Flow Meter Dealers in Vadodara

• Material: Mild Steel
• Color: White
• Finishing: Powder Coated
• Shape: Round
• Usage: Industrial, Water And Chemicals
• Country of Origin: India
• Brand Name: Cryogenic Liquide

Turbine Flow Straightener Generally in pipelines pumps , piping bends, vibrations, control valves will generate swirl. Any swirl present in the fluid which enters into turbine meter can change the effective angle of engagement and hence deviation in the reading will take place and false reading will be take place. so it is required to install flow straightener before turbine meter to minimize liquid rotation , the swirl effect of the fluid After passing through the turbine meter the fluid enters into the downstream of the flow meter which is 5D flow straightener which controls any swirl existence on the rotor. It is good practice to keep minimum straight run of pipe 10 times diameter of pipeline at upstream of turbine meter and 5 times diameter of pipeline at downstream of turbine meter. Construction As this 10 D upstream flow straightener is 2 to 3 D upstream plenum then 2 to 3 D tube bundle with 7 or 19 nos stainless steel tubes with again 5D downstream plenum. 5D downstream flow straightener consists of simple piping. With optional port for pressure , temperature measurement. Turbine Flow Straightener

Description: our full bore meter is a cost effective flow meter for conductive liquids such as raw water, effluents, potable water and industrial chemical. Using time proven electromagnetic flow metering principle, our flow meters are available for pipes from ½” nb to 6” nb. Since there are no moving parts, the flow meter gives years of maintenance free service. Its performance is independence of temperature, pressure, density and viscosity of medium. The flow meter is obstruction less and hence the pressure drop is almost negligible. it has all the features required in field mountable metering equipment. These include-weather proof / flame proof enclosure, rs485 communication option , with 4 to 20 ma isolated current output for flow signal transmission option for process control. The converter is available as field mounted – ip65 protection category. An optional batching controller also available on request. electro magnetic flow meters. it works on faraday’s law of electromagnetic induction. A magnetic field is generated by magnetic coil. The fluid flowing through this magnetic field generates emf (voltage) which is proportional to the flow velocity. This emf is measured by the electrodes giving corresponding output. used for precision measurement of any conducting liquid or slurry that is flowing in closed pipes. high accuracy flow metering optional digital transmission 2 line alpha numeric back lit display no pressure drops in process. line size 15 nb to 300 nb accuracy = 1% of reading flow range 0.5 to 10 m/s easy maintenance as no moving parts min.conductivity : 5 us/cm output :4-20 ma,relay and rs485 protection : cast aluminum lp65 field / wall mounted process temp: + 150 degree max. lining : ptfe / rubber / pp

We are an affluent Manufacturer, Exporter and Supplier of PFA Lined Double Window Sight Flow Indicator in Gujarat, India. Our Sight Flow Indicator is fabricated under the supervision of experienced professionals assuring the finest quality. We make available Window Sight Flow Indicator in different sizes and with technical specifications in order to ensure longer functional life. We believe in delivering PFA Lined Flow Indicator within the committed time frame.   Description : It provides clear inspection of fluid characteristics of severely corrosive liquid from either side. PFA/FEP Lining offers highest corrosion resistance. Minimum lining thickness of 3mm, lining locked by multiple locking grooves. It has Full port design minimizes pressure losses and increases flow capacities thus reducing energy and pumping costs. Sight Flow Indicators are made up to Ductile Iron Casting as per ASTM A 395 Gr 60-40-18. Motion flow and color can be inspected visually during the process since this indicator is equipped with two tempered Toughened glass windows for ANSI Class 150 Service.

• Brand Name: KABIR
• Material: PP,MS,SS
• Application: LIQUID
• Pressure: 20KG - 150 KG
• Model Number: DWSG
• Place of Origin: VADODARA

Kabir manufactures sight flow indicators which are most commonly used for monitoring liquid flow in pipelines without compromising the integrity of the piping system. Visual observation and supervision of the process flow stream are two of the main concerns. Single double window constructions, sight flow indicators are available in various figures & material. Cs ss made bodies with toughened borosilicate glass windows and standard units in flanged threaded connections provide immunity at higher temperature & pressures. These offer a quick, reliable and inexpensive way to affirm flow rate and direction, and monitor color and clarity in fluid lines. Different construction & sizes, highly economical, versatile uses. easy - access bolt - on design. Used for major liquids. toughened glasses. no-leak guaranteed. When a problem occurs at certain points along the industrial process line, sight flow indicators are used to visually monitor and determine the flow of fluids. These affordable and easy-to-operate devices are installed directly in the process line and allow operators to qualitatively observe flow rate, direction, color and clarity. The readings are then viewed through a glass viewing lens. There are two ways to deploy sight flow indicators: type : glass window liquid flow indication temperature : 300 º c pressure : 20 kgcm² line size : up to 8 inches (200 mm) moc : cs ss glass : toughened glass version : double single window viewing or full view. Connection : flanged threaded.the basic applications of sight flow indicators are spread across several industries and include measuring levels of water, condensate, coolant, diesel, solvent, chemicals, alcohol, lube

Thi Digital Moisture Meter can be used for measuring moisture content of various oil seeds like Ground Nut Seed, Cotton Seed, Cadtor Seed etc.

• Brand Name: Optima
• Display: Analog, Digital
• Connection: Flange end and screw end or sandwich type
• Accuracy (%): 0.5 %
• Communication: RS 485
• Diameter (mm): 15 mm to 800 mm and more
• Electrode Material: HAste Alloy C or SS 316L or Titanium

• Brand Name: Shivam Instrument & Calibration
• Accuracy: 0.2 - 0.5 %
• Material: MS
• Operating Temperature: 1 to 80 Deg C
• MOQ: As per Requirment
• Quality: Optimum Quality

• Country of Origin: Made in India
• Display: Analog
• Brand Name: Flowtech
• Application Media: Liquid
• Line Size: 4 Inch
• Accuracy: 0.5 %
• Temperature Ratings: -20 to 120 Deg. C

• Feature: Non-interchangeable specific gas / vacuum probes etc.
• Material:: ABS, Brass
• Medical gas include:: Vacuum, O2
• Test:: 100% air tightness tested
• Distinguish:: Cording to ISO32 Color standard
•   Extra facilities   available:   A Disk valve has been provided   At the base of each outlet   valve For easy maintenance.
• Lock type:   Single

Pantech Instrument’s Model 845S represents FLOW INDICATORS TOTALIZERS CONTROLLERS for mass flow applications related to STEAMS flow. The instrument is so designed to accept 3 inputs of FLOW, PRESSURE and TEMPERATURE at a time. Based on these inputs, and high end algorithms of STEAM TABLES fed in the chip, the instrument calculates MASS INSTANTANEOUS FLOW RATE to a resolution of 44.5 digits.

• Size: Multisizes
• Output: 4-20mA/HART/Relay/Batching/GSM/Data Logging
• Cable length: Up to 50 m / 164 ft
• Size :: 1” to 10”
• Accuracy :: ±2.5% to 3% of actual reading
• Gas Temperature :: Up to 70°C
• Power Supply :: 85 to 265 VAC @ 50Hz

DescriptionAllegiance Digital  Electromagnetic Water  Flow Meter, 80 mm (3 Inch) simply known as mag flow meter is a volumetric flow meter which is ideally used for waste water applications and other applications that experience low pressure drop and with appropriate liquid conductivity required.The device doesn’t have any moving parts and cannot work with hydrocarbons and distilled water. Mag flow meters are also easy to maintain.Magnetic flow meters works based on Faraday’s Law of Electromagnetic Induction. According to this principle, when a conductive medium passes through a magnetic field B, a voltage E is generated which is proportional to the velocity v of the medium, the density of the magnetic field and the length of the conductor.In a magnetic flow meter, a current is applied to wire coils mounted within or outside the meter body to generate a magnetic field. The liquid flowing through the pipe acts as the conductor and this induces a voltage which is proportional to the average flow velocity.This voltage is detected by sensing electrodes mounted in the Magflow meter body and sent to a transmitter which calculates the volumetric flow rate based on the pipe dimensions.Mathematically, we can state Faraday’s law asE is proportional to V x B x L[E is the voltage generated in a conductor, V is the velocity of the conductor, B is the magnetic field strength and L is the length of the conductor].It is very important that the liquid flow that is to be measured using the magnetic flow meter must be electrically conductive. The Faraday’s Law indicates that the signal voltage (E) is dependent on the average liquid velocity (V), the length of the conductor (D) and the magnetic field strength (B). The magnetic field will thus be established in the cross-section of the tube.Basically when the conductive liquid flows through the magnetic field, voltage is induced. To measure this generated voltage (which is proportional to the velocity of the flowing liquid), two stainless steel electrodes are used which are mounted opposite each other.The two electrodes which are placed inside the flow meter are then connected to an advanced electronic circuit that has the ability to process the signal. The processed signal is fed into the microprocessor that calculates the volumetric flow of the liquidPrinciple of Magnetic Flow Meter Based on Faraday’s LawAllegiance Water Management Electromagnetic Flow Meter Clamp On Ultrasonic Flow Meter S.S Electromagnetic Flow Meter Open Chenal Ultrasonic Flow Meter Vortex Flow Meter Instrumentation Tools Turbine Flow Meter by Membrane Key Digital water Flowmeter Telemetry Digital water Flowmeter Non Telemetry Digital water Flowmeter as per CGWA   Digital water Flowmeter

Pulse Transmitter   Generates Pulses to convert a revolutory motion into  electrical pulses proportional to the number of revolutions   Features:   Generates Dual pulses for one complete revolution.   Complies to Level A pulse security   Can be fitted to all PD meters with customised  couplings   PESO Approved.

• Material: PP
• Application: Level Indicator
• Color: Grey, Black
• Application Media: Water
• Set Of: 2 Piece

• Brand Name: Hesham
• Material: Aluminum
• Shape: Round
• Weight: 100-200kg
• Color: Black
• Line Size: 1''

We are offering industrial pumps supplier, blower supplier, mechanical seal supplier, flowmeter supplier, coupling supplier in gujarat, packings & gaskets supplier, pipes & fittings suppliers, pvcpepp pipeline machinery supplier, powercontrol panel supplier, dies and moulds supplier, high speed mixers supplier, canned pump supplier, acid transfer pump supplier, slurry transfer pump supplier, monoblock pump supplier supplier, knife gate valve supplier, tripple screw pump supplier, progressive cavity pump supplier, check valve supplier, pvdf pump supplier, flow meter.

• Material: Plastic Body
• Display: Analog
• Accuracy: 99.9%
• Packaging Type: Box
• Type: Non invasive
• Weight: 125gm
• Brand: Ishnee
• Application Media: Used to measure how air flows from your lungs in one "fast blast
• Usage/Application: Medical and Hospital
• Flow Range: 0-800
• Power Supply: No
• Model Name/Number: IN-108 A
• Body Material: Plastic
• Connection: Nil
•  :

• Application: Industrial
• Pattern: Plain
• Pressure: Medium Pressure
• Feature: Durable, Investment Casting
• Size: 1" to 12"
• Available M.O.C: PP Polypropylene

Mechanical volumetric flow-meter for private use, with mutating-disc type chamber for flow up to 120 Imin. It can be installed for gravitational feeding, as well as for hand operated or electric transfer pumps with by-pass arrangement. Suitable for Diesel Fuel, Gasoline, Kerosene, Methanol.

• Display: Analog
• Usage/Application: Gas
• Flow Range: 1-15L/min
• Output Pressure: 0.2-0.3Mpa
• Size: Standard
• Gas Type: Oxygen

Wittemann is engaged in the manufacturing and designing of Turbine Flow Meters, which are renowned for their smooth functioning. Clients’ huge demand has statured us on the top among the listed manufacturers and exporters of Turbine Flow Meter. Features : Complete line of vortex, coriolis and turbine flow metersAccessories for accurate measuringsHigh pressure gasLiquid carbon dioxide streamsCan be supplied with local indicationTantalizationTransmittersAlarm triggers or process controllers Applications : Distilling IndustryBeverage IndustryBrewing IndustryIndustry Gas Industry

• Brand Name: NRG GLOBAL
• Material: Stainless Steel
• Finishing: Powder Coated
• Driven Type: Electric
• Power: 12 To 24 VDC Or VAC
• Pressure: Low Pressure
• Operating Type: Manual
• Usage: Industrial
• Voltage: 220V
• Certificate: CE Certified
• Line Size: 4-20mm, 20-50mm
• Specialities: Accuracy

• Brand Name: PRIMA
• Material: Cast Aluminium
• Pressure: 10 Kg/cm2 (more on request)
• Operating Temperature: 2-50°C
• Accuracy: + 0.5 – 0.2 % of F.S
• Country of Origin: India
• Display: Digital

Introduction: Electromagnetic flowmeters accurately measure the flow rate of conducting liquids or slurries flowing in closed pipes. Due to its simple and proper design, the electromagnetic flowmeter is an obstruction less & maintenance-free instrument in place of the conventional mechanical flow measuring device. The use of “Pulsed DC” technology offers the highest ability & better measuring accuracy in the form of 4-20mA DC output linearly proportional to the volumetric flow.Applications:Effluent Treatment Plants, Sewage Treatment plants, Water Supply Schemes, Steel & Aluminium, Pulp & Paper, Chemical & Fertilizers Food & Drugs, Pumps Valve, Calibration Lab, Dairy Industry, Corrosive Liquid, Municipal Corporation, Sugar Industry, Textile Industries, Dyeing & Printing, Hotels & Resorts, Water Parks, and Buildings & Infrastructure.Features: Size DIN 10 to DIN 3000 NB pipeline. High accuracy better than + 0.5% of reading. Zero Pressure Drop. Suitable for High Viscosity Conductive Liquids. Digital Flow rate/ Totalizer Indication/ Batching system. Isolated Transmitting Output 4-20 mA. No Grounding Ring is required. Minimum Upstream & Downstream Straight Length. Compact & Rugged, IP 65 Protection. Remote Flow Indication Totalizer/ batching System through GSM Modem.

In order to attain complete client credibility, we let the clients' to choose either online mode or offline mode for making payment. And, we guarantee for authenticity and confidentiality. Be it seasonal supply, wholesale supply or quick delivery, we are capable of entertaining all your requirements as we have state-of-the-art storage space to keep the stacks of the products in an organized manner.

• Country of Origin: India
• Type: Analog Type Rotameter, Megnatic Flow Meter
• Material: Metal
• Warrenty: 1 Year
• Finishing: Polished
• Application: Industrial
• Packaging Type: Carton Box

• Size: 4/5inch
• Color: Silver
• Pattern: Plain
• Pressure: High Pressure, Low Pressure, Medium Pressure
• Feature: Casting Approved, Easy Maintenance., Smooth Finish And Robust Design
• Application: Industrial, Laboratory
• Feature: Durable, High quality, Reasonable price
• Material: Glass, Metal
• Temperature: Up To 750 Deg C
• Voltage: 220 V
• Finishing: Polished
• Texture: Plain
• Weight: 230-750gm
