Laboratory Bin Blender
500,000 - 100,000 Per Piece
1 Piece (MOQ)
Boinns Bin blenders are used mainly for blending of dry powders for tablet and capsule manufacturing process, which facilitates better flow for tablets and capsules. This is a closed contained, totally dust free single step transfer system. It can handle more than one size of container (Bin). Bin Blender has a flexibility of Batch Volume. Varying size of containers can be mounted on a drive console which is equipped which clamping arm. Batch size variation achievable in 3000 Liters. Model for example, is from 5 Liters to 3000 Liters. using different sizes of containers. The mixing efficiency is better than the other type of tumbling blenders like Double Cone, 'V' or Octa as they rotate in a diagonal and in a eccentric plane. It shuffles the product intimately resulting in homogeneous blend within 5-20 min. Salient Features 0° stopping for easy docking and undocking of the bin. A suitable fencing around the arm with an entry point for the bin on detachable trolley. Limit switch on entry door to prevent the accidental operation of the arm. Flexibility of accepting variable bin sizes providing wide range of batch volumes. cGMP construction with cladded polished S. S. sheets. Built-in Butterfly valve (150 mm dia) at the bottom suitable for discharge. Suitable leak proof vent on top. Highly effective for low volume active blending with as low as 1 % active. Processing of different sizes of production batches in single equipment with scale up data. 99 Recipe inbuilt 21 CFR Part 11 Compliances Printing option with USB MOC SS 316L Optional
Stainless Steel Conta Bin Blender
Get Price Quote
Fabricated making us of corrosion, abrasion and weather resistant stainless steel, our Stainless Steel Conta Bin Blender is energy efficient assuring longer service life. It is provided by us at the market-leading prices. When it comes to delivery, we make arrangements for swift and safe deliveries without any delays. We are a celebrated Manufacturer and Supplier of Stainless Steel Conta Bin Blender from Maharashtra, India
Best Deals from Bin Blenders
bin blenders
Get Price Quote
Vibro sifters are circular gyratory screens used to separate • Mass composition of solids, liquid form solid and for • Gradation of materials as per particle sizes. • Vibration is generated in three different planes along the • Vertical axis by means of a specially designed vibratory • Motor having off centered weights at the top and bottom • End of the motor shaft.
bin blender
Get Price Quote
Description One of the perfect example of batch blending where sized granules collected in a container, docked to the blender arm, clamped, lifted from a single end and tumbled for the pre-validated time. The low shear blending action prevents excessive fines or changes to particle shape or size. Fast loading, complete discharge, short cycle time, low powder requirement and minimum maintenance are some of the features. Conta blending improves efficiency compared to conventional blenders because of mixing in the diagonal and eccentric planes. Enormous flexibility – different capacity of bins (for e.g. 200 Ltrs., 400 Ltrs., 600 Ltrs.) can be docked in the single fork of the same conta blender. Also various shapes of bin can be accommodated. (For eg: You could dock an Octagonal / V Shaped Blender body in the same arm of the Conta bin) The arm of the bin blender does not have any nylon rollers or pins. It is a simple sliding system with a wedge arrangement for resting.
bin blenders
Get Price Quote
The right hand side shaft is connected to a standard gearbox by means of chain and sprockets, which in turn is coupled to an electric motor. The whole drive assembly is covered with S.S. side panel. The inside portion of Octa body is mirror polished and the outside surface of Octa body; frame & guards are matt polished. The material to be mixed is charged in machine either manually from top or bin charging system or vacuum charging system and then the port is locked positively. Then blender is started to preset blending time. At the end of process, machine is stopped and the product is transferred to process containers by opening the butterfly value.
bin blender
Get Price Quote
bin blender, cone mill, high shear mixer granulator
Conta Bin Blender
Get Price Quote
Bag Dump Station, SIFTING & SIZING EQUIPMENTS, CAP TRANSFER SYSTEM
