Furnaces Dealers in Dombivli, Thane

Light weight with ceramic wool insulation (instead of Brick insulation). The outer casting is made of double walled thick PCRC sheet, duly painted with attractive stove enamel. Heating elements are made of Kanthal A-1 wire and backed by high temperature cerwool insulation, which avoids loss of energy. The temperature control unit consists of highly accurate micro processor based PID & ON OFF Controller (timer facilities available optional), fitted in front of the furnace with two pilot lamps. The apparatus is complete with one thermocouple, silver thermal fuse, and main lead with power plug. To work on 220/230Volts AC or 400/440 Volts AC.

We manufacture optimum quality heat treatment furnaces, which are fabricated using finest quality raw materials. Our furnaces enable various heat treating applications with solid state temperature controls along with energy saving insulation. Our standard 1000° c and 1200° c furnaces are cost effective and high performance furnaces ideally suited for general purpose heat treating of tools, dies & other parts.

Mini Blast Furnace (MBF): A Blast furnace of working volume 350 M3 designed by MECON Ltd. to produce 3,00,000 MT annum of basic grade hot metal has been installed and sucessfully commissioned. The hot metal is mainly used in the steel melting shop as a raw material and surplus hot metal poured in pig casting machine. The Pig casting machine is designed by KBS Paramount & capacity 800 Tonnes per day (TPD). The Blast furnace gas is used for stoves heating, heating of preheating furnace of bar and section mill, heating of boiler ,sinter plant. Slag which is a byproduct is mainly sold to cement plants.

• Working Size: 4 × 4 × 9 in inches. (Other sizes optional)
• Resolution: 1 °C.
• Accuracy: ± 2 °C.

As per ASTM – D1709 and IS 2508. Smoke ventilation provided at backside. Temperature cross checking provision provided Temperature Range – Ambient to 1100 °C. Temperature control system – Microcontroller based PID controller. Supply – 230 VAC/ 50 Hz. Paint – Powder coated.

We are leading Muffle Furnace, Manufacturers, Suppliers & Exporters Located in Dombivli Dist. Thane, Mumbai India.   → Models: AE-MF-S → Working Size: 4” X 4” X 9” → Temperature Controlling System: Microcontroller based PID → Temperature Range: Ambient – 1100°C *** → Temperature Resolution: 1°C → Accuracy: +/- 0.25% of the range in throughout the chamber → Safety Thermal Fuse Protection: Optional*** → Safety MCB Protection: Available *** → Smoke Ventilation: Provided on backside → Accessories: Crucible; Long Twister → Supply: 230 VAC/50 Hz → Power: 1.5 KW → Paint: Powder coated

ceramic furnaces, Spiral Plating System, Automatic Colony Counter
