Automatic Sealing Machine Dealers in Vadodara

• Direction Of Movement: Left to Right.
• Packaging Type: Packet
• Height of Conveyor**: 860 mm to 910 mm.
• Electrical Specification – Main Motor: 300 Watt, Magnetic coil.
• Electrical Specification - Cap Feeding Bowl: 1 HP / 415 Volts / 50 Hz.
• No. of Sealing Head: 1 Nos.
• Output/Hour*: 1000 to 3000 bottles.
• Model: KEF-60

Depends on bottle size, cap size and type of cap. ** We can supply as per customer requirements. *** With help of change parts. Description: The Automatic Cap Sealing Machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine. Operation: The feed container moving on conveyor belt are fed into star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the bottle pickup a cap from the delivery chute of cap feeding bowl, where the body and the neck of the container are positioned below the rotating head. Where the sealing head is performing perfect operation of threading & sealing.   Salient Features: No container No cap arrangement. SS elegantly matt finished body. Single motor synchronizes conveyor, star wheel, & platform turret. Adjustable height of conveyor belt, to align with other machine of the line. Sealing pressure can be varied to suit different gauges and size of caps. Low noise level, low power consumptions. Self-lubricating UHMW- PE guide profile for low friction wears surface, smooth and noiseless conveying. SS cladding or hard chrome platting of all exposed parts to ensure long life and resistance against corrosion. Synchronized A/C drives to synchronize, Conveyor, Star wheel and Platform turret & capping bowl. Adjustable bottle height gauge for easy and quick setting.

We are offering fully automatic induction sealing machine. Voltage - 110 / 220 v (50-60hz) power - 1.5 kw capacity - 0-10 m/min sealing diameter - 20– 50 mm machine weight - 38 kgs machine size - 1150 × 480 × 400 mm.

Industrial model Motorized incorporating rotating, threading, sealing rollers, two rollers type, one for sealing other for threading with 22 dia., 25 Dia. and 28 Dia. cap size socket. Machine for sealing of 22 mm to 38 mm cap size The machine works on 0.5 H.P. 440 volt motor drive with Acrylic Shield, Belt Guard, 'V' Belt pulley and ON-OFF Switch. All M.S. parts are Chrome plated and body cladded by S.S. 304 sheet. Foot Paddle Model   :  Bottle lifted by operator with foot Base Lifting Model   :   Bottle lifted by came mechanism. Semi Automatic Model   :   Sealing head up & down mechanism.

Fully Automatic Heat Sealing Machines, Knurled PET Straps

Automatic Sealing Machine, Automatic Cutting Machine

Automatic Sealing Machine, electric sealing machine
