Ropp Cap Sealing Machine Dealers in Vadodara

No bottle no cap sensor. S.S. elegantly matt finished body. Adjustable height of conveyor belt, to align with other machine of the line. Sealing pressure can be varied to suit different gauges and size of caps. Low noise level, low power consumptions. Drain tray around the machine platform. VFD to synchronize, Conveyor, Star wheel and Platform turret & capping bowl. Universal coupling for quick and easy setting of In-feed worm. Adjustable bottle height gauge for easy and quick setting.

• Direction Of Movement: Left to Right.
• Packaging Type: Packet
• Height of Conveyor**: 860 mm to 910 mm.
• Electrical Specification – Main Motor: 300 Watt, Magnetic coil.
• Electrical Specification - Cap Feeding Bowl: 1 HP / 415 Volts / 50 Hz.
• No. of Sealing Head: 1 Nos.
• Output/Hour*: 1000 to 3000 bottles.
• Model: KEF-60

Depends on bottle size, cap size and type of cap. ** We can supply as per customer requirements. *** With help of change parts. Description: The Automatic Cap Sealing Machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are provided to facilitate the servicing of machine. Operation: The feed container moving on conveyor belt are fed into star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the bottle pickup a cap from the delivery chute of cap feeding bowl, where the body and the neck of the container are positioned below the rotating head. Where the sealing head is performing perfect operation of threading & sealing.   Salient Features: No container No cap arrangement. SS elegantly matt finished body. Single motor synchronizes conveyor, star wheel, & platform turret. Adjustable height of conveyor belt, to align with other machine of the line. Sealing pressure can be varied to suit different gauges and size of caps. Low noise level, low power consumptions. Self-lubricating UHMW- PE guide profile for low friction wears surface, smooth and noiseless conveying. SS cladding or hard chrome platting of all exposed parts to ensure long life and resistance against corrosion. Synchronized A/C drives to synchronize, Conveyor, Star wheel and Platform turret & capping bowl. Adjustable bottle height gauge for easy and quick setting.

Single Head / Four Head GMP Model Output : 40-90 Bottles per Minute (Depending on Bottle Size) Capping Attachment for PVC Cap (optional) Speed Variation by AC Drive (optional)
