Reducing Flanges Dealers in Vadodara

Reducing flanges are used in pipe-to-pipe connections. Reducing flanges are a little easier to bolt up than non-reducing flanges. They provide the most perfect solution when you need to connect different size flanges. They offer the simplest and least expensive method of mating two different sized flanges.

• Material: Stainless Steel
• Country of Origin: Made in India
• Size/ Diameter: 2 inch
• Pipe Size: 1 inch
• Fitting Type: Tee
• Usage/ Application: Gas
• Liner Thickness: 3.5mm

ALL DIMENSIONS ARE IN MM FOR OTHER DIMENSIONS PLEASE SEE 'LINED PIPE' PAGE MATERIAL OF CONSTRUCTION EQUAL TEE: EQUAL CROSS BODY (PIPE) ANSI B 46.10 ASTM A 216 Gr. WCB / ASTM A 106 Gr. B FLANGE : ANSI B. 16.5 ASA 150W IS 2002 LINER : ASTM D 3418 ASTM D 2116

• Material: CS / MS / SS
• Size: 15NB to 600NB
• Country of Origin: Made in India
• Brand Name: NG
• Usage/ Application: Industrial
• Thickness: 3mm to 6mm

• Size: 1" to 12" inch
• Shape: cylindrical
• Country of Origin: Made in India
• Product Type: Lined Component
• Pressure: 20 bar/300 psi.g. Full vacuum resistance depending upon the Process conditions

We are offering mstl reducing flange. Mstl reducing flange offered by us, is available with us in various sizes and shapes. We proffer our highly acclaimed mstl reducing flange at reasonable prices.

Manufacturing of Lined Pipes, Fittings, and Valves. We are also into the manufacturing of Virgin PTFE Products like Bushes, Sheets, Rods, Bellows, Feed Pipes, Dip Pipes, and Ropes etc.

FEPPFA lined reducing flanges can be grouped into different types, the configuration is based on the closeness of the small bore bolt holes to the large bore bolt holes. Each type is designed so that they do not clash and that the nuts can be fitted successfully.

• Size: 15NB TO 300NB ( ¾” TO 12” )
• Temperature: -29℃
• Length: As per Standard of B16.5 & ANSI B 16.42
• Liner: PFA    – Per Fluoro Alkoxy, ASTM D3307 FEP    – Fluorinated Ethylene Propylene,  ASTM D2116 HDPE –  As per Standard
• Body: As per ASTM A 234 Gr. WPB / DI A395 / SS304 / SS316 ( Seamless)
• Steel Housing: Carbon steel or Stainless Steel
• Flanges: ASTM A 105 (N) / IS 2062 / ASTM A351 GR CF8 & CF8M
• Drilling / Pressure: ASA 150# / 300# / DIN / Table – F
• Dimensional STD: Reducing Flange: B16.5 & ANSI B 16.42 Flanges               : ASME B 16.5 Lining Standard : ASTM F 1545
• Vacuum: Full vacuum rated

Reducing Flange, Standard Typical Units, Sight Glass, Column Components

PTFE LINED REDUCING FLANGE, PTFE Lined Pipes, PTFE Bellows, Ptfe Products

Reducing Flanges

PTFE Lined Reducing Flanges, T Bolt Clamp, PTFE Teflon Butterfly Valve
