Immersion Heaters Dealers in Thane

• Type: Water Immersion Heaters
• Certification: ISO 9001:2008
• Weight: 10-0kg
• Voltage: 110V, 220V, 380V, 440V
• Condition: New
• Power: 1-3kw, 3-6kw, 6-9kw, 9-12kw
• Warranty: 1year
• Energy source: Electric
• Temperature Capacity: 100-150C, 150-200C, 25-50C, 50-100C
• Country of Origin: India
• Brand Name: COMMONWEALTH
• Application: WATER HEATING

We are offering oil heaters used for furnace oil heater, thermic fluid process heater.

• Copper: 360°F (180°C)
• Stainless Steel: 1200°F (650°C)
• Steel: 750°F (400°C)
• Incoloy: 1500°F (815°C)

heating up liquids using direct heat transfer allows for the liquid medium to quickly reach the desired temperature using electric heaters. This application is commonly used in chemical processes, large petrochemical containers as well as large water containers that require fast heatup time. With minimal maintenance requirements, immersion heaters are an excellent solution to rapid heating in almost any industrial environment.   application   water heating. freeze protection. viscous oils. storage tanks. degreasing tanks. solvents. salts. paraffin. caustic solution. domestic applications . oil filtration plants . electroplating industry . features lightweight moisture proof available on all models portable no drilling holes required easy to install and to remove easy to maintain maximize heat transfer provide uniform temperature moisture resistant oxidation and corrosion resistant built solidly designed for safety durable safety issues considering the environment within which the immersion heater will operate utilization of adequate temperature controlling devices, temperature and pressure high limit switches, low liquid level and flow controllers and other control/safety devices that will control the heating process and protect the heater from excessive heat the classification of the electrical terminal box required the level of the contamination that the immersion heater will be exposed to safety and electrical code consideration the possible requirement of baffles that force a gas or a liquid to circulate around heating elements when flanged immersion heaters are used inside circulation tanks

We bring forth for our clients Tubular Direct Immersion Heaters that are specifically designed for direct contact heating of water, oils, viscous liquids, solvents, process solutions and gases. As all heat is generated within the liquid or process, virtually 100% energy ratio is achieved. Further, various options permit very tight process temperature control. The basic mounting options of these heaters like threaded screw plug connections, flanges or simple over-the-side designs help our clients with easy installation of the heaters.

Tubular elements used for heating liquids are known as immersion heaters. sheath of the element can be enclosed in metallic or non-metalic Element casing made of special alloy can be used for longerlife of the element. Material sheath- S.S. 304, S.S. 316, Titanium, encolly 800.

• Length: 8" to 72'
• Tube Dia: 3 8" to 5/8"
• Volts Q: 250 - 440V
• Watts: 500 to 60.0 KW

Flanged immersion heaters are one of the most widely used methods for heat-ing gases and liquids (such as water, oil, heat transfer fluid and corrosive solutions). Designed for use in tanks and pressurized vessels, they are easy to install and maintain to provide heat for many processes. The direct immersion method is energy efficient and easily monitored and controlled. Hot Water Storage Tanks Warming Equipment Preheating All Grades of Oil Food Processing Equipment Cleaning and Rinsing Tanks Heat Transfer Systems Process Air Equipment Boiler Equipment Freeze Protection of Any Fluid Flanged Immersion Heaters consist of bent tubular elements welded or brazed into a flange and provided with wiring boxes for electrical connections. Flange heaters are installed by bolting to a matching flange welded to the tank wall or nozzle. A wide selection of flange sizes, kilowatt ratings, voltages, terminal enclosures and sheath materials make these heaters ideal for all types of heating applications.

Flanged heaters are commonly used in many chemical, petroleum and water based applications. Consisting normally of an ANSI rated flange with several hairpin elements or bugle tubular elements extending from the face of the flange, this electric heater uses direct heat application to the liquid medium. Flanged heaters allow the flexibility of using many different alloys to help resist corrosion and maintain life longevity of the flanged heating element. Steel flanges are typically used for lubricant oils, heavy and light oils, waxes as well as mildly corrosive liquids and low flow gas heating.

Tubular elements used for heating liquids (corrosive - non-corrosive) are known as immersion heaters that are manufactured by us using high quality material. Available in ranges of 1 KW lo 4.5 KW with adaptor fillings 1'BSP lo 2 1/2'BSP threaded brass flanges duly nickel chromium plated. Application Areas:• Air-Conditioning• Pharmaceuticals• Chemicals• Textile• Nuclear

Tubular elements used for heating liquids (corrosive and non-corrosive) are known as immersion heaters. For corrosive medium, sheath of the element can be enclosed in metallic or non-metalic Element casing made of special alloy can be used for longerlife of the element.Available in ranges of 1 KW to 4.5 KW with adaptor fittings 1" B.S.P to 21/2 " B.S.P threaded brass flanges duly nickel Chromium plated. Heaters high rating are available on request with flanged connections. The Photographs are those of water 7 oil immersion heaters simultaneously.

• ranges: 1 KW to 4.5 KW

Tubular elements used for heating liquids (corrosive and non-corrosive) are known as immersion heaters. For corrosive medium, sheath of the element can be enclosed in metallic or non-metalic Element casing made of special alloy can be used for longerlife of the element.Available in ranges of 1 KW to 4.5 KW with adaptor fittings 1" B.S.P to 212 " B.S.P threaded brass flanges duly nickel Chromium plated. Heaters high rating are available on request with flanged connections. The Photographs are those of water 7 oil immersion heaters simultaneously.
