Digital Flow Meter Dealers in Vadodara

• Line Size: 1’’ to 12 Inches
• Material: Aluminum
• Color: Blue
• Driven Type: Electric
• Warrenty: 1 Year
• Automatic Grade: Automatic
• Supply Voltage: 230 V ac

descriptiondigital water flow meter as per cgwa compliance  electromagnetic flow meterdigital flow meter with telemetry as per cgwa guidelinesinstallation of digital water flow meter on ground water abstraction structures whereas the central government constituted the central ground water authority (hereinafter referred to as the authority) vide notification number s.o. 38(e), dated 14th january, 1997, followed by notification number s.o. 1124(e) dated 6th november, 2000 and s.o. 1121 (e) dated 13th may, 2010 of the government of india in the ministry of environment & forests, for the purposes of regulation and control of ground water development and management in the whole of india and to issue necessary regulatory directions. and whereas the authority has issued ‘guidelines to control and regulate ground water extraction in india’ vide notification number 3289(e) dated 24th september, 2020, wherein under section 9 (i) “installation of digital water flow meter (conforming to bis/ is standards)  having telemetry system in the abstraction structure(s) shall be mandatory for all usersseeking no objection certificate and intimation regarding their installation shall be communicated to the cgwa within 30 days of grant of no objection certificate through the web-portal.”this is to bring to the notice of all ground water users that : all the project proponents/users drawing ground water and seeking/having noc shall have to mandatorily install tamper-proof digital water flow meters with telemetry on all the ground water abstraction structures within their premises. all the micro and small enterprises drawing less than 10 cum/day shall also be mandatorily required to install digital water flow meters on all the ground water abstraction structures within their premises. such enterprises shall be subjected to randomised inspections.the afore-mentioned conditions need to be strictly followed by all the users and any ground water withdrawal without the installation of tamper-proof digital water flow meters and telemetry (wherever applicable) shall be construed as illegal. non-compliance of these conditions shall invite a penalty provision and/or environmental compensation against the proponent for illegal withdrawal of ground water as per the cgwa guidelines and may result in cancellation/rejection of noc and sealing of ground water abstraction structures.

• Display: Digital
• Brand Name: Flowtech
• Material: SS
• Accuracy: 0.25%
• Item Code: EMFMBO-099
• Application Media: Water
• Model: EMFMBO-099
• Application: Industrial
• Fluid Temp: 150 Deg C
• Temperature: up to 150 Deg C

• Flowmeter: Electromag

“kabir” make versatile electromagnetic flow meter is ideal for conductive liquids such as raw water, chilled water, effluents, potable water etc. Using time proven electromagnetic flow metering principle, the meter achieves a flow meter for pipes from 15mm to 600mm. Since there are no moving parts, the flow meter gives years of maintenance free service. “kabir” flow-head can be supplied in teflon lining or hard rubber lining is available with all the features required in a field mounted water metering equipments. These include - weather proof enclosure, communication options, rtc with data logging with printer option and 4 to 20 ma isolated flow signal transmission option for flow pattern recording. The converter is available as field mounted-ip65 protection category. Gsm modem interface can also be supplied as an optional add-on feature. the operating principle of magnetic flow meters is based upon faraday's law of electromagnetic induction, “it state that a voltage will be induced in a conductor moving through a magnetic field”. The magnitude of the induced voltage e is directly proportional to the velocity of the conductor width d, and the strength of the magnetic field b. Liquid acts as a conductor as it flows through pipes. This flowmeters find varied applications where the flowing medium is difficult to handle. Major advantage of these flow meters are : zero pressure drop, no moving part and highest accuracy level at most affordable cost.

This is working on the principle of Faraday's law which states that when a conductor moves through a magnetic field of a given strength a voltage is produced in the conductor and proportion to the relative velocity between the conductor and the magnetic field. Digital Flow Meter Has A Wide Range Of Application In Many Industries Like: Petroleum Products Acid & Alkaline Solutions Edible Oil Food Stuff Liquids of high viscosity Pains & Varnishes Corrosive liquids Chemicals Effluents water Salient Features Of The Flowtech Digital Flow Meters: Nominal diameter from 15mm to 400mm for a wide range of purposes. The material of Construction used is like MS, SS 304, and SS 316 & SS 316L for maximum life and durability. Accuracy : ± 1% FSD Optional: ±0.5% FSD Protection Class for Sensor : IP 65 Incline Flange Type of Installation Cable Length for Remote : 10 meters Repeatability : 0.3% Power Supply : 230 VAC, 110 VAC & 24 VDC Output: Std. 4 – 20 mA

• Voltage: Power: 60-265 VAC,24 VDC,3.6 V Lithium Battery
• Country of Origin: Made in India
• Material: Stainless Steel
• Display: Analog, Digital
• Accuracy: +- 0.5 % and +- 0.2 %
• Item Code: MAG-3000-01
• Communication: Output: Standard output 4-20 mA,RS485 Option: RS232,HART
• Electrode Material: SS 316L,Titanium,Tantalum,Hastelloy,,Platinum,SS Duplex
• Electronics Enclosure: Enclosure: weather proof IP67
• Diameter (mm): 10-3000 mm
• Working pressure (kg/cm2): 12,18,26,42 kg/cm2
• Min. Conductivity: 5 Micro Simens
• Model Name/Number: MAG-3000
• Brand: PETROTECH
• Usage/Application: WATER, ETP,CHEMICAL
