PTFE Pipe Dealers in Vadodara

• Material: PTFE
• Type: Vacuum Hose Pipe
• Shape: Round
• Country of Origin: Made in India
• Size/ Diameter: 2 Inch
• Length of Pipe: 6 m
• Application: Chemical Handling
• Maximum Operating Temperature: -29 to 260 Deg. C

We are well-known Manufacturers, Exporters and Suppliers of CS PTFE Lined Pipes are manufactured under the supervision of experienced professionals in order to assure the finest quality and durability. We can make available Lined Pipes in different grades and sizes as per the requirement of buyers. Our CTFE Lined Pipes have wide construction applications. We provide CS PTFE Lined Pipes at the most affordable prices.   Description :  Super Provides CS PTEF Lined Pipes from 25 NB TO 450 NB Size. Super has own In-house Fabrication, Extrusion, Lining and Flaring department for manufacturing of CS PTFE Lined Pipes. The Pipe Material used is 106 Grade B Sch 40 from 25 NB to 150 NB and above Sch 20 Pipes are used. The Flanges normally used are of ASTM A 105/IS 2062. Resin used for Making PTFE Liners is procured from DuPont. The pipe spools are lined with an interference fit paste extruded PTFE liner flared at each end to raised face dimensions giving all wetted parts in PTFE. Up to 6" NB the pipe spools use heavy duty PTFE liner suitable for vacuum performance. Above 6"NB we offer both heavy wall vacuum rated liners and standard wall liners as appropriate for the application. ALL CS/PTFE Lined Pipes are tested as Per ASTM F 1545 Which Includes Visual, Dimensional, Hydro Test at 29.8 Kg/cm2 and Spark Test 15 KVA.

Where highly corrosive materials are used in any area of Chemical process industry. Provides improved operational safety for personnel, processes and plants when handling extremely hazardous materials. Where product purity is critical viz:- Foods, Pharmaceuticals and Fine Chemicals. Where pipe replacement frequently is difficult or impossible. Where environmental pollution is to be avoided. Lining Available: PTFE/FEP/FEA

• Application: Industrial
• Size of MSTL Pipe line: depend upon sizes and length
• Size of Ball Valves: Depend upon Sizes
• Warranty: we provide warranty

We are manufacturer of Borosilicate Glass, MS PTFE Lined Products & Pure PTFE Products, So if you need any of these products then kindly contact us or email us.

• Shape: Round

VESCOAT offers PTFE Lined Dip pipe, PTFE Lined Sparger, PTFE Drop Tube, PTFE Nozzle Liners, PTFE Lined J Type Dip Pipe in various shape and size as per the glass lined reactors, agitator vessel and customize as per the customers requirement.VESCOAT Lined dip pipes are manufactured from a carbon steel fabricated construction with a PTFE liner both inside and Outside Pipe and Nozzle liner and Sparger from Pure PTFE Material.We provide Extra reducing flange on dip pipe which allow fitting on different size nozzles of vessel.   AVAILABLE Range :PTFE Lined Dip PipePTFE Lined J Type Dip PipePTFE Lined SpargerPure PTFE Dip PipePTFE Nozzle LinersPTFE Drop Tube Technical Specification :Pipe : A106 Gr. B, Seamless Sch 40 and Sch 80Flange : IS2062, A105, SS304, SS316Liner : PTFE (Both side) Details Require for Dip Pipe Inquiry:1. Mounting Nozzle Size on GLR2. Connection Nozzle Size at Top3. Straight / Tapper / J Type4. Flange Drilling Dimension5. Length

star scientific glass co. Is counted among the supreme ptfe pipes manufacturers and suppliers located in india. Our skilled workers use the best raw materials in the production of ptfe lined pipes. We can also offer plastic lined pipes according to the length specified by the client. We can also supply ptfe lined pipes that have a jacketed arrangement in them. Our ptfe lined pipes are highly valued for their effectuality and reliability. We proffer ptfe lined pipes at reasonable rates, which would not affect your pocket.

ALL DIMENSIONS ARE IN MM PIPE ANSI B 36.1D, ASTM A 10B GR B SCH 40 Upto 150 nb, 200 nb to 600 nb mn sch 20* & 700 nb onwards std sch* 450 & Above Sch pipe as above or welded construction from IS 2062 Plates with Spot X-Ray FLANGE : ANSI B. 16.5 ASA 150# IS 2022 GR A. LINER :ASTM D 1457 TYPE -II PTFE / 700 NE ONWARDS PTFE WELDED LINER STANDARD MAX. LENGTH OF PIPE 3000 MM THE TOLERANCES OF LENGTH OF PIPE +/- 3.2 LINING AND OTHER DIMENSIONAL TOLERANCES AS PER ASTM A 1545 9B / ASTM D 1457 TYPE III OTHER SPECIFICATIONS / DIMENSIONS / VACCUM / SERVICE AVAILABLE ON REQUEST P* G-2MM: J* 0.88 G

Our PTFE lined pipe series starts from 25mm to 300mm Diameter and up to 3000mm in lengths. Our standard pipes are with one end fix flange and one end loose flange. We can supply both end fix flanges and loose flanges on specific requirements.Jacketed pipes with various metals (fabricated steel, cast ductile iron, 304 and 316 stainless steel, etc.) are available. It is also possible to vary Metal Pipe thickness (S10, S20, S40, S80, etc.) on a special order basis.Standard flange thickness is as per AISI standards. Flanges 150 #, 300# and DIN rotating flanges are available in a variety of materials.All our standard pipes are supplied with vent holes for leakage detection during operation

Being a prominent firm, we are offering an exclusive array of CS PTFE Lined Pipes. Our pipes find an extended application in a number of industries. These pipes are rigorously tested examined against a series of parameters, considering that we are delivering a defect-free range from our end. Also, we manufacture these pipes in a wide range of sizes and dimensions to choose from. Our offered pipes are widely popular across the industry for featuring variegated attributes like dimensional accuracy, compact design, and perfect finish.

We are offering PTFE lined hose pipe.

• capacity: 29.9 kg/cm2(g)

The leading global provider of process equipment, engineered system & process solution. It has contributed effectively across many industry verticals. Ptfe lined dip pipe 100% visual check dimensional check. 100% hydro test at 29.9 kgcm2(g) for holding time of 3 mins. As per astm f 1545 - 15a.

• Material: SS / MS / CS
• Application: Industrial
• Country of Origin: Made in India
• Size/Diameter: 15NB TO 600NB
• Length of Pipe: Upto 3 m
• Maximum Operating Temperature: 200 Degree

Teflon Hose Pipe, Flush Bottom Valve, Laboratory Centrifuges

PTFE Lined Spool Pipes, ptfe lined pipes fittings, PTFE Lined Tee

teflon lined pipes, PTFE Lined Pipes, Pfa Lined Ball Valve

dip pipes are used to introduce products into reactors and columns. Manufactured in carbon steel and lined inside and outside with PTFE extruded liner, they are designed to bring the product up to the heart of the reaction despite the corrosive environment.

We are offering teflon hose pipe.the teflon hose pipe offered by us is frequently used in several clinics and laboratories. The ptfe teflon hose pipe we deal in is strong enough to withstand high pressure. It is resistant to various chemicals and high temperature which makes it an ideal one to be used in laboratories. The flexible teflon hose pipe is non-sticky to almost all the chemicals which ensure 100% purity of the chemicals passed through it. We are among the leading teflon hose pipe exporters in india.
