Level Indicator Dealers in Vadodara

• Size: 500MM - 3000MM
• Brand Name: KABIR
• Material: SS
• Color: BLUE
• Model Number: TMMLI-09
• Place of Origin: VADODARA

Owing to our high experience in this industry, we are recognized as the best manufacturer and supplier of Top Mounted Magnetic Level Indicator from Vadodara, Gujarat. This Level Indicator uses simple principle of mechanics and magnetic harness to offer precise and accurate level indication. This Level Indicator can be used for dangerous liquids under high pressure and temperature. This Level Indicator comprises of a float, an SS enclosure and a magnetic capsule design. The Magnetic Level Indicator we offer can be used along with high and low level alarm switches.   Notes : With High and Low Level Alarm Level Switch With 4-20 Ma Out Put Level Tranmitter with Digital Indication in Mm Minimum Nozzle Size Required 4" Nb Forliquids Below 0.8 Density

• Country of Origin: India
• Type: Water Level Indicator
• Condition: New
• Warranty: 1 Year
• Usage: Industrial
• Packing: Box Packing

Application Level Mesurement

We are offering tubular level indicator. flowtech make heavy duty tubular liquid level indicator is a simple & reliable device for direct reading in atmospheric or pressurized tank application. These indicators eliminates trouble giving threaded joints of conventional gauge glass cock as hazardous damage surrounding equipments & also endanger human life. 1. the top & bottom liquid chamber of indicator is made of solid bar & glass tube (borosilicate) is fully protected by box section made out of 2 mm thick m.s. Channel. The strength of the box is so good that even if a man stands on the indicator, supported at both ends, the tube remains intact. 2. .we are using 100% ptfe (teflon) rope as packing to ensure positive leak tightness for full vacuum as well as 6 kg / cm service pressure. 3. as compare to reflex & transparent type level gauge, this tubular level indicator is light in weight. 4. it is available in single length of 2000 mm c/c distance. We can extend the length by coupling 2 or more through coupler. 5. we are providing air vent plug at top & drain plug at bottom for taking sample. We can also provide inbuilt isolation valve on request. 6. it is simple and reliable device for direct reading in atmospheric or pressurized (below 5 kg/cm2) tank application. 7. it eliminates trouble giving threaded joints of conventional gauge glass cock as hazardous chemicals start leaking. 8. glass tube (borosilicate boiler quality) is fully protected by guard rods or box section made of 'c' – channel. 9. offset constructed isolation valve on request. 10. the connection provided will be flanged / screwed / tc joint.

• Brand Name: Optima
• Material: ABS
• Mass: 140 gm
• Protection Degree: IP54

We offer the Level Indicator, which is a self-contained cage designed for use with our top mounting level transmitters or switches. The Level Indicator, which we offer, is constructed using high-grade material that adds and a wide selection of configurations make this cage an ideal means of utilizing the power of our many technologies without mounting directly into the process vessel. Technical Specifications : MOC : SS 316L / SS 316 / SS 304 / BrassProcess Connection : Flange End #150 / #300Vent / Drain : ½ NPT(F), ¾ NPT(F)Dish End : 2�,3� ,4�Gasket : As per RequirementCertification : Corrosion Test - ASTM A262, Prac E/ IBR

• Application: LIQUID
• Material: SS304
• Country of Origin: India
• CC Distance: 300

NRG GLOBAL INSTRUMENTS MAKE TUBULAR LEVEL INDICATOR The Indicator is fitted between two end blocks through gland packings. The indicator is mounted parallel to tank so as to form a close loop causing tank liquid to seek its level in the gauge. Guards are provided in the form of Tie-rods for 360 visibility or C- channels around the gauge to protect it from accidental blows. Glass removal for replacement possible w/o dismantling the gauge. 100% PTFE bush as packing to ensure positive leak tightness for full vacuum as well as 6 kg/cm service pressure. It is available in single length of 2000mm c/c distance. We can extend the length by coupling 2 or more through coupler. We are providing Air Vent plug at top & drain plug at bottom for taking sample. We can also provide inbuilt isolation valve or offset constructed isolation valve on request. The connection provided will be Flanged/Screwed/TC joint.

• Color: Yellow
• Item model number: 022A
• Dimensions: 9.25 x 2.63 x 5.06 inches; 15.52 Ounces

• Material: SS
• Application: Industrial
• Country of Origin: Made in India
• Brand Name: Flowtech
• Item Code: FBLI-65
• Fluid Type: Liquid
• Model: FBLI-0913
• Material Grade: SS304

• Type: Manually
• Application: Controls Water Level
• Weight: 10-20kg
• Color: Blue
• Voltage: 110V
• Condition: New
• Display Type: Digital
• Power: 1-3kw, 6-9kw, 9-12kw
• Warranty: 1year

Description Allegiance Water Level Indicator Flat tape water level Indicator Enhanced Laser Marked Tape Features Durable PVDF non-stretch tape Improved electrical properties Thicker dog bone design prevents clinging to sides of the well Permanently laser marked every 1/100 ft or each mm The PVDF flat tape is laser marked every 1/100 ft or each mm; lengths up to 5000 ft (1500 m). New flat tape has increased tensile strength and electrical efficiency by using 6 strands of copper coated stainless steel and 13 strands of stainless steel in each conductor. The P7 Water Level Meter Probe is engineered to allow submersion to 1000 ft. (300 m). Sensor at the tip of the probe provides

• Material: Alloy Steel
• Color: Black
• Automatic Grade: Manual
• Feature: Accuracy, Measure Fast Reading
• Size: 1/2" 1"
• Available M.O.C: PP Polypropylene

We offer our customers, Oil Level Indicators which is used in the greasing/ oil system and gear to see the lubricating oil levels in the concerned equipment. Magnetic gauge of these is made using quality raw material, ensuring accurate measurement of the oil level. With the help of our professionals, we are also able to custom design our range as per the specifications of our eminent customers. sigma constant oil lavel indicator consists of a borosilicate glass  dome with suitable alluminim alloy base /carbon steel/stain less steel and elbow to fit your equipment. borosilicate glass has the advantage of extraordinary impact strength,excellent clarity and good temperature range ie upto 250*c   moc : Alluminium /carbon steel/satin less steel (ss 304/316).conn : 1/4' bsp (m) with lock nut bowl : Boro silicatecapacity : 250 ml

Our Float & Board Type Level Indicator, is listed among the must have Tank Level Indicators available in the market because of its unique construction designs. Ideally suited for fluid with specific gravity of 0.6, our Float & Board Type Level Indicator, has been very popular among our clients. Material of Construction : S.S.304S.S.316 P.P.Teflon Working : Works upon the specific gravity of the liquid principlePointer is connected to a pointer through Rope via a Sets of Pulleys Design Features : Offers vapor Seal Type float & Board type level GaugeThe float is connected to a magnetized counter weight moving in a sealed S.S. pipeMagnetized bi - colour capsule inside a glass tube to indicate liquid level Widely used for : Tanks having corrosive fumes / vapors OR N 2 [Nitrogen]Purging tanks Specifications FloatS.S.316 / S.S.304 / Poly PropyleneFloat Wire & Float Guide WireS.S.316 / Poly Propylene Pulley & Pulley Pin M.S. / S.S.304Pulley HousingAluminium / S.S.304 / S.S.316 die Cast weather Proof Enclosure of Weather ProofBoard (Scale)Aluminium with Powder Coated having 150 mm Width & White Back Ground & Black writing at every 10CMAnchor PlateM.S / S.S.304 / S.S.316Scale Bracket (T)M.S. / S.S.304PointerM.S / S.S.304 with PP Roller for Frictionless Sliding On Board.AvailableFrom 1 Metre to 20 Metre

• Country of Origin: Made in India
• Material: MS,SS 304,SS 316,PP,PVDF
• Item Code: TLG-15-01
• Phase: single
• I Deal In: New Only
• Construction: C- Channel,Tie Road
• Glass Material and Size: Borosilicate tube in OD of 12,16,19 and 25mm
• Maximum Pressure And Temp: 10 Kg/cm2 and 100 Deg C
• Wetted Part Material: CS,ASTM A 105,SS 304,SS 316L
• Usage/Application: Industrial
• Brand: PETROTECH
• Type: Glass

Magnetic Level Indicator manufacturer in India. These Level Indicators are flanged to the tank for indicating level of liquids and liquefied gases in open or closed tanks. These can be used in high temperature and pressure applications or if sight glasses and similar indicating glass parts cannot be used for safety reasons. This instrument is preferred because there is a safe pressure and gas tight separation between measuring and indicating parts. Thus the MAGNETIC LEVEL INDICATOR is suitable for a wide range of applications for the chemicals, pharmaceutical industries, petrochemical industries, refineries, oil and fuel tanks etc.

The "KiT" make tubular Level Indicator (Side Mounted) .It is a reliable device for reading the level of liquid. It is a simplest form of level indicator. These level indicators find wide application for level measurement in process tanks, batching tanks, vessels etc.

Product Specification   FULLY AUTOMATIC WATER LEVEL INDICATOR USING MAGNET SENSORS. Indicates five levels of the tank. Each level can be indicated in percentage or can be re-callibrated in 'liters' or in 'feet'. MAGNET SENSOR MEANS MOST ADVANCE TECHNOLOGY : MAGNET SENSORS  USED TO CHECK THE LEVEL OF WATER ARE SHOCK PROOF, RUST FREE & THERE IS NO POSSIBILITY OF SALT DEPOSITION ON  IT. ............MOST USEFUL FOR LARGE TANKS OF TOWNSHIP OR SOCIETY OR MUNICIPAL CORPORATION........

FIS provide an effective way to view the condition of liquids or solids flowing through pipelines at most any Flow, Pressure, or Temperature

Float devices use the buoyancy of a float to indicate the liquid level in the tank. The chain is attached to a counterweight which indicates the level as the float moves up and down. These types of devices are often found on atmospheric storage tanks in OEMS, Petroleum & Pharmacy Industry and the specific gravity of the fluid should be more than 0.6 like oil tanks, large Acid tanks and the storage tanks of storage tanks of Oil, Fire / DM water Alkalis, Acids furnace Oils, Lube Oil, Vegetable Oil, Molasses, Glucose etc. Flowtech is the leading manufacturer of float & Board level indicators in India and supplies its products to not just all major states of India but many overseas countries as well. The float we design as per the specific gravity of the liquid, floating on the liquid levels. The float connected to a pointer through Rope via a Sets of Pulleys, The pointer slides over a CM marked Board, Installed Parallel to the tank. For more than 3 meter height of the tank, we provide two guide wires firmly anchored to the tank bottom. So that horizontal movement of the float is restricted. Salient Features Of The Float & Board Level Indicators By Flowtech Are: Flowtech float & Board level indicators are available in different materials S.S.304/S.S.316/P.P./Teflon etc. Flowtech offers vapor Seal Type float & Board type level Gauge which is generally used for tanks having corrosive fumes/vapors OR N­2 [Nitrogen] Purging tanks. The float is connected to a magnetized counterweight moving in a sealed S.S. pipe & which drives a follower magnetized bicolor capsule inside a glass tube to indicate liquid level. The pointer of the level indicator moves on a 150 mm width aluminum powder coated scale. Vapors seals (Magnetic) for special applications like HCl, N2 purged tank, dilute alkalis, dilute HNO3, NH3 Methanol, Benzene, Toluene, IPA etc. In vapor seal, there are no sealing liquids so we get absolute vapor tightness.

• Output Signal: 4-20mA
• Accuracy: 0.1 %
• Compensated Temperature Range:: 0 to +70 deg C
• Vibration: 10 g
• Storage Temperature Range: -40 to +125 deg C
• Shock: 100 g

Water Level Indicator, Automatic Water Level Controller

We are the main supplier of this product.

It is designed for most critical requirements of liquid level in vessels under high pressure & temperature condition in petrochemicals, fertilizer and pharmaceuticals & chemical industries involving inflammable toxic liquid, high temp Liquids.
