Spraytech Systems India Pvt Ltd Wagle Estate, Mumbai, Maharashtra

Suited for CIP systems. No motor source is needed due to the reaction force of the cleaning liquid to rotate spray head. Low pressure for cleaning and rinsing application. For rinsing small and medium sized vessels for example dairy, chemical, pharmaceutical and food industries. Material of construction-corrosion –resistance TEFLON.

Compact stream jet with a defined jet length owing to optimum flow geometry. Flow conditions are not affected by turbulence. A concentrated jet with high impact force is achieved. This is used for powerful punctiform impact, wherever concentrated jet power is vital.

  Compact stream jet with a defined jet length owing to optimum flow geometry. Flow conditions are not affected by turbulence. A concentrated jet with high impact force is achieved. This is used for powerful punctiform impact, wherever concentrated jet power is vital. Characteristic : A high efficiency and economical performance is obtained. Design : One Piece Construction.Application : For High pressure cleaning systems, Jet Cutting and separating.Features : Optimized flow maximum jet power concentrated energy.

Application : For High pressure cleaning systems, Jet Cutting and separating.

  Application                         :  Continuous Casting Cooling. Spray Characteristics         : 1] Produces a full cone pattern                                             2] Sprayed volume is evenly distributed across spray pattern                                             3] Available with a range of spray angle Materials and Construction : 1] Standard materials are Brass and Stainless Steel                                             2] Male and female thread available                                             3] 3/8" or 1/4" BSP / NPT threaded connections available                                             4] Specially designed internal core ensures a good                                                 resitance to clogging

Produces a full cone pattern, Sprayed volume is evenly distributed across spray pattern, Available with a range of spray angle.Specially designed internal core ensures a good resitance to clogging.

Oil burner nozzles are available in semi hollow cone spray pattern. Micro-finish of tip & disc seats permitting flow only through the slots of the disc, plus extremely close manufacturing tolerances, ensure accurate capacity control. These nozzles are fitted with filter in order to provide highly efficient in depth filtration with one piece construction extra fine filter microns are supplied as standard on all small capacity nozzles. Application : LDO firing in kilns of cement, sponge,Iron plants & Dust suppression. Range : Spray Angle : 45º,60º,70º,80º & 90º.Flow rate (GPH) at 100 PSI Pressure : 2.50, 3.00, 3.50, 4.00, 4.50, 5.00, 5.50, 6.00, 6.50, 7.00...... GPH.Connection : UNFE 9/16”M.O.C. : SS 303

Oil burner nozzles are available in semi hollow cone spray pattern. Micro-finish of tip & disc seats permitting flow only through the slots of the disc, plus extremely close manufacturing tolerances, ensure accurate capacity control. These nozzles are fitted with filter in order to provide highly efficient in depth filtration with one piece construction extra fine filter microns are supplied as standard on all small capacity nozzles.

Material : Stainless Steel

  These hollow cone nozzles work on the tangential flow principle and are manufactured by machine tool operation from metal bar stock.This offers versatile construction of small sized nozzles. In addition nozzles can be made on request from any special materials and alloys that are available as a bar stock. There are Following types of hollow cone nozzles.1) Tangential Entry 2) Inline (Axial) Entry 3) Spiral Hollowcone. Design        : Vaneless (Two Piece Construction ) Non clogging Application : Cooling & Washing of gas

Application : Cooling & Washing of gas

   DA SERIES FULL CONE SPRAY NOZZLES - MEDIUM CAPACITY : The Larger Nozzles in the DA Series are widely used in the industry, for a wide variety of applications. They maintain the simple design of the smaller nozzles, With the inherent resistence to clogging due to design of the X-vane and are often manufactured by any type of machinable material like SS304, SS316, PP/PVC etc. Flow Rate    : 96 LPM to 1200 LPM Application : Surface spraying, Washing & Cooling of flue gasses to remove fly ash , Cooling Condenser, Scrubbing, Foam breaking.

CA SERIES FLAT SPRAY NOZZLES STANDARD FLAT SMALL CAPACITY  Type "C" flat nozzles are designed for high pressure washing applications. Their specially designed inner profile allows for even jet distribution, which results in effective and uniform cleaning action over the surface being processed. All nozzles are finished on high precision machinery assuring close manufacturing tolerances made out of AISI 316 grade stainless steel and all machinable material. Design : One piece construction, Non clogging type. Application : Surface Treatment, Roll Cooling, Degreasing & Rinsing, Lubricating, Industrial washing machines.

flat nozzles are designed for high pressure washing applications. Their specially designed inner profile allows for even jet distribution, which results in effective and uniform cleaning action over the surface being processed. All nozzles are finished on high precision machinery assuring close manufacturing tolerances made out of AISI 316 grade stainless steel and all machinable material.

Suited for CIP systems. No motor source is needed due to the reaction force of the cleaning liquid to rotate spray head. Low pressure for cleaning and rinsing application. For rinsing small and medium sized vessels for example dairy, chemical, pharmaceutical and food industries. Material of construction-corrosion –resistance TEFLON. Application  : Cleaning of tanks up to 3 m in diameter. Self - rotating. Double bearings.

Air Atomizing Spray Nozzle mixes liquid & air to give fine mist like formation. In common situation we can get super fine liquid spraying drops. Adjustable atomized nozzles can adjust liquid capacity and it can meet the requirement of spraying without changing air pressure and hydraulic pressure therefore it has good adaptability. Each spray device is composed of air cap and liquid cap which can offer two spray modes flat fan and round with wide liquid capacity coverage. There are various available sizes of inlet joint for these type of Spray Nozzles. It is flexible with changeable parts. Atomizing Nozzle has good moisture effect. It is the ideal choice for the location where requires moisture control. Application      : Wool Spraying & Moisturization                          Mould Lubricating                          Spraying Injection                          Air Disinfection                          Humidification

Air Atomizing Spray Nozzle mixes liquid & air to give fine mist like formation. In common situation we can get super fine liquid spraying drops. Adjustable atomized nozzles can adjust liquid capacity and it can meet the requirement of spraying without changing air pressure and hydraulic pressure therefore it has good adaptability. Each spray device is composed of air cap and liquid cap which can offer two spray modes flat fan and round with wide liquid capacity coverage. There are various available sizes of inlet joint for these type of Spray Nozzles. It is flexible with changeable parts. Atomizing Nozzle has good moisture effect. It is the ideal choice for the location where requires moisture control.
