Flush Valves Dealers in Thane

We are offering Toilet Flush Valve

We offer a wide range of flush bottom tank valves. These are available in opening inside tank and opening inside valve design with teflon seating and metal to metal seating. We can offer these valves with following features: Manual/Gear Operation Motorized/Pneumatic operation RTD for temperature indication Special Alloys APPLICABLE  STANDARDS FACE TO FACE - ANSI B 16.10 MFG. STD - TESTING STANDARDS -API 598

• Size: Standard
• Brand Name: As required

• Size: As per Requirements
• Material: UPVC, MS
• Certification: ISO 9001:2008 Certified
• Application: Gas Fitting, Water Fitting
• Color: Sky Blue
• Pressure: Medium Pressure
• Feature: Blow-Out-Proof, Casting Approved, Durable
• Automation Grade: Manual
• Quality: Optimum Quality

“Y” TYPE Flush bottom valves are used to discharge Liquids &Slurry from the bottom of Reactors, Receivers & huge Tanks. “IVE” Flush Bottom valves are available in design of Disc opening into the Tank ( vessel opening design) & Disc lowering (inside valve opening design) into the valve body. Flush bottom valves with disc opening into the tank or opening upwards is the most commonly used. It is used where enough space is available between bottom pad and the starrier of the tank. The mass load inside the tank helps closing & tight shut off the flush bottom valve. KEY FEATURES AND BENEFITS Unique design of IVE flush bottom valves assure “Zero- Hold Up” in the bottom pad of the tank. And facilitate the free flow and quick discharge of the liquid or slurry through the valves. Casted and fabricated in all available metallurgy, Carbon Steel, S.S 304, S.S 316, S.S 304L, S.S 316L, Alloy 20, Hast alloy and as per special specifications. Conical Metal to Metal disc seating/ PTFE seating with option of fixed or Renewable seat. Further metal seating can be hard faced by Stellite TM where distortion of seat by aggressive liquid or slurry is common. Valves available in the size range of 15 NB to 250 NB in BS, ANSI & DIN standards. Available in the design of Jacketed, Actuated & Lined. Offered for Sanitaryaseptic application. Outlet discharge angle available in 450and can also be tailored made to 600. IVE Flush Bottom vales can also be provided with the temperature sensors to measure the temperature in the vessel. Bolted Stuffing Box (Gland), easily adjustable & with Repackable service. Rinsing & Non Rinsing stem with outside ACME thread.

Flush Bottom Valve Flush Bottom Valves are most popular in Pharma and Industries for emptying the vessel from bottom. Effective in handling Highly Dense and Viscous Fluids & Slurry, Jacketed bodies are also available to maintain the liquid in flowing state

The Valves are designed to open directly in the tank, reactor for 100% Flushing or discharging the material. Easy Operation even under high pressures. Full circular passages. Easily replaceable PTFE seats & Packing. The design is featured with inclined bonnet which allows the automation OR manual operation to be free from fouling with the reactor disc end.

• Packaging Type: Box
• Media: Water
• Material: Stainless Steel
• Pressure (Bar): Upto 50
• Surface Finishing: Polished

The clients can stay assured with us for their transactions, as our payment methods are quite safe and reliable. Purchasers can rest secure; our entire range is premium, as they are wholesaled by us after subjecting them to a string of quality control tests.

Flush Bottom Valves are most popular in Pharma and Industries for emptying the vessel from bottom,Effective in handling Highly Dense and Viscous Fluids & Slurry,Jacketed bodies are also available to maintain the liquid in flowing stat.

Designed and Manufactured as per BS 5351 End Connection: ASME B 16.5 FEATURES The Valves are designed to open directly in the tank,reactor for 100% Flushing or discharging the material. Easy Operation even under high pressure. Full circular passages Easily replaceable PTFE seats & Packing. The design is featured with inclined bonnet which allows the automation OR manual operation to be free form fouling with the reactor disc end. MOUNTING Interface: ISO 5211. Body MOC : WCB,CF8,CF8M,CF3,CF3M(Special on Request). Trim MOC : CF8, CF8M,CF3,CF3M(Special on Request). Seat MOC : PTFE,GET,PEK(Special on Request). Size: ½” (15mm) to 8″ (200mm).

Tecnik’s Flush Bottom Valves are used for process materials discharging applications. These angle-type flush bottom valves are designated for two values and two types of construction. The first value is the inlet flange connection size which is fixed to the tank or vessel’s bottom pad, and the second value is the size of the port and the outlet flange which is connected to the pipe Better flow capacity for line sizeSuitable for drainage systemsTight closing for reliable shut-off even if change in pressure and temperature are sudden and extremeWide selection of actuators to meet most system requirementsFlexible design capabilities allows fitting any vessel configurationMeasurement temperature is available with built-in thermometerJacketed option available (full jacketed & semi-jacketed)Unique packing designs to suit various temperature and fluid needsExcellent shut-off performance Jacketed BodyIntegrated RTD in PlugInlet Flange Contoured to suit Vessel Curvature

We offer Y-type-flush-bottom-tank-valve. Pressure Rating ASA 150# Design Upward Downward Pressure Test BS 6755 End Connection ANSI B16.50 BS10 Table 'DEF' Flanges M.O.C. CS SS304 SS316 WCB CF8 CF8M & Higher Alloys on request Operation Hand Wheel Operated Option Jacketed Size Range 40 mm to 150 mm

Flush Bottom Bellow Seal Valve, Metal Cryogenic Valves
