DC To DC Converter Dealers in Thane

• Brand Name: POWERTRON
• Input Voltage: 230VAC,50HZ
• Design: SMPS BASED
• Series: SMPS
• Output Voltage: 24VDC
• Current: 5A

• Size: Miniature Size, High Efficiency, Long Life High Reliability
• Brand Name: POWERTRON
• Output Type: 110VDC
• Input Voltage: 24VDC
• Warranty: One Year Warranty
• Output: 110 VDC
• Output Ripple and Noise: Less than 1%: Working Temperature: -15o to 65oC
• 100% Full Load Burn in test: Built in EMI filter, Low ripple Noise
• Open frame enclosed frame Models are available: Protection: Short Circuit / Over Load / Over Voltage / Over Temperature

POWERTRON offers DC DC CONVERTER ranging from 5W to 10KW and come in a wide variety of Open frame, Enclose type, Chassis mounting, DIN Rail with total custom build solution.

DC/DC converters are designed to convert the voltage from DC power source to the single/multiple output voltages required by load devices with Galvanic Isolation and Dynamic correction.DC/DC converters are used in 220 V /110 V battery- powered systems in order to obtain low voltages 24 V or 48 V. The converters take advantage of redundancy, to ensure a highly reliable power supply to low-voltage loads eliminating the use of back-up batteries 24V or 48V. A single rack contains three identical DC/DC converters designed to operate in parallel. The output power of any two converters is sufficient to supply the loads. During normal operation, the load is distributed between the three converters, each of them supplying one third of the output power. Should one of the converters fail, the remaining two will continue to supply power to the loads. A 220V or110 V battery in combination with the DC/DC converter provides an uninterrupted supply to the low-voltage devices. They can also be used to supply high-voltage loads 220V or 110V from a 24 V or 48 V battery supply with no need for 220 V or 110 V batteries.Their main benefit is to save the costs of installing and maintaining the multiply batteries

• Noise: 2% P-P Max.
• Wider Range of Input: ± 20%.

DC voltage converter Overload & Short circuit Protection.Switching Frequency 50 100 KHz.Operating Temperature Range: 0 to 55°C.Load & Line Regulation: ±0.2%.

• Brand Name: POWERTRON

POWERTRON INSTRUMENTS offers DC DC CONVERTER in Single & Multiple Output ranging from 15W to 300W and come in a wide variety of Open frame, Enclose type, Chassis mounting with total custom build solution. Single & Multiple Output Series Specifications : � AC Input Range : 10VDC TO 550VDC � DC Output Range : Any Output VA rating OR CUSTOME BUILD � Output Ripple and Noise : Less than 1% � Working Temperature : -15o to 65oC � Efficiency : Better than 85% Features � 10VDC TO 550VDC Wide Input Supply Range � Built in EMI filter, Low ripple Noise � 100% Full Load Burn in test � Working Temperature -5DegC to 55DedC � Open frame & enclosed frame Models are available � Protection : Short Circuit Over Load Over Voltage Over Temperature � Miniature size, High efficiency, Long life & High reliability

We manufacture highly efficient DC-DC Converter which can be used with lots of products. We know the value of electronic items and for that we make sure our DC-DC Converter provides optimum performance and superior power stability. We also make sure that our DC-DC Converters are lightweight and consume less power on their own.
