Solvent Recovery System
Get Price Quote
1 Piece (MOQ)
Discover the transformative potential of Solvent Recovery Systems by K-Jhil. Designed to reclaim and recycle solvents from industrial processes, our cutting-edge facilities offer a sustainable solution to solvent management. By capturing and purifying solvents for reuse, our systems reduce waste and significantly lower procurement costs for businesses. Experience the versatility and efficiency of Solvent Recovery, seamlessly integrating chemical reaction and distillation in a single unit. From esterification to dehydration, our technology caters to diverse industries, including petrochemicals, pharmaceuticals, and specialty chemicals. Join the sustainable revolution with K-Jhil’s Solvent Recovery Systems.Salient Features : Distillation Units : Distillation is a common method for solvent recovery. The used solvent is heated in a distillation unit, and the vapor is collected and condensed back into a liquid. This process separates the solvent from impurities or contaminants. Condenser and Coolers : These components are crucial for converting the vaporized solvent back into a liquid form. They help in the separation of the purified solvent from other substances. Recovery Columns : Recovery columns enhance the separation of different components within the solvent mixture. They help improve the efficiency of the distillation process. Filtration and Purification Systems : Filtration systems remove solid impurities or particulate matter from the solvent. Additional purification methods may include adsorption or chemical treatments to remove remaining contaminants. Storage Tanks : Recovered and purified solvents are typically stored in tanks before being returned for reuse. Proper storage is important to maintain the quality of the recovered solvent. Monitoring and Control System : Automated systems monitor and control various parameters such as temperature, pressure, and flow rates to ensure the efficiency and safety of the solvent recovery process. Applications : Pharmaceutical Industry : Solvent recovery is crucial in pharmaceutical manufacturing processes. Chemical Industry : Used for the recovery of solvents in various chemical processes. Manufacturing Sector : Common in industries where solvents are utilized for cleaning and processing.
Solvent Recovery System
Get Price Quote
We are one of the renowned Solvent Recovery System Manufacturers and Suppliers in India. Our SRV is designed for system sizes handling 25-250 gallons per hour and is the simplest and highest performance system design in its price range. Construction This Solvent Recovery System is composed of a non-scraped vessel with a 70 cone design which incorporates a unique steep walled distillation chamber. This is surrounded by a large volume oil bath heated with electric immersion heaters or optional steam coils. The design of SRV provides excellent heat transfer characteristics because of the large surface area in contact with the solvent and the oil media. In most applications, the steep walls keep the inside surfaces of the distillation chamber free of sludge build-up for maximum heat transfer from the hot oil media, and assists in discharging the sludge from a bottom mounted 6" discharge valve. Use : Our Solvent Recovery System is utilized for waste streams which are not prone to hardening in the presence of liquid solvent, and provides ease of residue removal.
