Flexible Shafts Dealers in Thane

We manufacture various type of flexible shaft based on application. One can use flexible shaft suitable for speed of 850 RPM to 12000 RPM. We produce flexible shaft of minimum Size 3mm dia to maximum 25mm dia or more (as per requirement). Our flexible shafts are used or tube cleaner purpose, grinding purpose, concrete mixing vibrator purpose, Or for Power transmission purpose. A electrical power is transmitted into Flexible shaft in form of rotation through the motor unit to accessories (tool head cutter or brushes) is used for cleaning purpose. Flexible Shafts is made of Inner core, Outer Casing & connected with sockets. Inner Core is made of spring steel or stainless steel highly tensile flexible wire (as per requirement) with multiple wounded layer’s vibration free after processing through heat treatment process. Outer Casing is made from galvanized steel strip. To avoid any kind of friction between outer casing & inter core a special spring steel lining is provide with double interlock & circular round. Connect with one end by a Socket (machine end) is attached to suitable motor & other socket (tool end) is attached to shaft.

• Brand Name: Really
• Material: Cast Iron
• Usage/Application: Brush cutter attachment
• Model Name/Number: FLEXIBLE SHAFT
•  :

It is used for cleaning of tube by transmitting power in terms of rotation from the motor unit to tool head cutter or brush within tube. INNER CORE: It is flexible wire with multiple wound opposite layer. It is made of high tensile spring steel or stainless steel (as per requirement) and passed through heat treatment processes to make it absolutely vibration free. Outer Casing: It is flexible, double interlocked, circular rounded, made of galvanized steel strip, Special spring steel lining is provided within outer casing to avoid any friction between inner core & outer casing. Connection: One end of shaft with machine end socket is attached to suitable motor and other end is attached to tool end. For Domestic or Indian Flexible Shafts, Sizes are as Follow:   1. Model: BFS-105:: Inner Core: 12.5mm | Outer Casing: 26.5mm   2. Model: BFS-106:: Inner Core: 15.0mm | Outer Casing: 33.0mm   3. Model: BFS-107:: Inner Core: 18.5mm | Outer Casing: 35.5mm   Note: Tolerance for Inner Cores Are +/- 0.5mm   Note: Tolerance for Outer Casing Are +/- 1.0mm

The flexible shaft transmits constant torque from the drive motor to the to the connected tool within the tube. INNER CORE -  The inner core is double wound in opposing layers made out of high tensile spring steel wire and is then passed through stress relieving processes to achieve a totally vibration free performance and continuous duty.OUTER CASING - The outer casing is flexible, made from the finest galvanized steel strip and provided with a special steel anti friction lining for the entire length.CONNECTIONS -  A suitable motor connection at one end and a detachable ball bearing hand piece (tool Holder) with a threaded spindle for tool connections at the working end of the flexible shaft.

• Brand Name: Bhartiya
• Color: Black
• Length (mm): 800
• Diameter (mm): 5 to 30

• Material: SS
• Feature: Flexible
• Length: 5 m to 30m
• Inner Core: 1/2" to 3/4"
• Brand: Subzero
• Outer Core: 1" to 1 3/8"

• haft Model: Aluminium Cap Colour Code
• 701: Gold
• 702: Black/Red
• 703: Red
• 704: Blue

Nylon Flexible Shafts with Galvanized Inner Core.  When Ordering Nylon Flexible Shaft and Accessories, each item should be ordered for Specific Tube / Pipe Size or Size Range. Shafts have Colour Coded durable Aluminum Caps for easy identification. Galvanized Inner Core ensures our Shafts have Longest Life, Flexibility and Resistance for Corrosion. To Order Flexible Shaft's, determine Tube I.D.s and Length of the Longest Tubes. Order Flexible Shafts to correspond with Tube I.D.s and Lengths.

Boiler Tube Flexible Shaft, Grinding Contact Wheel, Bar Guide Pad
