Hydro Extractor Machine For Textile Dealers in Tirupur

• Brand Name: Starfish
• Condition: New
• Automatic Grade: Semi Automatic
• Certification: CE, ISO 9001:2008 Certified, GMP Certified
• Type: Industrial Laundry Equipment
• Country of Origin: India
• Driven: Electric
• Model Name: SDH 30
• Motor Brand: Specially Designed by us
• Rpm: 1000
• VFD (Optional): Adjustable Drum Rotation 0-1000 RPM
• Breaking: Electrical
• Drum with Motor: Directly Connected with Bearing
• Extraction Time: 0-15 min controlled by timer
• Control panel: Manually Operated by Switches
• Door Open Cut Off: Limit Switch
• Outer Drum.: Stainless Steel 304 Grade
• Inner Drum: Stainless Steel 304 Grade
• Perforation: Punch Press
• Back Cover: Stainless Steel 202 Grade
• Base Cover: Mild Steel Sheet
• Base Plate: Mild Steel Sheet
• Door: Stainless Steel 202 Grade with Lock
• Spring: Helical Extension
• Spring Adjustment: Screw Rod
• Nuts, Bolts And Connectors: Mild Steel
• Control Box: Stainless Steel 202 Grade
• Cutting: CNC
• Bending: CNC
• Welding: MIG/TIG
• Overall Finish: Gloss with Powder Coated
• Logo: Standard Sticker
• Dry Weight in Kg: 30
• Drum RPM: 1000
• Drum Volume in Liter: 115
• Liquor Ratio: 01:04.5
• Over All Dimension in mm: 940 x 1140 x 1100
• Door Open Dia in mm: 540
• Drain Outlet in mm: 75
• Centrifugal Effect (%): 70-75
• Foundation: Required
• Weight in Kgs: 400
• Motor Power in kw: 4

• Capacity: 30 KGS
• Automation Grade: Semi-Automatic
• Application: Industrial
• Drive Motor: NON CO AXIAL
• Diameter: 1450mm
• Motor Power: 3 hp
• Features: Accurate results, Sturdy construction, Accurate dimensions

• Model Name: ENH15
• Capacity in Kgs: 15
• Basket size dia*depth (mm) liter: (550*300) /71
• Basket Rotation (RPM): 800
• Centrifugal Effect: 70 to 75 %
• Electric Power (H.P): 2

EcoStar Hydro Extractor Non Co – AXIAL Features: Appearance: It is highly compact and requires only less maintenance, three leg suspension model Construction: outer and inner part made up with stainless Steel which is 304 Grade. Salient Features: Our Ecostar Hydro Extractor has Mechanical braking systems Purely running under the centrifugal mechanism. Whether pulling in 70%, make sure very little moisture preservation. The internal parts of the rotating perforated basket are dynamically well balanced and the body of the structure is made up of highly graded graded cast iron provided with heavy duty steel springs that ensure less vibration.

We are offering commercial hydro extractor with the assistance of skilled and dedicated professionals, we supply and import wide array of commercial hydro extractor. These products extensively utilized in hospital, bleaching and dyeing factories, laundry, hostel large and medium scale service industries. Our products are configured with advanced technologies and methods thereby assisting us to maintain distinguish position in the market. features: the aisi 304 grade stainless steel inner and outer drum ensure safety and durability 3 leg suspension structure ensures efficiency and good anti-vibration well equipped with starting wheel to protect the motor
