Wireless Motion Detector Dealers in Udaipur

Walnut Innovations PIR Motion sensor Switch This PIR Motion Sensor is a new type of Energy-Saving light control switch. It works by detecting heat rays emitted by the human body. Auto switching of lights or other fixtures based on human occupancy in residential and commercial buildings. Security systems for triggering of Buzzers or switching on CameraDVR when human motion is detected. TECHNICAL DETAILS : Operating voltage: AC 220-250V 50Hz-60Hz Operating temperature: -20C~+50C PRODUCT INSTALLATION : 1. In order to achieve effective Sensing distance, please keep the switch 1.5 meters high from the ground. 2. The light, such as incandescent lamp which emits high heat should be kept from the switch, at least one meter 3.During installation first time, the switch' initialization will take 30-50 sec. It's natural for the switch to turn onoff voluntarily. 4. When you install the switch on daytime, adjusted to SUN (max), it will work day and night, & when adjusted to MOON (min) it will be work only in the ambient light less than 3LUX means work only in night time or in dark .

• CW/WW/NW: Aluminium Die Cast

We are offering occupancy sensors 90-270v ac.

The product adopts good sensitivity detector, integrated circuit. It gathers automatism, convenient safe, saving-energy and practical functions. It utilizes the infrared energy from human as control-signal source, it can start the load at once when one enters detection field. It can identify day and night automatically. It is easy to install and used widely. Specification:Detection Range:360degree2.Rated Load:max.1200W3.Detection Distance: max.6m4.Time Delay:10sec to 7min(adjustable)FunctionIdentify day and night automatically. Can adjust ambient light according to your desire: when turn to SUN (max), it will work in the daytime and at night. When turn to MOON (min), it will only work under less than 3LUX circumstance. As for Adjustment, please refer to testing way. Time-delay is added continually: when it receives the second induction signal after the first inductor, it will compute time once more on the rest of the first time-delay basic (Set time) . Time-delay adjustment: it can be set according to your desire. The minimum is 10±3 sec; the maximum is 7±2min. Installation:Turn off the power. Moving the transparent vinyl cover what is in the bottom of the sensor. Loosing the screws in the connection terminal, connecting the power and rated load to connection terminal of sensor according to connection sketch map. Tighten the screws; put the transparent vinyl cover into the original station. Folding the metal spring of the sensor to upwards, until they are in "I" position with sensor, then put the sensor into the hole or installation box what is in the ceiling, the size is similar with item. Releasing the spring, the sensor will be set in this installation position. After finishing installing, the sensor could be connected the power and testing it.

• efficiency over: 120LM/W.

This product adopts microwave technology, to test ambient movement intelligently, auto-adjust work state, so no ambient temperature nor noise interruption, performance is better than the PIR sensor, sound-control switch and the touch switch. Sensor should be placed parallel to the ground when installation, to make sure the most sensitivity. Sensor against the metal block in front of it.

• Output: Relay
• Size: 76(H)x76(D) mm With IR Remote
• Weight: 91gms

Features: 360 Degree-Flush mount,micro motion detectable. Photo sensor inside for smart control Run-on time adjustable Ambient lux, setting adjustable 2000 W / 625 W loading Can Support IR remote Control also for On/ Off / Auto Control Detection range: 6m for micro motion @2.5height and 12m for walk across motion@ 5 height Warm up time: Approximately 1minute

Motion Sensor - Microwave, WiFi USB Stick 32GB - DM WFD020
