Test Chamber Dealers in Thane

• Brand Name: Indeecon
• Type: Automatic
• construction: Robust
• temperature: Limit of 180C
• Material: SS and MS

• Temperature Range: RT+100C
• Humidity range: 30%
• Testing Time: 20hours
• Testing Voltage: 120V
• Testing Current: 15A
• Black Bulb Thermometer: 63±30C
• Sample Rack Size: 508?
• Sample Rack Rotation Speed (rpm): 3
• Specimen Sample Rack: 248x50mm, 20pcs
• Dimension (W x D x H cm): 130x130x200
• Power: 1? 220V 6KVA

Low Temperature Test Chamber is designed for testing of different types of methods and allied products, especially for rubber and plastic industries at low and ultra low temperatures. Our company’s name figures in the list of prominent Manufacturers, Suppliers and Exporters of Low Temperature Test Chamber from Maharashtra, India. The testing can be carried out as per ASTM, IS and many other test methods i.e. brittleness, flexibility test, impact test and rubber hose bending and compression test. All different type of tests can be carried out in the Low Temperature Test Chamber at the different temperatures and to the tolerance limit of ±1oC.

• Brand Name: Labtop
• Place Of Origin: Mumbai
• Usage: To conduct stability and shelf life studies on drug and drugs substances
• Interior staniless steel thickness: 304 SS, 0.8 mm
• Exterioir white power coated thickness: 1.0 mm
• Features: Precise control of temperature and humidity

LABTOP Stability Test Chambers are especially designed to conduct stability and shelf life studies on drug and drugs substances. In addition to this, Labtop Stability Test Chambers are extensively used for seed testing, biological studies, testing on electronic & mechanical components, Cement plants, packaging industries etc. Special Features Precise control of temperature and humidity by using CE approved micro controller based.PID controller (Imported, Auto tuning type.)Direct digital read-out of % RH with a electronic capacitance type sensor. No wick, cup and water (Optional)Refrigeration system with CFC free compressor and R-134a ECO-friendly refrigeration system with time delay.PC interface with Windows based communication software.(Optional)Micro controller based programmable timer for chamber illumination. (Optional).Foamed - in - place PUF insulation ensures temperature stability and reduced energyconsumption.Audiovisual alarm if the temperature deviates from the pre set temperature (Optional). Cabinet Construction and Refrigeration System The cabinet of Labtop Chambers are insulated with high density CFC free Poly Urethane Foam. Interior of chamber is mirror finish stainless Steel (304 SS, 0.8 mm thick). The exterior is white powder coated (1.0 mm thick) mild steel and the door has a magnetic door gasket with a keyed door lock. Stainless steel trays are provided for storage inside. The cooling is effected by a hermitically sealed compressor of high quality. GMP models are in total stainless steel (Inside S. S 316 with mirror finished and outside. S 304 dull finish.) is also manufactured by Labtop Instruments Pvt Ltd. OPTIONAL ACCESSORIES Stand by Refrigeration system Ready to use stand by refrigeration system in case of regular system fails. This includes Compressor, Evaporator, condensers and other accessories. Safety Controller Dedicated safety controller with separate sensor to switch off the power supply in case of overshoot and undershoot of temperature giving audio visual alarm. Data Scanner Data Scanner 4 point temperature and 4 point humidity or 8 point temperature 8 point humidity complete with Sensors and printer interface and data storage facility. Printer Interface Facility to store, print records on printer with set values, Process values, date and time with variable print time interval. Data storage facility to print the data online and off line, suitable for 80 col. Dot matrix printer. printer interface for LUX & UV meter automatic shut off after specified exposure level. Software CFR 21 Part 11 compliance web based communication software for data management. Complete with RS 485 multi dropping to monitor multiple chambers to one software. P C Inter Face and Data Management PC Interface communication allows remote monitoring and data logging to control the chamber. Web based software having reports in tabular as well as graphical form. Temperature & Humidity Sensor Electronic capacitance type Temperature & humidity sensors, which will avoid wick, cup and water. PLC System for auto changeover of standby systems and other event managements with3.8" LCD display with touch screen, security lock for prevention of unauthorized tampering. US FDA 21 CFR Part 11 FEATURES Set and view control parametersComplying US FDA 21 CFR Part 11Access control and different access levelsMulti user with individual user name and passwordDatabase protection, backup and restore facilityOnline and Offline trendsChamber wise report / trend generation, printing facility reports can be export to other formats (PDF, Excel)Analysis of stored dataAlarm acknowledgement with user commentsAuto logout and account lockout facility for security reasonsAccess control with unique username and passwordReconfirmation of username and password for change of critical parameters Alphanumeric password.Password aging Complying US FDA 21 CFR Part 11 Date and time stamp audit trails User, EquipmentAlarm, SMS audit trails Separate alarm and log data recording SOP for installation, backup, restore, software operation. Documentation : For GMP complaint models LABTOP offers DQ IQ, OQ and PQ validation with documentation, reports, calibration and test certificates. Calibration : The equipment is calibrated with the help of master calibrator, which is certified for its accuracy by Electronics Regional Testing Laboratory (ERTL West) Government of India recognized testing laboratory with traceable reference to National Physical Laboratories (NPL).

• Temperature Range: : 20°C to 60°C
• Accuracy: : ± 0.2°C
• Humidity Range: : 40% RH to 95% RH
• Accuracy :: ±2% RH
• Humidity Uniformity: : ± 3% RH
• Temperature Uniformity: : ±1°C

Construction : The unit is a double walled chamber, with glass wool / PUF insulation. Interior is made of Stainless Steeland Exterior is either made of Mild Steel finished in powder coating paint (powder coating on both sides of the mild steel) or Stainless Steel. The unit has full-length inner glass door and outside metal door with magnetic gasket and lock. The unit is provided with perforated Stainless Steel trays. Forcedair circulation for uniform temperature. PU wheels for easy move ability.   Temperature & Humidity Suitable for 25 °C& 60% RH, 40 °C & 75% RH, 30 °C & 65% RH Specially designed chambers to carry out stability studies at low humidity conditions such as 25°C & 40% RH, 40°C & 25% RH NMT, 30°C & 35% RH   Intelligent Control System :   The controlling system having is PLC Base and PC communication on Ethernet   Heating System :   Long lasting stainless steel tubular heaters with s.s. fins.   Humidity System :   Humidity is by steam injection. A humidifier tank is fitted with two nos of heaters. One heater works as a stand by in case   the regular heater fails. A water reservoir tank is connected to the boiler tank. Two boiler tanks are fitted with magnetic   float switch and float valve. Magnetic float switch is provided for the safety of boiler as it facilitates in cutting off the heater   supply in case of low level of water.   Sensor :   Rotronic make temperature and humidity transmitter 4-20mA used for measurement. Temperature in degree Celsius   and Humidity in %RH with 0.1°C and 0.1%RH resolution.   Cooling System :   Hermitically sealed compressor coupled with evaporation coil and condenser, safe guarded by time delay circuit. CFC   free refrigerant.   Alarms :   Audio and visual alarms are generated for temperature / humidity variation.   Safety :   This unit is provided with safety devices for temperature and humidity over shoot in case of malfunction.   The unit works on 230 Volts AC and 50Hz mains supply.

• Brand Name: Remi
• Material: Stainless Steel
• Colour: off white
• Temperature Range: 10 to 60 Degree C
• Humidity Range: 40% to 95%

We are leading Rain Chambers, Manufacturers, Suppliers & Exporters Located in Dombivli Dist. Thane, Mumbai India.   As per IS 10322 / IEC 60529 IPX3, IPX4, IPX5, IPX6     The apparatus will consist will consist of an oscillating pipe of stainless steel 304, formed in to semi-circle having radius of 900mm   The pipe will be oscillated so as to describe an angle of 60 deg and 90 deg max up to 150 deg. C from vertical line in both the direction. The duration will be about 2 to 4 seconds. The pipe will be provided with holes of 0.4mm dia at a pitch of 50mm. The pipe will be provided with end connections which will be mounted on suitable two horizontal pipes with coupling to circulate the water in the semi circular tube.   The driver will be through geared motor.   The pump with by-pass valve will be provided suitable to be used for both rain proof apparatus as well as jet proof apparatus as per IPX6.   A panel will be provided with gauge to indicate the water pressure.   Timer will be provided of 0 to 30 minutes to set spray time and ON/OFF switch also will be provided.

Customers can avail from us efficient Walk In Stability Test Chamber at pocket friendly price. Walk In Stability Test Chamber has prefabricated modular type structure provided with CFC free PUF insulation. Walk In Stability Test Chamber comes with a safety alarm. Robust construction and efficient performance make our Walk In Stability Test Chamber a great buy for stability and shelf life studies on medicines. Walk In Stability Test Chamber is also useful for seeds testing, biological studies, testing on electronic & mechanical components, and many others. Our test chamber conforms to quality standards such as ICH, WHO Guideline, and USFDA requirements. Customized Walk In Stability Test Chamber can also be availed from us.Cabinet Construction and Refrigeration System : The cabinet of Test Chamber is insulated with high density and CFC free Poly Urethane Foam. Interior of the chamber is mirror finish stainless Steel (304). The exterior is white powder coated mild steel. The cooling is controlled by a hermitically sealed compressor of high quality. Special Features : Prefabricated modular type construction with high density CFC free PUF insulation A safety alarm system is provided in case of any emergency Chambers are available in standard size and also custom made to suit your requirement Display of set value and process value Unique airflow system ensures even distribution of humidity and temperature. Formed - in - place PUF insulation ensures temperature stability and reduced energy consumption. Precise control of temperature and humidity by using CE approved micro controller based PID controller (Imported, Auto tuning type). Refrigeration system with CFC free compressor and R-134a eco-friendly refrigeration system with time delay.

Capacity: 100 - 400 liters Temperature range: -70°C to 200°C Humidity range: 40% to 98% @ 20°C to 60°C. Rate of Heating & Cooling: 1°C min, 2°C min, 5°C min & 10°C min.

We offer Environmental Test Chambers. The REMI Humidity Chambers are designed for testing of electronic, electrical components, corrosion studies on mechanical parts, shelf life studies on paints, varnishes and cement at respective manufacturing facilities. These chambers control precise temperature and humidity. Seed Germinators are used for germination & biological studies, which includes Fluorescent lights coupled with 24 hours cyclic timer for lights on off regulation. These chambers are available in standard & GMP versions.

Construction : Double walled, inner S.S.304 / 316* grade and outer S. Steel or GI dully Epoxy Powder coat / finish, gap filled with Glass wool insulation (PUF in situ foam*) Inner full length viewing glass / plexi door or viewing window on outer metallic door provided. (To select while ordering) Leak proof positive locking arrangment for door. Chamber illuminated with bulb. Cooling -CFC free* Refrigeration :  By Hermetically sealed brand new ISI marked compressor coupled with air cooled condensing unit fitted with Motor, fan blade, Electrical Accessories etc.. Mounted on bottom of unit on heavy base frame.   Humidity : Humidity Created with Steam & Injection into working chamber.   Heating : By long lasting S. Steel Tubular Heater with fins.   Temperature Control : Electronic Digital Temperature Controller-Cum Indicator with Dry Bulb & Wet Bulb Principle. (Direct %RH setting optional)     Optional :   Strip Chart Recorder for Dry & Wet Bulb or Dry & %RH Higher Temperature Upto 700C ( RH ranges as Std ) Complete S. Steel Unit / GMP Models Any other sizes or other temperature range available on request. Micro controller based PID Controller with Printer Interface (Centronic Port) compatible with EPSON / WIPRO Micro controller based PID Controller with RS-232 C PC Interface / RS-485 Interface for multiple  networking of controller. mP Profile Controller for cyclic applications (Ramps & Soak)

"Classic Scientific” makes Laboratory Environmental Test Chambers, which are designed to suit the multi- application in the growing field of Medical, Agricultural, Industrial, Research Laboratories, Metal Treatment, and Various Industries. Our offered Environmental Test Chamber has carved an edge in international markets on the base o their apt functioning at low maintenance. These Environmental Test Chambers are also helpful in maintaining the climate conditions, which is one of their unique features. Traits :- Temperature + 100C to 600CHumidity (R.H.) 40% R.H. to 95% R.HDigital Display Electronic Temperature cum R.H(Humidity) Controller with an accuracy of +/-0.50C & +/-3% R.HMild Steel Powder Coated / Stainless Steel Matt Finish Used at :- MedicalAgriculturalIndustrial Research LaboratoriesMetal Treatment Specifications :- ModelsCS-03aCS-03bCS-03cCS-03d ChamberVolume90.0ltrs.170.0ltrs.285.0 ltrs.340.0ltrs. CubicFeet361012 Internal Size cms.40 X 40 X 5750X 40 X 8557X 57 X 8860X 60 X 95 ExternalSize cms.53X 68 X 13563X 68 X 16370X 85 X 16673X 88 X 173Shelves2233 Range+ 100C to 600CController Accuracy+/-0.50C of set value for Temp./ +/-3% R.H. (Humidity)Uniformity+/-1.00C for Temp +/- 3% for HumidityAir Heater ElementSpecial Type S.S. Tubular Air Heaters with fins.Heat up Time30 min. up to 600C without load.Cool Down time30 min. upto + 100C without loadCoolerPlate Fin CoolerCompressorHermetically Sealed Brand New Kirloskar CompressorControllerDigital Display Electronic Controller.SensorPt-100 for Dry & Wet Bulb / Capacitor type for Humidity.Internal ChamberStainless Steel 304 / 316L quality.ExternalMild Steel Powder Coated / Stainless Steel Matt Finish.InsulationBodyPuf 50mm / Glass Wool 65mmDoorThermo Cole.Inner Acrylic DoorInner Full Size Sea through Acrylic 8 mm thick.CirculationMotorizedBlower from backAirCirculation Motor1/12 Hp, 1440 R.P.M.Steam Injection SystemI.S.I. Mark Kettle HeaterWater tank Cartridge Reservoir4 ltrs4 ltrs9 ltrs9 ltrsBoiler4 ltrs4 ltrs9 ltrs9 ltrsWater qualitypH6.2 to 7.2Safety DeviceWater Level alarmOptionalImported Sensor0 to 100% R.H., Accuracy of +/-2%Computer InterfaceRS 485 / RS232 interface for multiple / single communication port.Safety DeviceThermostator Energy Regulator.  Over heating or humidity soft alarm.CyclicTimer0to 24 hrs X 7 days cyclic ON / OFF timer for illuminating condition.Capacity(watts)2000275032503750PowerConsumption9amps12 amps14 amps17 ampsNetWeight85 kgs90 kgs105kgs117kgsElectricrequirements AC230 V & 50 Hz cycle.

• Application: Industrial
• Temperature range: -70/-40
• Humidity: 10% to 98%
• Resolution: Temp. 0.1 deg.C R.H. 0.1%
• Accuracy: Temp. +-0.5 deg.C max. R.H. +-2% max.
• Volume: 150

We are offering environmental test chamber with Leak proof positive locking arrangment for door. Chamber illuminated with bulb.
