AUTO & FULLY AUTOMATIC CUTTING CYCLE TIME : 25 SECOND SHEARING TIME

• Weight: 2 ton
• Capacity: 15000 to 20000 meter in 24 hours
• Power Consumption: 17 HP
• Motor Power: 5 HP 2 MOTOR, 7 HP 1 MOTOR
• Machine Type: Automatic

Frame : Rigid steel frame of UDHNA MACHINE TOOLS shears are optimally designed to avid weak sections at load supports and is of interlocked design. The ram is guided throughout its length by hardened and ground guide ways ensuring proper clearance and clean cut. Hold-Down System : Spring loaded mechanical hold-down pads hold the sheets securely to avoid slipping and bowing result in clean square cut. Hold down units are provided with oversize pads to avoid impression on sheet metal. Blades : UDHNA MACHINE TOOLS shear are provided with Four Edge, single & segment ally High Carbon, Chromium Steel Blades suitable for M.S. &.S.S. Cutting and Extra long life. Lubrication : All bearing parts and guide surfaces are lubricated Through centralize hand-operated lubrication system. Mechanical Back Gauge : This is a standard equipment provided on all UDHNA MACHINE TOOLS Shears. Scale on the back gauge gives instantaneous reading of distance between shear and back gauge, thus avoiding errors and maintenance encountered in electronic equipment. Finger Guard : Fitted in front of hold-down for operator safety without obstructing viewing. Standard Equipment : Electrical System consisting of motor & Control Panel of Starter, Gear and wheel guard, V-Belts, Hand operated back gauge, Manual Lubrication System, T-slot front gauge, Front scale gauge, instruction Manual. Optional Equipment : Hydraulic hold-down system, Automatic lubrication system, Ball roller or Ball Transfer, Foundation bolts, Extension squaring arm.

• Voltage: 380V
• Weight: 4000 kg
• Max Shear Width: 200 to 250 cm
• Process Speed: 1000 rpm
• Shearing Blade Diameter: 149mm
• Number Of Spiral: 18, 20, 24 Spiral
• Dimension: 3.98 x 3.89 x 2.98 mtr
• Frequency: 50 Hz
• Fan Power: 7.5 kW
• Power: 8 kW
• Fabric: Velvet fabric

• Features: Hassle free operations, Excellent performance , Minimum maintenance
• Approx Weight: 2300 Kg
