Vortex Flowmeters Dealers in Thane

• Brand Name: Burak Metering
• Material: Stainless Steel
• Power: 24 VDC, 2 AMP & 230 VAC
• Specialities: Accuracy
• Line Size: As per requirement
• Packaging Type: Wooden Box
• Operating Temperature: -20 ... +150°C (Standard Version), -20 ... +280°C (for high temperature)
• Type: Vortex Flow Meter
• Country of Origin: India
• Display: Digital
• Accuracy: ± 2% of reading
• Analog Output: 4 - 20 mA, 3 – Wire Source output

• Medium: gas,liquid,vapor
• .Accuracy: Liquid Gas 1% Steam 1.5%
• Temperature: -20oC to +350oC
• Measure: Liquid Gas Steam
• inside nominal diameter (mm): 25,40,50,65,80,100,125,150,200,250,300,(300
• nominal pressure (MPa): DN25-DN200 4.0(>4.0 order by agreement),DN250-DN300 1.6(>1.6 order by agreement)
• medium temperature (°C): piezoelectric type:-40
• noumenon: 1Cr18Ni9Ti,(order by agreement if need other material)
• vibrating acceleration: piezoelectric type:0.2g     capacitance:1.0
• range: ±1%R,±1.5%R,±1FS;plug-in:±2.5%R,±2.5%FS
• Range degree: 1:6
• service voltage: sensor:+12V DC,+24V DC;transmitter:+12V DC ,+24V DC;battery supply feed:3.6V battery
• output signal: square wave pulse (non- battery supply feed):high level≥5V,low level≤1V;current:4
• loss coefficient: JB/T9249 Cd≤2.4
• anti-explosion sign: Ben-an type:ExdⅡia CT2-T5 anti-explosion type:ExdⅡCT2-T5
• Protection grade: ordinary type IP65     dive type IP68
• environment condition: Tem-20°C
• transmission range: three-wire system flow sensor:≤300m,electric sign of two-wire system transmitter (4

• Nominal diameter: DN15-DN300
• Rated pressure: PN16, PN25, PN40
• Body Material: SUS304
• Detection Probe: 316L
• Power Supply: 24VDC/220VAC
• Output signal: 4-20 mA, pulse
• Temperature range: 280°C

vortex flow meter combines with a unique and powerful combination of digital technology that includes spectral signal processing (SSP).Vortex flow meter is accurate and stable, even in harsh process conditions, and has a highly reliable and robust design that delivers improvements in plant efficiency and reduced operating costs

We deals in manufacturing, supplying and exporting of wide range of VORTEX FLOW METERS.
