Linear Grill Dealers in Vadodara

• Type: Grille
• Shape: Square
• Color: White, Powder Coated
• Brand Name: HES
• Material of Construction: Aluminium Extrusion Powder coated white
• Finish: Powder Coated

• Frame: High quality extruded aluminium profile with 30 mm flange width as standard. 12,16,24 mm flange widths are optional.
• Face Bar: High quality aluminium profiles of 0°, 15° - 1 way throw and 15° - 2 way throw.
• Grille width: 50 mm to 300 mm with increments of 50 mm.

Frame and face bars are of high quality extruded aluminium profiled construction with the advantages of corrosion resistance and rigidity.Horizontal face bars with 0°, 15° - 1 way throw and 15° - 2 way throw are fixed rigidly to the frame with 8 mm pipes.Vertical aluminium aerofoil blades are fixed at the rear side of the frame by nylon bushes. These blades can be adjusted manually and individually in the vertical plane to obtain optimum air distribution.For perfect unbroken appearance of continuous runs, alignment strips are provided.Total structure is manufactured by mechanical assembly, assuring rigidity and to maintain straight line appearance. Foam gasket is sealed around the back of the frame as option to avoid air leakage.Supplied with C - clamps for concealed fixing.

linear supply air grill, linear return air grill, adjustable grills
